Overview of Cisco Meraki MS350 48-Port Cloud Managed Network Switch (MS350-48FP-HW)| Like New
The Cisco Meraki MS350 48-Port Cloud Managed Network Switch (MS350-48FP-HW) is a robust and adaptable solution built to suit the needs of today's enterprise networks. This switch's sophisticated features and cloud-managed capabilities enable seamless connectivity, robust performance, and simpler management, making it perfect for big campuses and mission-critical situations. The MS350-48FP-HW has 48 Gigabit Ethernet ports with PoE+ capability, which can deliver up to 740W of power to connected devices. This feature is required for powering IP phones, wireless access points, and other PoE devices without the use of external power sources. The switch also contains 4 x 10G SFP+ uplink ports, which allow for high-speed connections to other network devices and faster data transfer rates. The MS350 is designed with a non-blocking switch fabric and has a switching capability of 176 Gbps, ensuring uninterrupted data delivery. Its Layer 3 routing capabilities include advanced technologies like OSPF and VRRP, making it ideal for complicated network topologies.
The Meraki MS350 series' cloud-managed architecture is one of its most distinguishing features. This enables centralized control through an intuitive web interface, allowing IT personnel to monitor and customize the network from any location. The switch features zero-touch provisioning, which simplifies deployment by automatically configuring devices when they connect. The MS350-48FP-HW also includes advanced security capabilities such integrated Layer 7 application visibility and quality of service (QoS) controls. These features ensure that key apps have adequate bandwidth while also providing information about network performance. The Cisco Meraki MS350 is a good alternative for enterprises wishing to improve their network infrastructure by providing dependable performance, advanced management capabilities, and solid security features.
Key Features of Cisco Meraki MS350 48-Port Cloud Managed Network Switch
• 48 Gigabit Ethernet Ports: Supports PoE+ with up to 740W total power budget for connected devices.
• 4 x 10G SFP+ Uplinks: High-speed uplink options for seamless integration with other network components.
• Non-Blocking Switch Fabric: Provides a switching capacity of 176 Gbps for efficient data transmission.
• Layer 3 Routing Capabilities: Advanced routing features including OSPF and VRRP for complex network setups.
• Cloud Management: Centralized control via a web-based dashboard for easy monitoring and configuration.
• Zero-Touch Provisioning: Simplifies deployment by automatically configuring devices upon connection.
• Advanced Security Features: Layer 7 application visibility and QoS settings to prioritize critical applications.
Specifications
Specifications for Cisco Meraki MS350 48-Port Cloud Managed Network Switch (MS350-48FP-HW) | Like New
| Manufacturer | Cisco |
| Manufacturer Part Number | MS350-48FP-HW |
| Product Name | Cisco Meraki MS350 48-Port Cloud Managed Network Switch |
| Product Type | Networking Switch |
Enclosure Type | Desktop, rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 740 W |
Performance | Non-blocking switching capacity: 176 Gbps |
Capacity | Forwarding table entries: 96000 ¦ Tagged VLANs: 4096 |
Jumbo Frame Support | 9600 bytes |
Routing Protocol | OSPFv2, static IP routing |
Remote Management Protocol | SNMP 2c |
Authentication Method | RADIUS |
Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, E-mail alert, Broadcast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), SMS alert, LLDP support, DHCP client, tagged VLAN, crossover detection |
Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at |
Interfaces | 48 x 1000Base-T RJ-45 PoE+ - 25.5 W ¦ 4 x 10Gbit LAN SFP+ uplink |
Power Device | Internal power supply - hot-plug |
Installed Qty | 1 |
Max Supported Qty | 2 |
Power Redundancy | Optional |
Power Redundancy Scheme | 1+1 (with optional power supply) |
Power Provided | 1025 Watt |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 885 Watt |
Rack Mounting Kit | Included |
MTBF | 516,000 hours |
Compliant Standards | CSA, C-Tick, IC, RoHS |
Width | 19.1 in |
Depth | 21.8 in |
Height | 1.7 in |
Weight | 14.99 lbs |
Service & Support | Limited warranty - replacement - lifetime - response time: next day |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 113 °F |
Humidity Range Operating | 5 - 95% (non-condensing) |
User Guides
Frequently Asked Questions
Cisco Meraki MS350 48-Port Cloud Managed Network Switch (MS350-48FP-HW)
Frequently Asked Questions (FAQ's)
What is the maximum PoE power budget of the Cisco Meraki MS350-48FP-HW?The MS350-48FP-HW has a maximum PoE budget of 740W, so it can power a variety of devices like IP phones, cameras, and access points.
Does the Cisco Meraki MS350-48FP-HW support Layer 3 functionality?Yes, the MS350-48FP supports advanced Layer 3 routing, such as static routing, OSPF, and multicast routing.
How many SFP+ uplink ports are available on the MS350-48FP?The MS350-48FP has four SFP+ ports that handle 1G and 10G connections for uplinks and stacking.
Is the Cisco Meraki MS350-48FP-HW managed through the cloud?Yes, the MS350-48FP is a cloud-managed switch that can be completely configured and monitored from the Meraki dashboard.
Does the MS350-48FP-HW support stacking?Yes, the switch allows physical stacking of up to eight switches, with a total stacking bandwidth of 160Gbps.
Does the MS350-48FP-HW come with built-in DHCP functionality?Yes, the MS350-48FP can be used as a DHCP server for network devices.
Can I configure VLANs on the Cisco Meraki MS350-48FP?Yes, the switch supports VLAN configuration via the Meraki dashboard, which enables network segmentation and isolation.
Does the Cisco Meraki MS350-48FP-HW have redundant power supply options?Yes, it offers two, hot-swappable power sources for added redundancy and reliability.
How many devices can the MS350-48FP power simultaneously via PoE?It can power up to 48 PoE devices, depending on their individual power requirements and the overall power budget.
Can the MS350-48FP be monitored remotely?Yes, all Cisco Meraki devices, including the MS350-48FP, may be remotely monitored and managed using the Meraki dashboard.
What is the power consumption of the Cisco Meraki MS350-48FP-HW?The switch's maximum power consumption is 1080W, including PoE.
Is the MS350-48FP suitable for high-density environments?Yes, with 48 Gigabit Ethernet ports and a generous PoE budget, it is perfect for high-density settings like offices, colleges, and retail stores.
Does the MS350-48FP support Quality of Service (QoS)?Yes, it supports QoS, which enables traffic prioritizing for VoIP, video, and other key applications.
Is there a fan in the Cisco Meraki MS350-48FP-HW?Yes, the MS350-48FP includes fans to keep operating temperatures stable, especially in high-load circumstances.
Does the Cisco Meraki MS350-48FP offer security features like 802.1X?Yes, the switch supports advanced security features including 802.1X authentication, DHCP snooping, and access control lists (ACLs).
Can I schedule firmware updates for the MS350-48FP?Yes, firmware updates may be scheduled and performed via the Meraki dashboard without requiring manual interaction.
Does the MS350-48FP-HW support multicast traffic?Yes, it supports IGMP snooping and Layer 3 multicast routing to handle multicast traffic more efficiently.
What cabling is required for stacking the MS350-48FP?The switches employ Meraki's proprietary stacking connections to link up to eight switches in a stack.
Does the Cisco Meraki MS350-48FP-HW have a web GUI for local management?No, the MS350-48FP is only administered via the cloud-based Meraki dashboard and does not include a local GUI.
What are the mounting options for the Cisco Meraki MS350-48FP-HW?The switch can be rack-mounted with the accompanying rack-mounting kit.
