Overview for Fortinet Fortigate 60F Network Security/Firewall Appliance (FG-60F) | New


The FortiGate FG-60F Network Security/Firewall Appliance (FG-60F) from Fortinet delivers comprehensive network protection by integrating a firewall, intrusion prevention, VPN, and other features. With the FG-60F, you can protect your valuable data while also ensuring the integrity of your network.

The Fortinet FortiGate FG-60F provides high-performance security. This appliance provides rapid and efficient protection without affecting network speed thanks to its powerful hardware and improved security features. Because of the FG-60F's versatile and adaptable design, you can scale your security capabilities as your network grows.

The Fortinet FortiGate FG-60F simplifies network security management. Its user-friendly interface and centralized control make it simple to configure, monitor, and manage your security policies and devices. From a single management interface, you can receive extensive visibility into your network and take preemptive measures to fight against emerging threats.


Key Features of Fortinet FortiGate FG-60F Network Security/Firewall Appliance

Next-Generation Firewall (NGFW) Protection

The FortiGate 60F appliance includes next-generation firewall technology, which provides greater security capabilities above and beyond typical firewalls. It combines stateful packet inspection with advanced threat intelligence, application control, and intrusion prevention to detect and prevent threats in real time. This comprehensive security protects your network from emerging dangers and guarantees that only authorized traffic passes through it.

Secure VPN Connectivity

The FortiGate 60F can establish secure Virtual Private Network (VPN) connections, allowing remote and branch office employees to safely access network resources. The equipment supports industry-standard VPN protocols and encryption methods, assuring the secrecy and integrity of data exchanged through VPN tunnels. This capability is critical for enterprises with a remote workforce or various office locations, as it provides a secure and smooth connectivity across different areas of the network.

Advanced Threat Protection

The FortiGate 60F incorporates powerful threat protection capabilities to guard against sophisticated cyber threats. It employs advanced threat intelligence services, sandboxing, and antivirus technologies to detect and prevent known and unknown malware, ransomware, and other dangerous behaviors. With real-time threat updates and continuous monitoring, the appliance detects and mitigates attacks before they can infiltrate your network, reducing the risk of data breaches and operational disruptions.

Hardware Acceleration

The FortiGate 60F, which includes hardware acceleration technology, provides high-performance network security without sacrificing speed or latency. Its purpose-built security processing units offload resource-intensive security activities, allowing the appliance to handle high network traffic while still performing well. This ensures that your network activities run smoothly and continuously, especially during peak demand times.

Scalability and Flexibility

The FortiGate 60F is designed to adapt to your network's changing requirements. It provides scalable performance and can scale to meet increasing network demands as your company grows. The appliance provides a variety of deployment choices, including standalone, distributed, and virtualized settings, allowing for greater network architectural and administration flexibility. Because of its scalability and versatility, the FortiGate 60F is a long-term investment that can grow with your network.

Centralized Security Management

The Fortinet FortiGate 60F may be administered centrally using the Fortinet Security Fabric, which offers a consistent interface for configuring, monitoring, and reporting numerous Fortinet devices. This unified management makes network security administration easier by allowing IT managers to administer security rules, monitor network activity, and respond to security issues from a single dashboard. This improves visibility, streamlines operations, and improves overall network security posture.

Real-time Monitoring and Reporting

The appliance provides real-time monitoring and reporting capabilities, revealing useful information about network traffic, security events, and system performance. It creates extensive reports and logs that let administrators to monitor network behavior, identify potential risks, and make sound security decisions. Real-time alerts and notifications improve proactive threat response by allowing IT teams to respond to security problems quickly and effectively.

Fortinet FortiGate FG-60F Network Security/Firewall Appliance Frequently Asked Questions (FAQs)

**Q: Can the Fortinet FortiGate 60F appliance be deployed in a cloud environment?

A: Yes, cloud deployments are supported with the Fortinet FortiGate 60F equipment. It integrates smoothly into cloud infrastructures, allowing you to extend network security to the cloud. This ensures that your security rules and threat prevention are consistent throughout both on-premises and cloud settings.

