Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) | New

Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) | New

SKU: U7-PRO-WALL-N
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$159.99 $159.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) | New


The Ubiquiti UniFi U7 Pro Wall (U7-PRO-WALL) is a high-performance, wall-mounted WiFi 7 (802.11be) access point designed for both residential and commercial environments. It is tailored for seamless integration into modern spaces, offering advanced wireless technology, high device capacity, and robust management features. The device is particularly suited for home builders, offices, hospitality venues, and other spaces where discreet yet powerful wireless coverage is required


Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) Features:

  • WiFi 7 with 6 GHz Support: Utilizes the latest WiFi 7 standard, enabling faster speeds, lower latency, and improved efficiency, especially in dense environments. The 6 GHz band offers additional spectrum for interference-free connectivity.
  • Tri-Band Operation: Supports simultaneous operation on 2.4 GHz, 5 GHz, and 6 GHz bands for optimal performance and flexibility.
  • Six Spatial Streams: Delivers high throughput and efficiency with 2x2 MIMO on each band, supporting up to 688 Mbps (2.4 GHz), 4,324 Mbps (5 GHz), and 5,764 Mbps (6 GHz).
  • High Device Capacity: Supports over 300 concurrent clients, making it suitable for high-density deployments such as offices, schools, and public venues.
  • Wide Coverage: Provides up to 140 m² (1,500 ft²) of wireless coverage per unit.
  • PoE+ Powered: Simplifies installation by providing both power and data over a single Ethernet cable (supports 2.5 GbE uplink).
  • Versatile Mounting: Designed for wall mounting with optional flush mount and table stand accessories for flexible deployment.
  • Robust Security: Supports WPA3, WPA2, and WPA encryption standards and offers guest traffic isolation for enhanced network security.
  • Centralized Management: Fully integrated with the UniFi Network application, enabling remote device management, monitoring, firmware updates, and advanced configuration.
  • Future-Proof: Multi-Link Operation (MLO) support is planned via a future software update, further enhancing throughput and reliability

Best Uses for Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL):

  • Modern Homes: Seamlessly blends into home interiors, providing fast, reliable WiFi for streaming, gaming, and smart home devices.
  • Offices and Workspaces: Handles high client density and ensures stable connectivity for video conferencing, cloud applications, and IoT devices.
  • Hospitality and Public Venues: Ideal for hotels, cafes, and event spaces requiring secure guest networks and high-capacity coverage.
  • Educational Institutions: Supports large numbers of devices and seamless roaming across campus environments

The Ubiquiti UniFi U7 Pro Wall is a state-of-the-art WiFi 7 access point that combines high-speed, tri-band wireless performance with robust device management and security. Its wall-mounted design and versatile deployment options make it ideal for modern homes, offices, hospitality venues, and high-density environments. With support for over 300 devices, advanced security, and centralized UniFi management, it is a future-ready solution for demanding wireless networks

Specifications

Specifications for Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) | New


ManufacturerUbiquiti
Manufacturer Part NumberU7-PRO-WALL
Product NameUbiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL)
Product TypeAccess Point
Wireless StandardWiFi 7 (802.11be), backward compatible with WiFi 6/6E/5/4/3/2
Bands2.4 GHz, 5 GHz, 6 GHz (tri-band)
Spatial Streams2x2 MIMO per band (6 total)
Max Throughput688 Mbps (2.4 GHz), 4,324 Mbps (5 GHz), 5,764 Mbps (6 GHz)
CoverageUp to 140 m² (1,500 ft²)
Device Capacity300+ concurrent clients
Uplink2.5 GbE RJ45 (PoE+)
Power ConsumptionMax 22W
MountingWall (included), optional flush mount/table stand
SecurityWPA3, WPA2, WPA, guest isolation
ManagementUniFi Network application
Dimensions150 x 103 x 36 mm (5.9 x 4.1 x 1.4")
Operating Temp/Humidity-30 to 60°C, 5-95% non-condensing
Weight0.46

