Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch (MS350-24X-HW) | Like New

Overview of Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch (MS350-24X-HW) | Like New

The Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch (MS350-24X-HW) is specifically designed for campus and enterprise settings that require next-generation networking performance, unparalleled dependability and ease of cloud management. High-bandwidth users and wireless uplinks can enjoy lightning-fast connectivity due to this switch's hybrid mix of 16 ordinary gigabit and 8 multigigabit UPoE-ready ports. Mission-critical robustness and smooth scalability are guaranteed by four integrated 10G SFP+ uplinks, physical stacking and hot-swappable, redundant power supplies. To secure and speed up contemporary networks, the user-friendly Meraki Dashboard offers granular visibility, zero-touch provisioning, sophisticated Layer 3 capabilities and strong security controls. In a small 1U rackmount chassis, the MS350-24X offers non-blocking throughput, high PoE power and a wide range of cloud functions, making it perfect for high-density deployments.

Key Features of Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch

• 24 Ethernet Ports Total with 16 x 10/100/1000BASE-T RJ45, 8 x 100M/1G/2.5G/5G/10G RJ45 multigigabit with UPoE.

• 4 x SFP+ 10G Uplink Ports with non-shared dedicated uplinks for backbone, fiber and aggregation.

• Physical Stacking with dual 40G stack ports, 160 Gbps bandwidth for enterprise-grade resilience and scalability.

• Hot-Swappable Power & Fans with dual redundant power supplies, field-replaceable fans; maximum PoE output up to 740W.

• Cloud Managed with Meraki Dashboard centralizes configuration, monitoring, security, diagnostics and multi-site management.

• Layer 3 Routing & Services with static and dynamic routing (OSPFv2), multicast (PIM-ASM), DHCP server/relay, VRRP warm spare.

• UPoE & Intelligent Power Allocation with PoE+, UPoE (60W/port), 802.3at/af support, intelligent LLDP-based device power management.

• Non-Blocking Fabric / High Performance with 272 Gbps switching, 202.38 mpps forwarding rate, 9600 byte jumbo frame support.

• Environment & Size with operating temp: -5°C to 50°C; 1U rackmount; 1.74” x 19.08” x 23.4”; weight: 14.48 lb (6.6 kg).

• Security & Compliance with role-based access, port-security, cloud authentication, regulatory certifications: CSA-US, FCC, IC, CE, RoHS.

Benefits of Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch

🗹 Fast, Reliable Networking with high-performance multigigabit and 10G uplinks empower fast devices and wireless access points with non-blocking throughput.

🗹 Effortless Cloud Management that streamlined, unified and remote Meraki Dashboard configuration saves IT time and simplifies troubleshooting.

🗹 Enterprise-Grade Resilience with dual redundant power supplies, stacking and hot-swappable architecture maximize uptime in demanding environments.

🗹 Future-Ready Connectivity with UPoE, multigigabit, jumbo frame and advanced Layer 3 features support growing campus, office, and wireless needs.

🗹 Secure, Compliant Deployments with built-in security controls help defend network assets and ensure compliance with global standards.

Specifications for Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch (MS350-24X-HW) | Like New

Cisco Meraki MS350 Cloud Managed 24-Port Gigabit Ethernet Switch (MS350-24X-HW)
