Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router (NA) | Refresh

Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router (NA) | Refresh

SKU: RV345-K9-NA-RF
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$199.99 $199.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview for Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router (NA) | Refresh

The Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router is a strong, business-class router designed for small and medium-sized businesses looking for dependable remote access, strong security and fast connectivity. This router, which has 16 Gigabit Ethernet LAN ports and two Gigabit WAN ports, offers outstanding performance and sophisticated load balancing and failover capabilities, guaranteeing continuous internet access for crucial processes. The RV345 is perfect for today's distributed and hybrid work situations since it has a strong VPN server that supports up to 50 IPsec and 50 SSL VPN tunnels, allowing employees and branch offices to have secure remote access. A stateful packet inspection (SPI) firewall, dynamic web filtering, application and endpoint identification, and support for VLANs, NAT and complex routing protocols are all part of the RV345's enterprise-grade security. The demands of high-traffic commercial networks are met by its dual-core processor, 1GB RAM and 256MB flash memory, which enable up to 900 Mbps firewall throughput and 650 Mbps VPN throughput. This router is both flexible and future-ready thanks to its user-friendly web-based control, cloud monitoring using Cisco FindIT and USB ports for file sharing or 3G/4G failover.


Key Features of Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router


• 16 x Gigabit Ethernet LAN Ports with high-speed wired connectivity for workstations, servers and network devices.

• 2 x Gigabit Ethernet WAN Ports with Dual WAN for load balancing and automatic failover, maximizing uptime.

• Robust VPN Support with up to 50 IPsec and 50 SSL VPN tunnels for secure remote access.

• High Firewall & VPN Throughput with up to 900 Mbps firewall and 650 Mbps VPN throughput for demanding networks.

• Enterprise-Grade Security with stateful packet inspection (SPI) firewall, dynamic web filtering, application and endpoint identification and DoS protection.

• Comprehensive Routing & Protocols that supports IPv4/IPv6, RIP v1/v2, RIPng, static routing, inter-VLAN routing, NAT, PAT and DMZ.

• Quality of Service (QoS) that prioritizes critical applications for optimal performance.

• USB Ports with two USB ports for 3G/4G failover or file sharing.

• Easy Management with intuitive web-based interface, SNMP and optional Cisco FindIT Network Manager for remote/cloud management.

• Rack-Mountable Design with compact, durable enclosure with included rack-mount kit.

• IPv6 Ready & Future-Proof with full IPv6 support ensures long-term compatibility.

• Energy Efficient with low power consumption and fanless operation for quiet environments.


Benefits of Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router


🗹 Dual WAN ports with load balancing and failover keep your business online, even if one ISP fails.

🗹 Robust VPN capabilities enable secure, reliable access for remote employees and branch offices.

🗹 Advanced security features safeguard sensitive data and block threats before they reach your network.

🗹 User-friendly web interface and cloud-based tools reduce IT workload and speed up troubleshooting.

🗹 Sixteen Gigabit LAN ports and VLAN support make it easy to expand your network as your business grows.

🗹 QoS and advanced routing ensure smooth VoIP, video and cloud app experiences.

🗹 USB failover and robust hardware design minimize interruptions and keep you connected.

🗹 IPv6 support and Cisco’s renowned reliability ensure your network is ready for tomorrow’s demands.

Specifications

Specifications for Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router (NA) | Refresh

ManufacturerCisco
Manufacturer Part NumberRV345-K9-NA-RF
Product NameCisco RV345-K9 16-Port Dual WAN Gigabit VPN Router
Product TypeRouter
Enclosure Type
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Firewall throughput (TCP): 900 Mbps ¦ VPN throughput (IPSec): 650 Mbps ¦ VPN throughput (PPTP): 100 Mbps
Capacity
IPSec VPN connections: 50 ¦ PPTP VPN connections: 25 ¦ VLANs supported: 32
Network / Transport Protocol
TCP/IP, PPTP, UDP/IP, L2TP, IPSec, PPPoE, DHCP
Routing Protocol
RIP-1, RIP-2, IGMP, static IP routing, GRE, RIPng
Remote Management Protocol
SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS
Features
NAT support, VPN support, PAT support, ALG support, IPv6 support, VPN passthrough, firmware upgradable, Quality of Service (QoS), IPSec passthrough, static IP mode, port forwarding, Port Security, 3G/4G USB Dongle Support, DHCP client, static routing, IGMP proxy, 802.1x authentication, PPTP passthrough, L2TP passthrough, Web Filtering
Compliant Standards
IEEE 802.1x, FCC Class A certified, UL, BSMI, cUL, CB, CCC, ANATEL, KC
RAM
1 GB
Flash Memory
256 MB
Status Indicators
Status
VoIP Protocols
SIP
Interfaces
LAN: 16 x 1000Base-T - RJ-45 ¦ WAN: 2 x 1000Base-T - RJ-45 ¦ USB: 2 x 4 pin USB Type A ¦ Console: 1 x RJ-45
Cables Included
1 x network cable
Rack Mounting Kit
Included
Localization
Canada, Mexico, United States
Width
11 in
Depth
1.7 in
Height
6.7 in
Weight
2.51 lbs
Service & Support
Limited warranty - lifetime
Min Operating Temperature
32 °F
Max Operating Temperature
104 °F
Humidity Range Operating
10 - 85% (non-condensing)

