Bogen DRZ120 6-Zone Music & Paging System | New
SKU: DRZ120-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Bogen DRZ120 6-Zone Music & Paging System | New
The Bogen DRZ120 6-Zone Music & Paging System is a versatile and efficient audio solution for commercial applications. This system, which is ideal for schools, retail spaces, warehouses, and offices, allows users to manage music and paging across six different zones, ensuring seamless communication and entertainment options throughout the facility. The Bogen DRZ120 is designed to produce high-quality sound with consistent performance. Its six-zone capability allows users to easily control audio distribution, ensuring that announcements and music are directed to specific areas as needed. The system has an easy-to-use interface that can be customized to meet the needs of the environment. The DRZ120 is an excellent choice for businesses that want to improve their audio capabilities. Its versatility, user-friendly features, and high-quality sound make it an excellent addition to any commercial setting.
Key Features of Bogen DRZ120 6-Zone Music & Paging System
• 6-Zone Control manage music and paging across six distinct zones, allowing for targeted announcements and tailored audio experiences.
• Powerful Amplification equipped with a robust amplifier that ensures clear sound quality and adequate volume for various environments.
• Flexible Input Options supports multiple audio sources, including microphones, music players, and other audio devices, providing versatility in audio management.
• The intuitive front panel design allows for easy operation, making it accessible for users with varying levels of technical expertise.
• Integrated paging functionality enables quick and efficient communication, ideal for announcements and alerts.
• Designed to deliver clear and crisp audio, enhancing the overall listening experience in any setting.
• The sleek and compact design allows for easy installation in various locations without taking up excessive space.
• Built to withstand the demands of commercial use, ensuring long-lasting performance and reliability.
Specifications
Specifications for Bogen DRZ120 6-Zone Music & Paging System | New
| Manufacturer | Bogen |
| Manufacturer Part Number | DRZ120 |
| Product Name | Bogen DDU250 Desktop Dynamic Gooseneck Microphone |
| Product Type | Paging Interface |
| Power Rating (RMS) | 120 watts into 8-ohms |
| Distortion | < 1% Rated output power @ 1 kHz |
| Signal to Noise Ratio | LINE = -74dB |
| Audio Frequency Response | 80 Hz - 16 kHz @ 4O (+/-3dB) |
| Zone Outputs | 120 watts @70V max. for any single zone, or 20 watts @70V max. for each zone (assuming equal loads) |
| AUX Speaker Output | 4-16O |
| Tone Controls | Bass +/-10 dB @ 100 Hz |
| Treble | +/-10 dB @ 10 kHz |
| Microphone Inputs | = 3mV/1kO balanced (Front 1/4” TRS, Rear XLR, Rear Euro-Block x2) |
| MIC1 Precedence | VOX-activated, with adjustable MUTE Control |
| LINE Inputs | = 300mV/10kO unbalanced; RCA jacks |
| AUX Line Output | 50O/(1V); RCA jacks |
| Station Tuning | Digital, with PLL Synthesizer |
| Band Coverage | FM 87.5 to 108 MHz |
| Antenna | 75O coaxial |
| Preset Memory | Over 800 FM stations |
| Memory Scan | Automatically presets stations |
| Channel Indicator | Back-lit, LCD |
| Power Required | 120V AC nominal @ 60 Hz |
| Power Consumption | 250W |
| Overall Dimensions | 19-1/8" W x 3-1/2" H x 13-3/4" D |
| Product Weight | 252 lbs |
User Guides
Frequently Asked Questions
Bogen DRZ120 6-Zone Music & Paging System
Frequently Asked Questions (FAQ's)
What is the power output of the Bogen DRZ120?The Bogen DRZ120 delivers 120 watts of power.
How many zones can the Bogen DRZ120 manage?It supports up to six distinct audio zones.
What types of inputs does the Bogen DRZ120 support?It has multiple inputs, including two microphones, one music source, and one auxiliary input.
Can I control the volume for each zone individually?Yes, the Bogen DRZ120 allows for individual volume control in each of the six zones.
Is the Bogen DRZ120 suitable for both music and paging?Yes, it's intended for both background music distribution and paging.
What are the typical applications for the Bogen DRZ120?It is widely used in commercial settings such as offices, schools, retail stores, and restaurants.
Does the system support emergency paging?Yes, the Bogen DRZ120 supports priority paging for emergency announcements.
Can the Bogen DRZ120 be rack-mounted?Yes, the system is intended for rack-mounted installation.
Does the Bogen DRZ120 have a built-in equalizer?Yes, it does have bass and treble controls for sound customization.
Can I connect multiple Bogen DRZ120 units together?Yes, multiple units can be linked to provide greater coverage and control.
Is it possible to mute specific zones while paging?Yes, the system supports the muting of specific zones during paging.
How do I switch between different audio sources on the Bogen DRZ120?The front panel controls allow you to select an audio source.
Does the Bogen DRZ120 include an auto-sensing feature for music and paging?Yes, it automatically detects paging signals and mutes the music during announcements.
What is the frequency response range of the Bogen DRZ120?The frequency response ranges from 50Hz to 15kHz.
Can I use wireless microphones with the Bogen DRZ120?Yes, wireless microphones can be connected using the auxiliary or microphone inputs.
Does the Bogen DRZ120 have a built-in chime feature?Yes, it has a pre-announcement chime for paging.
What is the total weight of the Bogen DRZ120 system?The system weighs about 15 pounds (6.8 kilograms).
How do I reset the Bogen DRZ120 to factory settings?The Bogen DRZ120 6-Zone Music & Paging System Manual Sheet provides instructions for resetting to factory settings.
Is the Bogen DRZ120 compatible with external amplifiers?Yes, it can be connected to external amplifiers to increase power and coverage.
Can the Bogen DRZ120 be used in outdoor environments?The Bogen DRZ120 is intended for indoor use, but it can also be used outside if protected from the elements.
