Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage | Refresh
SKU: IE-3300-8T2S-A-RF
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage | Refresh
The Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage is intended for industrial environments. This switch is an excellent choice for providing dependable Gigabit Ethernet connectivity in harsh environments, thanks to its rugged construction, advanced features, and flexible modular design. The Cisco Catalyst IE-3300-8T2S-A-RF has 8 Gigabit Ethernet RJ-45 ports and 2 SFP-based fiber ports for a flexible mix of copper and fiber connectivity. Its modular design allows for up to 26 ports of expansion, ensuring scalability to meet increasing network demands. The switch is designed to withstand extreme temperatures, vibrations, and other environmental challenges, making it suitable for a variety of applications including manufacturing, energy, transportation, mining, and more. The IE-3300-8T2S-A-RF is an excellent choice for industrial organizations seeking to deploy a dependable and scalable network infrastructure under demanding conditions. Its rugged design, adaptable modular architecture, and advanced capabilities make it an invaluable asset in any industrial setting.
Key Features of Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage
• 8 Gigabit Ethernet RJ-45 Ports delivers high-speed connectivity for a variety of devices.
• 2 SFP-based Fiber Ports offers flexible uplink options for fiber connectivity.
• Expandable up to 26 ports, allowing for future growth and adaptability.
• Designed to operate in harsh environments, withstanding extreme temperatures, vibrations, and other challenges.
• Provides advanced security features, API-driven configuration, and seamless integration with Cisco management tools.
• DIN Rail Mounting enables easy installation in industrial environments.
• Network Advantage License includes advanced features like Flexible NetFlow and Cisco Secure Network Analytics for enhanced visibility and security.
Specifications
Specifications for Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage | Refresh
| Manufacturer | Cisco |
| Manufacturer Part Number | IE-3300-8T2S-A-RF |
| Product Name | Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage |
| Product Type | Switch |
Enclosure Type | DIN rail mountable |
Subtype | Gigabit Ethernet |
Ports | 10 x 10/100/1000 + 2 x SFP |
Capacity | Queues: 8 ¦ IGMP multicast groups: 1000 ¦ VLAN IDs: 256 ¦ STP instances: 128 |
Routing Protocol | IGMPv2, IGMP, IGMPv3 |
Remote Management Protocol | SNMP, SNMP 3, SSH, SCP, NTP, DHCP |
Authentication Method | RADIUS, TACACS+ |
Features | IGMP snooping, Syslog support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, RSTP support, MSTP support, DHCP snooping, DHCP server, DAI, PVST+, UDLD, LLDP support, RSPAN, FNF, IGMP filtering, Storm Control, IP source guard, REP, SmartPort technology, rate limit, IGMP querier, Voice VLAN, Guest VLAN, Inter-VLAN Routing, SPAN, VTP v.3, BPDU Guard, VTP v.2 |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 1588v2 |
RAM | 2 GB |
Flash Memory | 1.5 GB |
Built-in Devices | SD card reader |
Interfaces | 10 x 10/100/1000 Base-T RJ-45 ¦ 2 x SFP ¦ 3 x alarm ¦ 1 x serial (RS-232) RJ-45 console ¦ 1 x console mini-USB |
Power Device | Internal power supply |
Voltage Required | DC 9.6 - 60 V |
Power Consumption Operational | 33 Watt |
MTBF | 633,420 hours |
Compliant Standards | EN55024, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-8, IEC 60950-1, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, EN 61326-1, EN 61000-4-16, EN 61000-4-29, IEC 60068-2-14, IEC 60068-2-78, MIL-STD-810, EN 50121-4, IP30, VCCI Class A, CISPR 11 class A, EN 61000-4-10, EN 61000-4-18, IEC 61850-3, FCC CFR47 Part 15 B Class A, IEEE 1613, CNS 13438 Class A, EN 300 386, KN35, UL/CSA60950-1, AS/NZS CISPR 32 Class A, KN32 Class A, IEC 62368-1, IEEE 1588, EN 60068-2-52, EN 60068-2-60, UL 62368-1, EN 60079-15, IEC 60079-0, IEC 60079-15, EN 60079-0, EN 55032/CISPR 32 Class A, CISPR 35, EN 61000-4-17, UL 121201, EN 61850-3, UL/CSA 61010-2-201, IEC/EN 61010-2-201, UL/CSA 60079-0, UL/CSA 60079-15 |
Width | 3.6 in |
Depth | 5.3 in |
Height | 6 in |
Weight | 3.75 lbs |
Service & Support | Limited warranty - 5 years |
Min Operating Temperature | -40 °F |
Max Operating Temperature | 140 °F |
Min Storage Temperature | -40 °F |
Max Storage Temperature | 185 °F |
User Guides
Frequently Asked Questions
Cisco Catalyst IE-3300-8T2S-A-RF 8-Port Gigabit Ethernet Expansion Module Network Advantage
Frequently Asked Questions (FAQ's)
Does the Cisco Catalyst IE-3300-8T2S-A support industrial protocols like Modbus or PROFINET? Yes, it supports industrial protocols like Modbus TCP, PROFINET, and Common Industrial Protocol (CIP) to ensure seamless integration with industrial systems.
