Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports | New
SKU: C1111-8P-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports | New
The Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports is a high-performance networking solution designed for small and medium-sized businesses, branch offices and teleworker environments. Combining advanced security, reliable connectivity and simplified management, this router is ideal for modern network demands. The C1111-8P provides remarkable performance and scalability for expanding businesses, with its powerful hardware and the feature-rich Cisco IOS XE software. Equipped with eight Gigabit Ethernet LAN ports, the Cisco C1111-8P provides high-speed local connectivity, while its two WAN ports (one RJ-45 and one combo RJ-45/SFP) offer flexible internet access options. It features Power over Ethernet (PoE) support on four ports, enabling direct power supply to devices such as IP phones and cameras. With advanced security features like a stateful inspection firewall, VPN support and intrusion prevention, a secure network environment is guaranteed. Additionally, the router offers support for SD-WAN to enhance WAN connections and for cloud-based management to simplify operations. Due to its compact design and lack of fans, it is ideal for environments where space is limited.
Key Features of Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports
• Eight Gigabit Ethernet LAN Ports with high-speed connectivity for multiple devices within the network.
• Dual WAN Ports includes one RJ-45 and one combo RJ-45/SFP port for flexible internet access.
• Power over Ethernet (PoE) with four PoE ports (two PoE+) to power connected devices like IP phones or cameras.
• Cisco IOS XE Software provides advanced routing, security and network management capabilities.
• Advanced Security Features includes stateful inspection firewall, VPN support (IPsec, DMVPN) and intrusion prevention.
• SD-WAN Ready optimizes WAN performance with software-defined networking capabilities.
• Energy Efficiency supports Energy Efficient Ethernet (EEE) to reduce power consumption.
• Cloud-Based Management simplifies configuration and monitoring through Cisco Meraki or other platforms.
• Compact Fanless Design with quiet operation suitable for noise-sensitive environments.
• Up to 250 Mbps encrypted throughput with support for bandwidth-intensive tasks.
Benefits of Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports
🗹 Dual WAN ports ensure uninterrupted internet access with failover and load balancing.
🗹 Protects sensitive data with advanced firewall capabilities and secure VPN connections.
🗹 Eight Gigabit LAN ports provide flexibility to accommodate growing network demands.
🗹 Powers devices directly through the network cable, reducing the need for additional power supplies.
🗹 Cisco IOS XE Software offers intuitive tools for configuration and monitoring.
🗹 SD-WAN readiness ensures compatibility with evolving networking requirements.
🗹 Fanless design is perfect for offices or other space-constrained environments.
🗹 Reduces operational costs while maintaining high performance levels.
🗹 Ideal for branch offices, small businesses, teleworkers and distributed networks.
🗹 Backed by Cisco’s reputation for reliability and innovation in networking solutions.
Specifications
Specifications for Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports | New
| Manufacturer | Cisco |
| Manufacturer Part Number | C1111-8P |
| Product Name | Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports |
| Product Type | Router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Encryption throughput: 250 Mbps |
| Network / Transport Protocol | IPSec, PPPoE, DHCP, DNS, L2TPv3 |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP |
| Remote Management Protocol | SNMP, RMON, CLI, TR-069 |
| Encryption Algorithm | DES, Triple DES, SHA, MD5, IKE, ECDSA, 128-bit AES, 256-bit AES, 1024-bit RSA, 2048-bit RSA, 256-bit SHA, 512-bit SHA, 748-bit RSA, 384-bit SHA |
| Authentication Method | RADIUS |
| Features | Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), 2T2R MIMO technology, NetFlow, Maximum Ratio Combining (MRC), PoE-upgradable ports, IPFIX, cyclic shift diversity (CSD), Location ID Separation Protocol (LISP), packet aggregation A-MPDU, packet aggregation A-MSDU, Management Information Base (MIB) II, Application Visibility and Control (AVC), Authentication, Authorization and Accounting (AAA), Dynamic Frequency Selection (DFS), Encapsulated Remote SPAN (ERSPAN), Embedded Event Manager (EEM) |
| Compliant Standards | IEEE 802.3af, IEEE 802.11i, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at, IEEE 802.11r, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, UL 60950-1 Second Edition, VCCI V-3, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS CISPR 22, CNS 13438, EN 301 489-7, EN 301 489-1, FCC CFR47 Part 22, FCC CFR47 Part 24, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, EN 301 489-24, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13 |
| RAM | 4 GB |
| Flash Memory | 4 GB |
| Status Indicators | Status |
| Interfaces | WAN / LAN: 1 x 1000Base-T/1000Base-X - RJ-45/SFP ¦ WAN: 1 x 1000Base-T - RJ-45 ¦ LAN: 2 x 1000Base-T - RJ-45 ¦ LAN: 2 x 1000Base-T - RJ-45 ¦ LAN: 4 x 1000Base-T - RJ-45 ¦ USB 3.0: 1 x console |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational | 66 Watt |
| OS Provided | Cisco IOS XE Universal |
| Width | 32.3 cm |
| Depth | 23 cm |
| Height | 4.2 cm |
| Weight | 2.59 kg |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 65 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
User Guides
Frequently Asked Questions
Cisco C1111-8P Integrated Services Router with 8 Gigabit Ethernet Ports
Frequently Asked Questions (FAQ's)
What are the basic specifications of the C1111-8P?
How do I perform the initial setup of the C1111-8P?
How do I access the web GUI?
What IOS XE version is recommended?
How many PoE ports does it have?
What is the maximum throughput?
How do I configure DHCP on the router?
How do I set up NAT?
How do I upgrade the IOS?
Can it function as a wireless access point?
How do I configure VLANs?
What VPN types does it support?
How do I troubleshoot connectivity issues?
What is the power consumption?
Does it support dual WAN for redundancy?
How do I configure QoS?
How do I configure port forwarding on the C1111-8P?
Does the C1111-8P support IPv6?
How do I configure a DHCP relay?
What is the maximum number of ACLs supported?
