Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) | New

Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) | New

SKU: 901-R650-WW00-N
(0)No Reviews yet

🗹 Wi-Fi 6 (802.11ax) Technology
🗹 BeamFlex+ Adaptive Antenna Technology
🗹 OFDMA and MU-MIMO Support
🗹 IoT Integration
🗹 2.5GbE Ethernet Port

Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$419.99 $419.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) | New

The Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) is a high-performance networking solution that is ideal for demanding enterprise environments. The R650 takes advantage of cutting-edge Wi-Fi 6 (802.11ax) technology to provide remarkable speed, capacity, and efficiency in high-density environments. This dual-band access point can handle data rates of up to 2974 Mbps thanks to its 4x4:4 antenna array in 5GHz and 2x2:2 in 2.4GHz. The R650 can manage up to 512 client connections with ease, making it excellent for high-traffic office spaces, educational institutions, and retail settings.


Key Features of Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6


• Wi-Fi 6 Technology offers increased capacity and performance in dense environments.

• Dual-Band Operation supports 2.4GHz and 5GHz frequencies simultaneously.

• High-Speed Connectivity delivers up to 2400 Mbps in 5GHz and 574 Mbps in 2.4GHz.

• BeamFlex+ Adaptive Antennas optimizes coverage and mitigates interference.

• 2.5GbE Ethernet Port ensures full utilization of available Wi-Fi capacity.

• OFDMA and MU-MIMO Support enhances network efficiency for multiple clients.

• Built-in IoT Radios includes Bluetooth Low Energy and Zigbee capabilities.

• Enterprise-Grade Security supports WPA3 and flexible authentication options.

• Versatile Management compatible with various Ruckus controller options.

• ChannelFly Technology with dynamic channel selection for improved throughput.

• SmartMesh Support enables extended coverage without additional cabling.

• Compact Design with sleek form factor for unobtrusive ceiling or wall mounting.

• USB 2.0 Port provides additional connectivity options.

• Energy Efficient that optimizes power consumption for cost-effective operation.

• Future-Proof designed to support emerging wireless technologies.

Specifications

Specifications for Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) | New

ManufacturerRuckus
Manufacturer Part Number901-R650-WW00
Product NameRuckus ZoneFlex R650 Wireless Access Point Wi-Fi 6
Product TypeAccess Point
Width
7.6 in
Depth
8.8 in
Height
1.9 in
Weight
30.12 oz
Localization
Worldwide
Form Factor
External
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Network / Transport Protocol
L2TP
Routing Protocol
GRE
Frequency Band
2.4 GHz, 5 GHz
Capacity
Wireless clients: 512 ¦ Maximum number of configured SSIDs: 31
Features
VLAN support, IPv6 support, wall mountable, Wireless Intrusion Detection System (WIDS), Quality of Service (QoS), IPv4 support, Low Density Parity Check (LDPC), Space Time Blocking Code (STBC), ceiling mountable, Wireless Intrusion Prevention System (WIPS), BeamFlex+ Smart Antenna Technology, 4x4 MU-MIMO technology, Smart Roaming, 4x4 SU-MIMO technology, HotSpot 2.0, WMM Power Save, Smart Mesh technology, Transmit Beamforming
Encryption Algorithm
AES, TKIP, WPA2, WPA-PSK, WPA3
Compliant Standards
IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax
Antenna
Internal
Internet of Things (IoT) Compatible
Yes
Communications Technology
Bluetooth Low Energy (LE), Zigbee
Interfaces
1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x USB 2.0 - Type A
Compliant Standards
EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, UL 2043, RoHS, EN 60950-1, WEEE, EN 60601-1-2, EN 62311, EN 50121-4, IEC 61373, EN 50121-1, ISTA 2A
Power Over Ethernet (PoE) Supported
PoE+
Service & Support
Limited warranty - lifetime
Min Operating Temperature
32 °F
Max Operating Temperature
104 °F
Humidity Range Operating
95% (non-condensing)