Q: Does the FortiGate 60F appliance provide web filtering capabilities?

A: Yes, the FortiGate 60F device has web filtering capabilities. It includes web filtering capabilities that enable you to manage and monitor web access based on categories, URLs, and user profiles. By implementing approved internet usage regulations, this helps businesses limit access to malicious websites and unsuitable content while also increasing productivity.

Q: Can the FortiGate 60F appliance be integrated with other security systems and tools?

A: Absolutely! Through APIs, the FortiGate 60F appliance may be integrated with various security systems and tools, as well as interoperable with third-party solutions. This allows for easy collaboration among various security components and improves the overall effectiveness of your network security infrastructure.

Q: Does the FortiGate 60F appliance provide secure Wi-Fi connectivity?

A: Although the FortiGate 60F appliance does not support Wi-Fi, it can be used in conjunction with Fortinet access points or other Wi-Fi solutions to enable secure Wi-Fi connectivity. You may extend the FortiGate 60F's security features to your wireless network by pairing it with compatible wireless access points, ensuring a comprehensive and unified security posture.

Q: What kind of support and maintenance options are available for the FortiGate 60F appliance?

A: Fortinet provides comprehensive support and maintenance options for the FortiGate 60F equipment. These alternatives include technical support, software upgrades, and hardware replacement services. You can select the level of service that best meets your requirements, assuring the continuing reliability and optimal performance of your network security architecture.


Specification for Fortinet Fortigate 60F Network Security/Firewall Appliance (FG-60F) | New


Manufacturer Part NumberFG-60F
Product NameFortinet Fortigate 60F Network Security/Firewall Appliance
Product TypeWiFi
GE RJ45 WAN / DMZ Ports2/1
GE RJ45 Internal Ports5
GE RJ45 FortiLink Ports (Default)2
USB Ports1
Console (RJ45)1
IPS Throughput21.4 Gbps
NGFW Throughput2, 41 Gbps
Threat Protection Throughput2, 5700 Mbps
Firewall Throughput (1518 / 512 / 64 byte UDP packets)10/10/6 Gbps
Firewall Latency (64 byte UDP packets)3.3 μs
Firewall Throughput (Packets Per Second)9 Mpps
Concurrent Sessions (TCP)700000
New Sessions/Second (TCP)35000
Firewall Policies5000
IPsec VPN Throughput (512 byte)16.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels200
Client-to-Gateway IPsec VPN Tunnels500
SSL-VPN Throughput900 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)200
SSL Inspection Throughput (IPS, avg. HTTPS)3630 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)3400
SSL Inspection Concurrent Session (IPS, avg. HTTPS)355000
Application Control Throughput (HTTP 64K)21.8 Gbps
CAPWAP Throughput (HTTP 64K)8 Gbps
Virtual Domains (Default / Maximum)45209
Maximum Number of FortiSwitches Supported16
Maximum Number of FortiAPs (Total / Tunnel Mode)64 / 32
Maximum Number of FortiTokens500
High Availability ConfigurationsActive-Active, Active-Passive, Clustering
Height x Width x Length (inches)1.5 x 8.5 x 6.3
Height x Width x Length (mm)38.5 x 216 x 160 mm
Weight2.23 lbs (1.01 kg)
Form FactorDesktop
Multiple User (MU) MIMO3x3
Maximum Wi-Fi Speeds1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz
Maximum Tx Power20 dBm
Antenna Gain3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz
Power Rating12Vdc, 3A
Power RequiredPowered by External DC Power Adapter, 100–240V AC, 50/60 Hz
Maximum Current100Vac/1.0A, 240Vac/0.6A
Power Consumption (Average / Maximum)10.17 W / 12.43 W
Heat Dissipation63.1 BTU/hr
Operating Temperature32–104°F (0–40°C)
Storage Temperature-31–158°F (-35–70°C)
Humidity10–90% non-condensing
Noise LevelFanless 0 dBA
Operating AltitudeUp to 7,400 ft (2,250 m)
CertificationsICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
