Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | New
SKU: C1000-16P-2G-L-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview for Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | New
The Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch is an enterprise-class Layer 2 managed switch intended for small enterprises and branch offices that require dependable network connectivity with Power over Ethernet features. This versatile network switch combines powerful features with accessible management, making it excellent for setting up IP phones, wireless access points, and security cameras. The C1000-16P-2G-L provides 120W of PoE+ power via 16 Gigabit Ethernet ports and two SFP uplink ports for network expansion2. With its fanless design and extensive security features, this switch delivers dependable performance for important IoT deployments and out-of-the-wiring-closet installations.
Key Features of Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch
• 16 Gigabit Ethernet ports with PoE+ support
• 120W PoE+ power budget for connected devices
• 2 SFP uplink ports for flexible connectivity
• Layer 2 switching with advanced management features
• Fanless operation for quiet environments
• 36 Gbps switching bandwidth capacity
• Web-based GUI and CLI management options
• Enhanced network security features
• Zero-touch deployment capability
• Energy-efficient design
• VLAN support for network segmentation
• Quality of Service (QoS) capabilities
• 512MB DRAM and 256MB Flash memory
• Compact form factor (10.56" x 11.69" x 1.73")
• Limited lifetime warranty
Specifications
Specification for Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | New
| Manufacturer | Cisco |
| Manufacturer Part Number | C1000-16P-2G-L |
| Product Name | Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch |
| Product Type | Networking Switch |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 16 x 10/100/1000 (PoE+) + 2 x Gigabit SFP (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 120 W |
| Performance | Forwarding bandwidth: 18 Gbps ¦ Switching bandwidth: 36 Gbps ¦ Forwarding rate (64‑byte L3 packets): 26.78 Mpps |
| Capacity | Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte |
| Jumbo Frame Support | 10240 bytes |
| Routing Protocol | IGMP, MLDv2, MLD, MSTP, RSTP, STP |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS |
| Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), fanless, Shaped Round Robin (SRR), LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, Management Information Base (MIB), Class of Service (CoS), 802.1x authentication, DiffServ Code Point (DSCP) support, IGMP filtering, IP source guard, Weighted Tail Drop (WTD), SmartPort technology, VLAN Trunking Protocol (VTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), proxy ARP, Switched Port Analyzer (SPAN), loopback detection, MAC Access Bypass (MAB), BPDU Guard, Network Edge Access Topology (NEAT) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX |
| Processor | X ARM: 800 MHz |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Status Indicators | Status |
| Interfaces | 16 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-X SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational | 136.92 Watt |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A |
| Width | 10.6 in |
| Depth | 11.7 in |
| Height | 1.7 in |
| Weight | 5.25 lbs |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 90% |
| Min Storage Temperature | -13 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% |