User Guides

Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00) Data Sheet

Frequently Asked Questions

Ruckus ZoneFlex R650 Wireless Access Point Wi-Fi 6 (901-R650-WW00)
Frequently Asked Questions (FAQ's)



What is the Ruckus ZoneFlex R650 Wireless Access Point?
  • The Ruckus ZoneFlex R650 is a Wi-Fi 6 (802.11ax) wireless access point designed for high-density environments, with advanced features such as BeamFlex+ technology, OFDMA, and MU-MIMO for improved performance and connectivity.
    • What Wi-Fi standards does the Ruckus R650 support?
  • The Ruckus R650 is compatible with the latest Wi-Fi 6 (802.11ax) standard as well as 802.11a/b/g/n/ac.
    • What is the maximum data rate of the Ruckus R650?
  • The Ruckus R650 supports a combined maximum data rate of up to 2.4 Gbps.
    • What is BeamFlex+ technology?
  • BeamFlex+ is Ruckus' adaptive antenna technology, which improves signal quality by dynamically adjusting antenna patterns to avoid interference and increase coverage.
    • What are OFDMA and MU-MIMO?
  • OFDMA (Orthogonal Frequency Division Multiple Access) and MU-MIMO (Multi-User Multiple Input Multiple Output) are technologies that increase network efficiency by allowing multiple devices to communicate at the same time, lowering latency and improving throughput.
    • What is SmartMesh technology?
  • SmartMesh technology facilitates network expansion by allowing access points to communicate wirelessly, eliminating the need for additional cabling and simplifying deployment.
    • How many devices can the Ruckus R650 support simultaneously?
  • The R650's advanced Wi-Fi 6 features allow for a large number of simultaneous connections, but the exact number varies depending on the environment and usage patterns.
    • What management options are available for the Ruckus R650?
  • The Ruckus R650 can be managed using either Ruckus' cloud-based platform or on-premises controllers, providing flexibility in deployment and management.
    • Does the Ruckus R650 support Power over Ethernet (PoE)?
  • Yes, the Ruckus R650 supports 802.3at PoE for a simple and adaptable installation.
    • What are the physical dimensions of the Ruckus R650?
  • The Ruckus R650 measures 197 mm by 197 mm by 48 mm.
    • What is the weight of the Ruckus R650?
  • The Ruckus R650 weighs 0.78kg.
    • How many Ethernet ports does the Ruckus R650 have?
  • The Ruckus R650 contains two Ethernet ports.
    • Can the Ruckus R650 be used outdoors?
  • No, the Ruckus R650 is intended for indoor use. Ruckus offers other models designed specifically for outdoor deployment.
    • What is the warranty period for the Ruckus R650?
  • The warranty period for the Ruckus R650 varies according to region and reseller. For more specific warranty information, contact your local Ruckus distributor or reseller.
    • Is the Ruckus R650 compatible with older Wi-Fi devices?
  • The Ruckus R650 is backward compatible with older Wi-Fi standards, such as 802.11a/b/g/n/ac devices.
    • How is the Ruckus R650 powered if PoE is not available?
  • If PoE is not available, the Ruckus R650 can be powered from a DC power input.
    • What type of environments is the Ruckus R650 suitable for?
  • The Ruckus R650 is best suited for high-density environments like offices, schools, hotels, and public venues.
    • Does the Ruckus R650 support mesh networking?
  • Yes, the Ruckus R650 uses SmartMesh technology to support mesh networking, which allows you to extend coverage without the need for additional wiring.
    • What security features does the Ruckus R650 support?
  • The Ruckus R650 supports advanced security protocols such as WPA3 and WPA2, providing robust network protection.
    • How does the Ruckus R650 handle interference?
  • The Ruckus R650 employs BeamFlex+ adaptive antenna technology, which dynamically adjusts antenna patterns to reduce interference and improve signal quality for dependable connectivity.
