Overview of Fortinet FortiAP 431F Indoor Wireless Access Point (FAP-431F-A) | New
The Fortinet FortiAP 431F Indoor Wireless Access Point (FAP-431F-A) is a cutting-edge indoor wireless access point engineered to deliver exceptional performance and security to modern enterprise networks. The FortiAP 431F, which uses cutting-edge Wi-Fi 6 technology, is ideal for businesses that require dependable, high-speed connectivity in densely populated areas. The FortiAP 431F has a tri-radio design and 4x4 MU-MIMO capabilities, which allows it to handle multiple simultaneous connections efficiently. It can operate on both the 2.4 GHz and 5 GHz bands, with a maximum throughput of 2.4 Gbps on the 5 GHz band and 1.1 Gbps on the 2.4 GHz band. This provides seamless connectivity for a wide range of devices, including smartphones and laptop computers, making it ideal for busy offices, schools, and retail settings.
The FortiAP 431F supports Power over Ethernet (PoE), which simplifies installation by eliminating the need for separate power sources. It has two Ethernet ports, one 2.5 GE RJ45 and one GE RJ45. It also includes Bluetooth Low Energy (BLE) capabilities for location-based services and beacons, which increase user engagement and operational efficiency. With the FortiAP 431F, security is top priority, and it integrates seamlessly with Fortinet's security fabric. This enables centralized management via FortiGate appliances or the FortiAP Cloud, giving complete visibility and control over both wired and wireless networks. To protect against evolving threats, the access point includes advanced security features such as integrated firewall capabilities, intrusion prevention systems (IPS), and application control. The Fortinet FortiAP 431F is an excellent choice for businesses looking to improve their wireless network with high-performance capabilities and strong security. Its combination of advanced technology, simplicity of management, and dependability makes it an excellent choice for modern business environments.
Key Features of Fortinet FortiAP 431F Indoor Wireless Access Point
• Wi-Fi 6 technology delivers faster speeds and improved efficiency for multiple connected devices.
• Tri-Radio design supports simultaneous connections on both 2.4 GHz and 5 GHz bands.
• High throughput is up to 2.4 Gbps on the 5 GHz band and 1.1 Gbps on the 2.4 GHz band.
• Dual ethernet ports includes one 2.5 GE RJ45 port and one GE RJ45 port for flexible connectivity.
• Power over Ethernet (PoE) simplifies installation by eliminating separate power requirements.
• Bluetooth Low Energy (BLE) enables location-based services and beacons for enhanced user experiences.
• Centralized management through FortiGate appliances or FortiAP Cloud.
Specifications
Specifications for Fortinet FortiAP 431F Indoor Wireless Access Point (FAP-431F-A) | New
Manufacturer | Fortinet |
Manufacturer Part Number | FAP-431F-A |
Product Name | Fortinet FortiAP 431F Indoor Wireless Access Point |
Product Type | Wireless Access Point |
Ruggedized Design | Indoor |
Width | 8.3 in |
Depth | 8.3 in |
Height | 2.2 in |
Weight | 34.56 oz |
Localization | Americas |
Form Factor | External |
Connectivity Technology | Wireless |
Line Coding Format | 64 QAM, 256 QAM, BPSK, QPSK, 1024 QAM, OFDMA |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, 802.11ax |
Spread Spectrum Method | OFDMA |
Frequency Band | 2.4 GHz (1 band) / 5 GHz (2 bands) |
Capacity | Maximum number of configured SSIDs: 16 |
Status Indicators | Status |
Features | Firewall protection, DFS support, surge protection, wall mountable, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), 802.1x authentication, iBeacon technology, MU-MIMO technology, T-Rail mountable, spectrum analyzer, Packet Sniffer Mode, security slot (Kensington security lock compatible), Bluetooth (BLE) clients support, Target Wait Time (TWT) |
Encryption Algorithm | TLS, PEAP, TTLS, WPA, WPA2, WEP, EAP-AKA, WPA3, EAP-FAST |
Authentication Method | MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA, EAP-GTC, EAP-TLS, EAP-TTLS |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11j, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ac Wave 2, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
Antenna | Internal |
Interfaces | 1 x 1/2.5GBase-T (PoE+) - RJ-45 ¦ 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x management (RS-232) - RJ-45 ¦ 1 x USB - Type A |
Included Accessories | Wall mounting kit, T-Rail mounting kit |
MTBF | 10 years |
Compliant Standards | RoHS |
Power Over Ethernet (PoE) Supported | PoE+ |
Power Consumption Operational | 24.5 Watt |
Service & Support | Limited warranty - lifetime |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 113 °F |
Humidity Range Operating | 5 - 90% (non-condensing) |