What is the difference between the RF and non-RF versions of this switch? The RF (Remanufactured) version is a Cisco-certified remanufactured model that provides the same performance, reliability, and warranty as a new product but at a lower cost.
Can the Cisco Catalyst IE-3300-8T2S-A be integrated into existing IT networks? Yes, it can be integrated into both IT and OT networks, providing convergence via Cisco DNA and automation capabilities for unified management.
What environments is the Cisco Catalyst IE-3300-8T2S-A designed for? It is designed for use in harsh industrial environments such as manufacturing plants, transportation systems, utilities, smart cities, and other industries.
What type of ports does the Cisco Catalyst IE-3300-8T2S-A provide? The switch has eight Gigabit Ethernet ports and two SFP (Small Form-Factor Pluggable) uplink ports for fiber or copper connections.
Is the Cisco IE-3300-8T2S-A suitable for outdoor use? Yes, it is ruggedized to withstand extreme environmental conditions such as temperature fluctuations, dust, moisture, and vibration, making it suitable for use outdoors or in harsh environments.
What is the power input requirement for the Cisco Catalyst IE-3300-8T2S-A? The switch has dual redundant power inputs and accepts a wide range of input voltages, ensuring operational reliability in industrial applications.
What kind of management options does the Cisco Catalyst IE-3300-8T2S-A support? The switch can be managed via CLI (Command Line Interface) or web, and it also supports Cisco DNA for automation and centralized control.
What is the maximum operating temperature for the Cisco Catalyst IE-3300-8T2S-A? The switch can operate in temperatures ranging from -40°C to 70°C (-40°F to 158°F), making it ideal for harsh environments.
Is the Cisco Catalyst IE-3300-8T2S-A compatible with Cisco DNA Center? Yes, it supports Cisco DNA for automation, policy-based networking, and centralized management, which enables seamless integration with IT and OT networks.
Does the Cisco Catalyst IE-3300-8T2S-A support PoE (Power over Ethernet)? This model does not support PoE. Other models in the Cisco IE3300 series may include PoE capabilities.
What redundancy features are supported by the Cisco Catalyst IE-3300-8T2S-A? The switch supports redundancy protocols such as Resilient Ethernet Protocol (REP) and EtherChannel, as well as ring topologies, to ensure network resiliency.
What certifications does the Cisco Catalyst IE-3300-8T2S-A have for industrial use? It has IP30, UL, and IEC certifications for industrial-grade standards, ensuring dependability in harsh industrial environments.
Can the Cisco Catalyst IE-3300-8T2S-A be used in transportation networks? Yes, it is best suited for transportation applications such as roadside networks, rail systems, and other infrastructure.
What security features are included in the Cisco Catalyst IE-3300-8T2S-A? Cisco TrustSec, MACsec encryption, role-based access control, and secure device management are among the security features available.
Is the Cisco IE-3300-8T2S-A-RF suitable for outdoor use? Yes, it is ruggedized to withstand extreme environmental conditions such as temperature fluctuations, dust, moisture, and vibration, making it suitable for use outdoors or in harsh environments.
Is the Cisco Catalyst IE-3300-8T2S-A modular? Yes, the IE-3300 series supports modular expansion, allowing for additional interface modules to increase flexibility and scalability.
How does the Cisco Catalyst IE-3300-8T2S-A handle industrial IoT (IIoT) deployments? It supports IIoT and OT (Operational Technology) networks and offers real-time monitoring, industrial protocols, and secure networking, making it ideal for smart factory and automation applications.
What are the deployment options for the Cisco Catalyst IE-3300-8T2S-A? It can be installed in DIN rail or wall-mount configurations, depending on the environment and available space.
What is the primary benefit of using the Cisco Catalyst IE-3300-8T2S-A in industrial environments? Its rugged design, modularity, advanced security features, and ability to operate in harsh environments make it an excellent choice for ensuring reliable and secure network performance in critical industrial applications.