User Guides

Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL) Data Sheet

Frequently Asked Questions

Ubiquiti UniFi U7 Pro Wall Access Point (U7-PRO-WALL)
Frequently Asked Questions (FAQ's)



What is the Ubiquiti UniFi U7 Pro Wall Access Point used for?
  • The U7 Pro Wall Access Point is designed to deliver high-performance WiFi 7 connectivity in wall-mounted applications, ideal for hotel rooms, dorms, and office spaces.
    • Does the U7 Pro Wall support WiFi 7 technology?
  • Yes, the U7 Pro Wall fully supports WiFi 7 (802.11be), offering faster speeds, lower latency, and improved performance in high-density environments.
    • How is the UniFi U7 Pro Wall mounted?
  • The access point is designed for easy wall mounting using a standard single-gang or EU-sized wall box, making it discreet and space-saving.
    • What is the maximum wireless speed of the U7 Pro Wall?
  • The U7 Pro Wall offers up to 9.3 Gbps combined throughput across its 2.4 GHz, 5 GHz, and 6 GHz bands for ultra-fast wireless performance.
    • Can the U7 Pro Wall be powered via PoE?
  • Yes, it supports Power over Ethernet (PoE+), allowing for simplified cabling and installation using a single Ethernet cable.
    • Does this access point support all three WiFi bands?
  • Yes, it operates on tri-band frequencies: 2.4 GHz, 5 GHz, and 6 GHz, ensuring maximum compatibility and speed.
    • How many devices can connect to the U7 Pro Wall simultaneously?
  • The U7 Pro Wall is capable of supporting hundreds of simultaneous connections, making it suitable for high-density areas.
    • What are the ideal deployment scenarios for the U7 Pro Wall?
  • This access point is ideal for hospitality, student housing, and small-to-medium enterprise deployments where in-room wireless access is needed.
    • Is the UniFi Network Controller required to manage this device?
  • Yes, the U7 Pro Wall is managed via UniFi Network Controller, which provides centralized configuration, monitoring, and analytics.
    • Does the U7 Pro Wall have Ethernet pass-through ports?
  • Yes, it includes multiple Ethernet ports, including pass-through, for connecting additional wired devices such as VoIP phones or media equipment.
    • How secure is the U7 Pro Wall Access Point?
  • It supports WPA3 encryption and advanced UniFi security features, including firewall rules and traffic segmentation for robust network security.
    • Can I use multiple U7 Pro Wall units in a mesh network?
  • Yes, the U7 Pro Wall supports seamless roaming and integration into a larger UniFi mesh network for expanded coverage.
    • What is the physical design of the U7 Pro Wall like?
  • It features a low-profile, in-wall design that blends into indoor environments while providing high-performance wireless coverage.
    • Does the U7 Pro Wall support guest WiFi networks?
  • Yes, it allows for the creation of secure guest networks with customizable access controls and captive portals.
    • Is the U7 Pro Wall compatible with older WiFi devices?
  • Yes, it's backward compatible with WiFi 6, WiFi 5, and earlier devices, ensuring universal connectivity.
    • Can VLAN tagging be configured on the U7 Pro Wall?
  • Yes, VLANs are fully supported and configurable through the UniFi Controller for network segmentation and policy enforcement.
    • What kind of throughput can be expected on the 6 GHz band?
  • The 6 GHz band offers superior speeds and reduced interference, ideal for bandwidth-intensive applications like 4K streaming or video conferencing.
    • How does the U7 Pro Wall handle device roaming?
  • It offers fast and seamless handoff between UniFi access points using 802.11k, 802.11r, and 802.11v protocols to improve user experience.
    • What is the typical range of the U7 Pro Wall?
  • The typical coverage range depends on the environment, but it is designed to effectively cover a single room or small office area with high-speed WiFi.
    • Can the LED status light on the U7 Pro Wall be turned off?
  • Yes, the LED can be managed via the UniFi Controller, allowing users to disable or customize its behavior for aesthetic or privacy purposes.
