Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | New
SKU: C1000-16FP-2G-L-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | New
The Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks is a high-performance, enterprise-grade network switch intended for small and medium-sized organizations. This switch, which combines robust security, powerful Layer 2 capabilities and Power over Ethernet Plus (PoE+) compatibility, provides dependable and efficient connectivity for modern corporate environments such as offices, retail spaces and educational institutions. The Catalyst 1000-16FP-2G-L has 16 Gigabit Ethernet ports that support PoE+, giving up to 30W per port to power devices such as IP phones, wireless access points and security cameras. It also has two SFP uplink ports that provide high-speed fiber connectivity to other switches or core networks. With a total PoE budget of 240W and a fanless design for silent operation, this switch is excellent for deployments that demand low power consumption and quiet performance. Advanced security features such as access control lists (ACLs) and IEEE 802.1X ensure full network protection.
Key Features of Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks
• 16 Gigabit Ethernet Ports with high-speed connectivity for end devices like computers, printers and IP phones.
• PoE+ Support delivers up to 30W per port with a total PoE budget of 240W for powering connected devices.
• 2 SFP Uplink Ports provides high-speed fiber connectivity for seamless network expansion.
• Layer 2 Features includes VLANs, QoS and link aggregation for efficient traffic management.
• Advanced Security features ACLs, IEEE 802.1X authentication and port security to safeguard the network.
• Fanless Design with silent operation suitable for noise-sensitive environments like offices or classrooms.
• Energy-Efficient Operation complies with Energy Efficient Ethernet (EEE) standards to reduce power consumption.
• Space-saving design fits easily into rack-mounted or standalone setups.
• Managed through an intuitive web-based interface or Cisco Network Assistant.
Benefits of Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks
🗹 PoE+ support eliminates the need for separate power adapters, reducing cable clutter.
🗹 SFP uplink ports enable high-speed connections to other switches or core networks.
🗹 Protects sensitive data with advanced security features like ACLs and 802.1X authentication.
🗹 Layer 2 features ensure efficient handling of network traffic for better performance.
🗹 Fanless design makes it ideal for noise-sensitive environments such as offices or classrooms.
🗹 Reduces operational costs with energy-saving technologies.
🗹 Compact size and web-based management simplify installation and configuration.
🗹 Designed for long-term use in demanding business environments with Cisco’s trusted quality.
🗹 Suitable for both rack-mounted and standalone setups.
🗹 High-speed uplinks and advanced features ensure compatibility with evolving network needs.
Specifications
Specification for Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | New
| Manufacturer | Cisco |
| Manufacturer Part Number | C1000-16FP-2G-L |
| Product Name | Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks |
| Product Type | Networking Switch |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 16 x 10/100/1000 (PoE+) + 2 x Gigabit SFP (uplink) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 240 W |
Performance | Forwarding bandwidth: 18 Gbps ¦ Switching bandwidth: 36 Gbps ¦ Forwarding rate (64‑byte L3 packets): 26.78 Mpps |
Capacity | Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte |
Jumbo Frame Support | 10240 bytes |
Routing Protocol | IGMP, MLDv2, MLD, MSTP, RSTP, STP |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS |
Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
Features | BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), fanless, Shaped Round Robin (SRR), LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, Management Information Base (MIB), Class of Service (CoS), 802.1x authentication, DiffServ Code Point (DSCP) support, IGMP filtering, IP source guard, Weighted Tail Drop (WTD), SmartPort technology, VLAN Trunking Protocol (VTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), proxy ARP, Switched Port Analyzer (SPAN), loopback detection, MAC Access Bypass (MAB), BPDU Guard, Network Edge Access Topology (NEAT) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX |
Processor | X ARM: 800 MHz |
RAM | 512 MB |
Flash Memory | 256 MB |
Status Indicators | Status |
Interfaces | 16 x 1000Base-T RJ-45 PoE+ - 15 W ¦ 2 x 1000Base-X SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A |
Power Device | Internal power supply |
Installed Qty | 1 |
Voltage Required | AC 120/230 V (50 - 60 Hz) |
Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A |
Width | 10.6 in |
Depth | 12.1 in |
Height | 1.7 in |
Weight | 5.49 lbs |
Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days |
Min Operating Temperature | 23 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 5 - 90% |
Min Storage Temperature | -13 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 5 - 95% |
User Guides
Frequently Asked Questions
Cisco Catalyst 1000-16FP-2G-L 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks
Frequently Asked Questions (FAQ's)
What is the Cisco Catalyst C1000-16FP-2G-L switch? The Cisco Catalyst C1000-16FP-2G-L is a managed, Layer 2, PoE+ network switch designed for small to medium-sized businesses.
How many ports does the Cisco C1000-16FP-2G-L have? It has 16 Gigabit Ethernet ports and 2 Gigabit SFP uplink ports.
Does the Cisco C1000-16FP-2G-L support PoE? Yes, it supports PoE+ (Power over Ethernet) with a total power budget of 240W.
What is the power budget of the Cisco C1000-16FP-2G-L switch? The switch has a PoE power budget of 240W, ideal for powering IP phones, access points, and other PoE-enabled devices.
Is the Cisco Catalyst C1000-16FP-2G-L suitable for small businesses? Yes, it is specifically designed for small to medium-sized businesses requiring reliable connectivity.
What type of uplink ports does the Cisco C1000-16FP-2G-L provide? It provides 2 SFP uplink ports for fiber or high-speed Ethernet connections.
Does the Cisco Catalyst C1000-16FP-2G-L support Layer 2 switching? Yes, it is a Layer 2 switch, ideal for small business network environments.
What are the management options for the Cisco C1000-16FP-2G-L? It offers web-based management via Cisco Network Assistant and supports CLI and SNMP.
Can the Cisco C1000-16FP-2G-L be used in a stacking configuration? No, the Catalyst C1000-16FP-2G-L does not support stacking.
What is the switching capacity of the Cisco Catalyst C1000-16FP-2G-L? The switch offers a total switching capacity of 36 Gbps.
Does the Cisco Catalyst C1000-16FP-2G-L have fanless operation? No, this switch is not fanless; it uses a fan for cooling.
How do I configure the Cisco Catalyst C1000-16FP-2G-L switch? It can be configured using the Cisco Network Assistant or through its web-based GUI.
What VLAN features does the Cisco C1000-16FP-2G-L support? It supports VLAN tagging (802.1Q), voice VLAN, and guest VLAN, offering robust segmentation options.
Does the Cisco Catalyst C1000-16FP-2G-L support QoS? Yes, it supports advanced Quality of Service (QoS) features to prioritize traffic.
What security features are available in the Cisco C1000-16FP-2G-L switch? It includes features like 802.1X authentication, port security, and access control lists (ACLs).
Is there a built-in power supply in the Cisco C1000-16FP-2G-L? Yes, it comes with a built-in power supply.
What mounting options are available for the Cisco Catalyst C1000-16FP-2G-L? The switch is rack-mountable and can be mounted using the included rack-mount kit.
Does the Cisco Catalyst C1000-16FP-2G-L support IPv6? Yes, it supports IPv6 addressing and management.
What are the dimensions of the Cisco C1000-16FP-2G-L switch? The switch measures 17.5 x 9.5 x 1.73 inches (440 x 240 x 44 mm).
What is the operating temperature range for the Cisco Catalyst C1000-16FP-2G-L? The operating temperature range is between 0°C to 40°C (32°F to 104°F).
