Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch | New
SKU: C9200-48P-A-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch | New
The Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch is a high-performance network switch with a variety of features for fast data transfer. Its 48x 1GB PoE+ RJ-45 ports and additional module slots offer numerous connectivity options. The switch's built-in Power over Ethernet (PoE) technology powers a variety of PoE+ devices. This model has two power supply slots, allowing for redundant power and greater flexibility in the event of a failure. It can provide a maximum PoE budget of up to 740W with a single PSU or 1440W with two PSUs installed. Regarding performance, the Cisco C9200-48P-A has a switching capacity of up to 176 Gbps (336 Gbps when stacked), allowing for smooth data flow across networks. Its forwarding rate is 261.9 Mpps (250 Mpps with stacking), ensuring fast and reliable packet delivery.
Key Features of Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch
PoE+ Capability
The Cisco Catalyst C9200-48P-A supports full Power over Ethernet Plus (PoE+) for up to 48 ports, providing power to connected devices without the need for additional power sources.
Resiliency and Redundancy
This switch includes Field-Replaceable Units (FRU), as well as redundant power supplies, fans, and modular uplinks, to ensure network operational continuity and reliability.
Advanced Security Features
The C9200-48P-A improves network security and data protection by supporting AES-128/256 MACsec encryption, policy-based segmentation, and Layer 3 capabilities such as OSPF and EIGRP.
Flexible Downlink Options
This switch, which supports data, PoE+, and mGig downlinks, allows you to connect multiple devices and meet a variety of network needs.
Operational Efficiency
The optional backplane stacking feature allows for stacking bandwidth of up to 160 Gbps, improving operational efficiency and scalability in network management.
Enhanced Network Monitoring
The switch supports Full Flexible NetFlow for advanced network monitoring, giving administrators visibility into network traffic and performance.
Intent-Based Networking
The C9200-48P-A, part of the Cisco Catalyst 9200 Series, enhances intent-based networking capabilities by simplifying complexity, optimizing IT operations, and lowering operational costs via automation and intelligence.
High-Performance IP Routing
The switch uses the Cisco Express Forwarding hardware routing architecture for high-performance IP routing, which supports a variety of routing protocols for efficient data transmission.
Operational Choice
Users can manage the switch using CLI, Cisco Catalyst Center (formerly Cisco DNA Center) on-premises management, or cloud monitoring via the Meraki dashboard, allowing for operational flexibility based on preferences.
Energy Efficiency
The switch includes Energy Efficient Ethernet (EEE) on RJ-45 ports and supports low-power modes for unused ports, promoting energy savings and environmentally friendly operation.
Specifications
Specifications for Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch | New
| Manufacturer | Cisco |
| Manufacturer Part Number | C9200-48P-A |
| Product Name | Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch |
| Product Type | Networking Switch |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000 (PoE+) |
Power Over Ethernet (PoE) | PoE+ |
Performance | Stacking bandwidth: 160 Gbps ¦ Switching bandwidth: 176 Gbps ¦ Forwarding rate: 261.9 Mpps |
Capacity | Virtual networks: 4 ¦ IPv4 routing table entries: 4000 ¦ IPv6 routing table entries: 2000 ¦ ACL scale entries: 1600 ¦ Packet buffer size: 6 MB ¦ VLAN IDs: 4096 ¦ Switched virtual interfaces (SVIs): 1000 |
MAC Address Table Size | 32000 entries |
Jumbo Frame Support | 9198 bytes |
Routing Protocol | OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP |
Remote Management Protocol | NETCONF, RESTCONF |
Encryption Algorithm | 128-bit AES |
Features | Cisco StackWise Technology, Virtual Routing and Forwarding (VRF), Flexible NetFlow (FNF), MACsec support, built-in ASIC, Control plane protection (CoPP), Virtual Extensible LAN (VXLAN), Location ID Separation Protocol (LISP), Blue Beacon LED, Security Group Tag (SGT) caching, Embedded Event Manager (EEM), Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, DNA support, Superior QoS |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
RAM | 4 GB |
Flash Memory | 4 GB |
Built-in Devices | RFID tag |
Interfaces | 48 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W |
Power Device | Internal power supply - hot-plug |
Max Supported Qty | 2 |
Power Redundancy | Optional |
Voltage Required | AC 100-240 V (50 - 60 Hz) |
MTBF | 375,570 hours |
Compliant Standards | Plug and Play, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35 |
Software Included | Cisco Network Advantage |
Width | 1.7 in |
Depth | 17.5 in |
Height | 13.8 in |
Weight | 12.13 lbs |
Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day |
Humidity Range Operating | 5 - 90% (non-condensing) |
Min Storage Temperature | -40 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 5 - 90% (non-condensing) |
User Guides
Frequently Asked Questions
Cisco Catalyst C9200-48P-A 48-Port PoE+ Network Advantage Switch
Frequently Asked Questions (FAQ's)
What is the primary function of the Cisco Catalyst C9200-48P-A switch? The primary function is to provide 48 PoE+ ports for connecting and powering network devices, along with advanced network management and security features.
What type of devices can be powered using the PoE+ ports on the C9200-48P-A switch? Devices such as IP phones, wireless access points, and IP cameras can be powered using the PoE+ ports.
What is the total PoE power budget of the C9200-48P-A switch? The total PoE power budget is 740W.
Does the C9200-48P-A support stacking? Yes, it supports stacking with other switches in the Catalyst 9200 series.
What is the maximum stacking bandwidth supported by the C9200-48P-A? The maximum stacking bandwidth is 160 Gbps.
What type of uplink modules are compatible with the C9200-48P-A? The switch supports various uplink modules, including 1G, 10G, and 25G.
Is the C9200-48P-A switch managed or unmanaged? It is a managed switch with advanced network management features.
What are the security features available on the C9200-48P-A switch? Security features include TrustSec, MACsec encryption, and segmentation.
What operating system does the C9200-48P-A switch use? It uses Cisco IOS XE operating system.
Does the C9200-48P-A support IPv6? Yes, it supports both IPv4 and IPv6.
Can the C9200-48P-A switch be used in a Layer 3 network? Yes, it supports Layer 3 routing capabilities.
What is the forwarding bandwidth of the C9200-48P-A? The forwarding bandwidth is 208 Gbps.
How many multicast routes are supported on the C9200-48P-A switch? It supports up to 4,000 multicast routes.
Is there support for Quality of Service (QoS) on the C9200-48P-A switch? Yes, it supports advanced QoS features.
What are the dimensions and weight of the C9200-48P-A switch? Dimensions: 1.73 x 17.5 x 11.3 inches (H x W x D); Weight: approximately 10.14 lbs (4.6 kg).
Does the C9200-48P-A switch support redundant power supplies? Yes, it supports dual redundant power supplies.
What is the maximum number of VLANs supported by the C9200-48P-A switch? It supports up to 4,000 VLANs.
How is the C9200-48P-A switch managed? It can be managed via the Cisco DNA Center, web UI, command-line interface (CLI), and Simple Network Management Protocol (SNMP).
What is the MTBF (Mean Time Between Failures) for the C9200-48P-A switch? The MTBF is approximately 356,930 hours.