User Guides

Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router Data Sheet

Frequently Asked Questions

Cisco RV345-K9 16-Port Dual WAN Gigabit VPN Router
Frequently Asked Questions (FAQ's)



What are the key features of the Cisco RV345 16-Port Gigabit Router?
  • The Cisco RV345 16-Port Gigabit Router features dual WAN ports, a business-class firewall, and a variety of VPN options. It also has built-in Wi-Fi-5, a 16-port LAN switch, and PoE LAN ports available in model variations.
    • How many LAN ports does the Cisco RV345 16-Port Gigabit Router have?
  • The Cisco RV345 16-Port Gigabit Router features 16 LAN ports.
    • Does the Cisco RV345 16-Port Gigabit Router support PoE?
  • The Cisco RV345 16-Port Gigabit Router does not include PoE support. However, there are model variants that have PoE LAN ports.
    • What is the warranty for the Cisco RV345 16-Port Gigabit Router?
  • The Cisco RV345 16-Port Gigabit Router includes a limited lifetime warranty.
    • Does the Cisco RV345 16-Port Gigabit Router support dual WAN?
  • Yes, the Cisco RV345 16-Port Gigabit Router can support dual WAN ports.
    • Can the Cisco RV345 16-Port Gigabit Router be used for VPN connections?
  • Yes, the Cisco RV345 16-Port Gigabit Router provides flexible VPN options.
    • What is the power budget for the PoE ports on the Cisco RV345 16-Port Gigabit Router?
  • The Cisco RV345 16-Port Gigabit Router lacks built-in PoE support. However, there are model variants that include PoE LAN ports. The RV345P model has 8 ports that support 802.3af and 802.3at PoE, with a total power budget of 120W.
    • Is there a configuration guide available for the Cisco RV345 16-Port Gigabit Router?
  • Yes, configuration guides, examples, and technologies for the Cisco RV340x Series (including the RV345) are available on the Cisco website at: https://www.cisco.com/c/en/us/support/routers/rv340-dual-gigabit-wan-vpn-router/model.html#~tab-documents
    • What are the available USB ports on the Cisco RV345 16-Port Gigabit Router used for?
  • The Cisco RV345 16-Port Gigabit Router includes two USB ports that can be used to connect a 3G/4G modem or flash drive.
    • Does the Cisco RV345 16-Port Gigabit Router have a built-in firewall?
  • Yes, the Cisco RV345 16-Port Gigabit Router features a business-class firewall.
    • Does the Cisco RV345 16-Port Gigabit Router support Cisco Anyconnect VPN?
  • Yes, the Cisco RV345 16-Port Gigabit Router does support Cisco Anyconnect VPN.
    • Can the Cisco RV345 16-Port Gigabit Router limit Internet surfing to specific site categories?
  • Yes, the Cisco RV345 16-Port Gigabit Router can limit Internet surfing to appropriate site categories, thereby increasing employee productivity and overall network performance.
    • Does the Cisco RV345 16-Port Gigabit Router have status lights?
  • Yes, the Cisco RV345 16-Port Gigabit Router has status lights, but the exact placement may vary depending on the model.
    • Can the Cisco RV345 16-Port Gigabit Router be used for small businesses?
  • Yes, the Cisco RV345 16-Port Gigabit Router is designed to connect small businesses to the Internet and protect employees from unwanted content and malicious websites while maintaining the online experience.
    • Is the Cisco RV345 suitable for my small business?
  • Yes, it's ideal for SMBs that need secure and dependable network connectivity.
    • Does the RV345 support VPN connections?
  • Yes, it includes VPN functionality to ensure secure remote access.
    • Does the RV345 offer dual WAN functionality?
  • Yes, it has dual Gigabit WAN ports to ensure redundancy and load balancing.
    • What security features are included in the RV345 router?
  • It includes a built-in firewall to protect your network from cyber threats.
    • How do I configure the Cisco RV345 router?
  • The RV345 has a simple web interface that allows for easy configuration.
    • What type of internet connection does the RV345 support?
  • It supports a variety of wired internet connection types that work with Gigabit Ethernet ports.
