🗹 8x 1 Gigabit Ethernet PoE+ RJ-45
🗹 2x 1 Gigabit Ethernet Combo
🗹 67W PoE Budget
🗹 20 GbpsSwitching Capacity
🗹 14.88 Mpps Forwarding Rate
🗹 Fanless
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
The Cisco Catalyst C1000-8P-2G-L 8-Port Gigabit Ethernet PoE+ Managed Switch is an enterprise-level networking solution designed for small businesses and branch offices. This switch combines advanced features with ease of use, making it an excellent choice for businesses seeking to improve their network infrastructure. The Cisco Catalyst C1000-8P-2G-L has eight Gigabit Ethernet ports, four of which support Power over Ethernet Plus (PoE+), for a total power budget of 67W. This enables you to power devices like IP phones, wireless access points, and security cameras directly via the network cable, eliminating the need for external power sources. The switch also has two Gigabit SFP ports for flexible uplink options, allowing for easy integration into existing networks. The C1000-8P-2G-L is a dependable and effective solution for businesses looking to expand their network capabilities. Its PoE support, advanced security features, and simple management options make it an excellent choice for modern networking requirements.
• 8 Gigabit Ethernet Ports provides high-speed connectivity for devices, ensuring efficient data transfer and network performance.
• Supports PoE+ on four ports, delivering up to 30W per port to power connected devices, simplifying installation and reducing clutter.
• 67W Total PoE Budget adequate power allocation for multiple PoE devices, ensuring reliable operation without overloading the switch.
• Two Gigabit SFP Uplink Ports offers flexibility in network design by allowing connections to fiber optic cables or additional switches.
• Features advanced management capabilities through Cisco IOS Software, including a command-line interface (CLI) and web-based GUI for easy configuration and monitoring.
• Supports advanced security protocols such as 802.1X, DHCP snooping, and dynamic ARP inspection, helping to protect your network from unauthorized access.
• Operates silently, making it suitable for office environments where noise reduction is essential.
• The sleek and compact design allows for easy installation in various environments, whether mounted on a rack or placed on a desk.
| Manufacturer | Cisco |
| Manufacturer Part Number | C1000-8P-2G-L |
| Product Name | Cisco Catalyst C1000-8P-2G-L 8-Port Gigabit Ethernet PoE+ Managed Switch |
| Product Type | Networking Switch |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 4 x 10/100/1000 (PoE+) + 4 x 10/100/1000 + 2 x combo Gigabit SFP (uplink) |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 67 W |
Performance | Forwarding bandwidth: 10 Gbps ¦ Switching bandwidth: 20 Gbps ¦ Forwarding rate (64‑byte L3 packets): 14.88 Mpps |
Capacity | Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte |
Jumbo Frame Support | 10240 bytes |
Routing Protocol | IGMP, MLDv2, MLD, MSTP, RSTP, STP |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS |
Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
Features | BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), IDS, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, DTP support, PAgP support, ACL support, QoS, UDLD, Rapid PVST+, fanless, SRR, LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, MIB, CoS, 802.1x authentication, DSCP support, IGMP filtering, IP source guard, WTD, SmartPort technology, VTP, STRG, AAA, UDP, proxy ARP, SPAN, loopback detection, MAB, BPDU Guard, NEAT |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX |
Processor | X ARM: 800 MHz |
RAM | 512 MB |
Flash Memory | 256 MB |
Status Indicators | Status |
Interfaces | 4 x 1000Base-T RJ-45 PoE+ - 15 W ¦ 4 x 1000Base-T RJ-45 ¦ 2 x 1000Base-T / 1000Base-X RJ-45/SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A |
Power Device | Internal power supply |
Installed Qty | 1 |
Voltage Required | AC 120/230 V (50 - 60 Hz) |
Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A |
Width | 10.6 in |
Depth | 12.7 in |
Height | 1.7 in |
Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days |
Min Operating Temperature | 23 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 5 - 90% |
Min Storage Temperature | -13 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 5 - 95% |
