Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch | New

Overview of Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch | New

The Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch is a Layer 3 managed switch of enterprise quality designed for scalable, secure, and high-performance network deployments. With 16 regular 10/100/1000 PoE+ ports and 8 multigigabit (100/1000/2.5G/5G/10GBase-T) PoE+ ports, this switch is ideal for Wi-Fi 6/6E access points, high-density device scenarios, and branch or campus networks with high bandwidth requirements. It streamlines installation and lowers infrastructure costs by delivering data and power to connected devices—like wireless access points, IP phones, and security cameras—through a single cable due to its powerful 370W PoE+ power budget. With a forwarding rate of 261.90 Mpps and a large switching capacity of 352 Gbps, the C9200-24PXG-A ensures non-blocking, wire-speed performance for mission-critical applications. Segmentation, encryption (AES-128 MACsec) and support for Cisco SD-Access are examples of advanced security features that shield your network from ever changing threats. With StackWise-160 technology, modular uplinks, hot-swappable fans and power supplies and cold patching for continuous operation, the switch offers full-stack redundancy. With its extensive Layer 3 routing protocols (OSPF, EIGRP, VRRP, RIP and PIM), flexible NetFlow and superior QoS, the C9200-24PXG-A gives IT teams granular network visibility, control and automation.

Key Features of Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch

• 24-Port Configuration with 8 x 100/1000/2.5G/5G/10G multigigabit PoE+ ports and 16 x 10/100/1000 PoE+ ports for flexible, high-speed device connectivity.

• 370W PoE+ Power Budget delivers up to 30W per port, ideal for powering Wi-Fi 6/6E APs, IP phones and IoT devices.

• 352 Gbps Switching Capacity ensures high throughput and non-blocking performance for demanding business applications.

• StackWise-160 Technology enables stacking of up to 160 Gbps for simplified management and enhanced redundancy.

• Advanced Security with AES-128 MACsec encryption, segmentation and Cisco SD-Access support for robust network protection.

• Comprehensive Layer 3 Routing supports OSPF, EIGRP, VRRP, RIP, PIM and more for advanced network segmentation and traffic control.

• Flexible NetFlow & QoS provides granular traffic analytics and prioritization for optimal application performance.

• Redundant Power & Cooling with hot-swappable power supplies and fans ensure continuous uptime and easy maintenance.

• Modular Uplinks that support for 1G/10G uplinks for scalable network expansion.

• Enhanced Management that managed via Cisco IOS XE, SNMP, CLI, NETCONF and RESTCONF for streamlined operations.

Benefits of Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch

🗹 Multigigabit ports and modular uplinks support next-gen Wi-Fi, IoT and high-bandwidth devices, ensuring your network is ready for tomorrow’s demands.

🗹 PoE+ delivers both power and data over a single cable, reducing installation complexity and costs.

🗹 StackWise-160, redundant power and hot-swappable fans provide enterprise-level resiliency and minimize downtime.

🗹 Advanced encryption, segmentation, and Cisco SD-Access defend your network from internal and external threats.

🗹 Modular design and stacking capabilities allow your network to grow seamlessly as your business expands.

🗹 Flexible NetFlow and advanced QoS empower IT teams with deep insights and precise traffic management.

🗹 Intuitive interfaces and automation tools reduce administrative overhead and speed up troubleshooting.

🗹 Backed by Cisco’s enhanced global support for peace of mind.

Specifications for Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch | New

Cisco Catalyst C9200-24PXG-A 24-Port PoE+ Network Advantage Switch
