  • Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks | New
Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks | New

Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks | New

SKU: C1000-16T-2G-L-N
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$359.99 $359.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks | New

The Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks is a trusted and high-performance Layer 2 managed switch intended for small enterprises, branch offices, and IoT applications. With advanced features, strong security, and efficient network management, this switch provides easy connectivity for current business applications while also maintaining scalability and stability. This Catalyst switch has 16 Gigabit Ethernet ports for fast connectivity and two SFP uplink ports for easy network expansion. It has a switching capacity of 36 Gbps and a forwarding bandwidth of 18 Gbps, ensuring seamless data transfer between devices. The switch's compact, rack-mountable form size and fanless operation make it ideal for quiet locations such as offices or classrooms. Advanced security features like Access Control Lists (ACLs) and IEEE 802.1X authentication offer robust protection against illegal access.


Key Features of Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks


• 16 Gigabit Ethernet Ports with high-speed connectivity for end devices like computers, printers and IP phones.

• 2 SFP Uplink Ports enables seamless network expansion with high-speed fiber connections.

• Layer 2 Switching includes VLANs, QoS, IGMP snooping and link aggregation for optimized traffic management.

• Advanced Security features ACLs, IEEE 802.1X authentication, port security and IP source guard.

• Fanless Design with silent operation suitable for noise-sensitive environments.

• Energy Efficiency complies with Energy Efficient Ethernet (EEE) standards to reduce power consumption.

• Rack-mountable design fits neatly into small spaces.

• Managed via CLI or an intuitive web-based interface.

• Supports up to 26.78 Mpps forwarding rate for efficient data handling.


Benefits of Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks


🗹 Provides reliable high-speed connections for a variety of devices and applications.

🗹 SFP uplink ports enable easy integration with core networks or additional switches.

🗹 Protect sensitive data with advanced security features like ACLs and port authentication.

🗹 Layer 2 features ensure efficient handling of network traffic for improved performance.

🗹 Fanless design ensures quiet performance in noise-sensitive environments like offices or classrooms.

🗹 Energy-efficient technologies help reduce operational costs over time.

🗹 Fits neatly into any workspace without taking up excessive space.

🗹 Intuitive management options simplify installation and configuration.

🗹 Built with Cisco’s trusted quality for long-term use in demanding environments.

🗹 Advanced features ensure compatibility with evolving business needs.

Specifications

Specification of Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks | New

ManufacturerCisco
Manufacturer Part NumberC1000-16T-2G-L
Product NameCisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks
Product TypeNetworking Switch
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
16 x 10/100/1000 + 2 x Gigabit SFP (uplink)
Performance
Forwarding bandwidth: 18 Gbps ¦ Switching bandwidth: 36 Gbps ¦ Forwarding rate (64‑byte L3 packets): 26.78 Mpps
Capacity
Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte
Jumbo Frame Support
10240 bytes
Routing Protocol
IGMP, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Authentication Method
Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), fanless, Shaped Round Robin (SRR), LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, Management Information Base (MIB), Class of Service (CoS), 802.1x authentication, DiffServ Code Point (DSCP) support, IGMP filtering, IP source guard, Weighted Tail Drop (WTD), SmartPort technology, VLAN Trunking Protocol (VTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), proxy ARP, Switched Port Analyzer (SPAN), loopback detection, MAC Access Bypass (MAB), BPDU Guard, Network Edge Access Topology (NEAT)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX
Processor
X ARM: 800 MHz
RAM
512 MB
Flash Memory
256 MB
Status Indicators
Status
Interfaces
16 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A
Power Device
Internal power supply
Installed Qty
1
Voltage Required
AC 120/230 V (50 - 60 Hz)
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A
Width
10.6 in
Depth
10.7 in
Height
1.7 in
Weight
3.92 lbs
Service & Support
Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature
23 °F
Max Operating Temperature
122 °F
Humidity Range Operating
5 - 90%
Min Storage Temperature
-13 °F
Max Storage Temperature
158 °F
Humidity Range Storage
5 - 95%

User Guides

Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks Data Sheet

Frequently Asked Questions

Cisco Catalyst 1000-16T-2G-L 16-Port Gigabit Ethernet Switch with 2 SFP Uplinks
Frequently Asked Questions (FAQ's)



What type of switch is the Cisco Catalyst C1000-16T-2G-L?
  • It is a fixed managed Layer 2 Gigabit Ethernet switch intended for small installations and sensitive IoT applications.
    • How many ports does this switch have?
  • It has sixteen Gigabit Ethernet connections and two Gigabit SFP uplink connectors.
    • Is the Cisco Catalyst C1000-16T-2G-L fanless?
  • Yes, all 16-port versions, including this one, are fanless, resulting in silent operation.
    • Does this switch support Power over Ethernet (PoE)?
  • No, the C1000-16T-2G-L does not support PoE.
    • What management options are available for this switch?
  • It runs Cisco IOS® Software and provides device and network administration through a Command-Line Interface (CLI) and an on-board web UI.
    • Is the Cisco Catalyst C1000-16T-2G-L stackable?
  • No, this model does not allow stacking.
    • What security features are included?
  • It provides enterprise-level security, including 802.1X authentication, access control lists (ACLs), and DHCP snooping.
    • How do I reset the switch to factory defaults?
  • To reset the switch, press and hold the Mode button while the device is turned on until the system LED goes amber. When you release the button, the switch will begin to reset itself.
    • Does it support VLANs?
  • Yes, it does support VLAN setups for network segmentation.
    • Does the switch support stacking?
  • No, the Cisco Catalyst C1000-16T-2G-L does not allow stacking.
    • What is the maximum VLAN capacity?
  • The switch can support up to 256 VLANs at once.
    • Is IPv6 supported?
  • Yes, it supports IPv6.
    • What QoS features are available?
  • Quality of Service (QoS) capabilities are available to help prioritize network traffic.
    • Is there a web-based management interface?
  • Yes, the switch includes an on-board web interface for easy management.
    • What is the forwarding capacity of the switch?
  • The switch supports a forwarding bandwidth of 18 Gbps.
    • Are there any fanless models in the Catalyst 1000 Series?
  • Yes, all 16-port versions are fanless, including the C1000-16T-2G-L.
    • What is the power consumption of the switch?
  • The normal power consumption is about 13.5 watt.
    • Does it support SNMP?
  • Yes, it supports the Simple Network Management Protocol (SNMP).
    • Can the switch be managed via a web interface?
  • Yes, it has an on-board web interface for management.
    • Is the switch suitable for industrial environments?
  • It is intended for modest deployments and critical IoT applications; applicability for industrial environments is contingent on individual requirements.
