Bogen CC4021 Mixer-Amplifier – 40 W with 70V/25V/4/8 Taps | New
SKU: CC4021-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Bogen CC4021 Compact Mixer-Amplifier – 40 W Output
40 watts for small-to-mid installs
The CC4021 delivers 40 W of clean power for paging, background music and small venues, with output taps for 70 V, 25 V, 4 Ω and 8 Ω speaker systems. Its 8.25″-wide chassis is two rack units tall, so you can mount one—or two side-by-side—without wasting rack space.
Simple two-input mixing
You get 2 inputs with individual volume controls: 1 balanced MIC/LINE and 1 unbalanced AUX (RCA). Input 1 can automatically mute the other source (VOX) for priority announcements, and you still keep hands-on control with bass and treble tone knobs.
Installer-friendly features
A front-panel signal LED and peak indicator speed setup; there’s a rear REC output for feeds, and an external 24 VDC input for backup power. Phantom power is available on MIC inputs, and an optional rack kit allows single or dual mounting.
Performance you can trust
Frequency response extends to 20 kHz with <1% THD+N, so music stays clean while pages cut through clearly. Listed to UL 60065 for the U.S. and Canada.
Built to last
Bogen backs the CC4021 with a 3-year warranty for the original purchaser, reflecting its proven reliability in commercial installs.
Specifications
| Manufacturer | Bogen Communications |
| Manufacturer Part Number | CC4021 |
| Product Name | CC Series Compact Mixer-Amplifier, 40 W |
| Product Type | Compact mixer-amplifier |
| Power Output | 40 W (1 kHz @ rated distortion) |
| Inputs | 2 total: 1 × balanced MIC/LINE, 1 × unbalanced AUX (RCA) |
| Priority / Muting | Input 1 VOX priority; audio-activated, defeatable |
| Tone Controls | Bass & treble, ±10 dB |
| Indicators | Signal and Peak LEDs |
| Outputs | 70 V, 25 V, 4 Ω, 8 Ω; REC out |
| Frequency Response | MIC/LINE 100 Hz–20 kHz (0/–3 dB); AUX 80 Hz–20 kHz (0/–3 dB) |
| THD+N | < 1% (MIC/LINE & AUX) |
| Power Supply | 120 VAC, 60 Hz, 2 A; external 24 VDC, 3 A input |
| Dimensions (W × H × D) | 8.25 × 3.5 × 10.375 in (210 × 89 × 264 mm) |
| Weight | ≈ 11 lb (5.0 kg) |
| Mounting | 2U half-rack; optional RPK93 kit for single or dual mount |
| Safety Listing | UL 60065 (US & Canada) |
