Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP) | New
SKU: ER-X-SFP-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP) | New
The Ubiquiti EdgeRouter X SFP (ER-X-SFP) is an advanced gigabit Ethernet router designed for reliable and flexible network deployment. It features five Gigabit RJ45 Ethernet ports with passive PoE output and one Gigabit SFP port for fiber backhaul connectivity. This router is powered by an 880 MHz dual-core processor and runs on Ubiquiti's EdgeOS, offering both a user-friendly graphical interface and a command-line interface for advanced users.
Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP) Features:
- Five 10/100/1000 Mbps RJ45 Ethernet ports with 24V passive PoE output to power airMAX or UniFi devices
- One Gigabit SFP port for hot-swappable fiber connectivity and backhaul applications
- Dual-core 880 MHz MIPS1004Kc processor for efficient routing performance
- 256 MB DDR3 RAM and 256 MB NAND code storage
- Supports line-rate, Layer-2 switching on all ports
- Powered by an external 24V AC/DC power adapter
- Passive PoE output supports connected devices like NanoBeam, UniFi Video Cameras, and access points
- EdgeOS graphical user interface with integrated CLI for advanced network management
- Wall-mountable form factor
- Operating temperature range from -10 to 45°C and humidity range of 10 to 90% non-condensing
- Certifications: CE, FCC, IC
Best Uses for Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP):
- Small to medium business networks requiring fiber backhaul connectivity
- Deployments needing PoE to power multiple network devices such as access points and cameras
- Networks demanding cost-effective, versatile routing with advanced configuration options
- Service provider networks with OSPF and multiple internet connections
- Use cases requiring both copper Ethernet and fiber connectivity options for uplink
Specifications
Specifications for Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP) | New
| Manufacturer | Ubiquiti |
| Brand: | Ubiquiti Networks |
| Model Name: | EdgeRouter X ER-X-SFP |
| Special Feature: | WPS |
| Compatible Devices: | Personal Computer |
| Frequency: | 880 MHz |
| Recommended Uses For Product: | Home |
| Connectivity Technology: | Ethernet |
| Color: | Black |
| Item Weight: | 0.6 Kilograms |
| Dimensions: | 142 x 75 x 23 mm (5.59 x 2.95 x 0.91") |
| Weight: | 215 g (7.58 oz) |
| Processor: | Dual-Core 880 MHz, MIPS1004Kc |
| Memory: | 256 MB DDR3 RAM |
| Code Storage: | 256 MB NAND |
| Max. Power Consumption: | 5W |
| Power Input: | 24VDC, 2.5A Power Adapter (Included) |
| Power Supply: | External AC/DC Adapter |
| Supported Voltage Range: | 9 to 26VDC |
| Buttons: | Reset |
| LEDs: | Power, Link/Activity (6), PoE (5) |
| Wall Mount: | Yes |
| Operating Temperature: | -10 to 45° C (14 to 113° F) |
| Operating Humidity: | 10 to 90% Noncondensing |
| Certifications: | CE, FCC, IC |
User Guides
Frequently Asked Questions
Ubiquiti EdgeRouter X SFP Advanced Gigabit Ethernet Router (ER-X-SFP)
Frequently Asked Questions (FAQ's)
What is the Ubiquiti EdgeRouter X SFP? The EdgeRouter X SFP is an advanced gigabit Ethernet router featuring an SFP port for fiber connectivity and five 10/100/1000 Mbps RJ45 ports.
How do I set up the EdgeRouter X SFP? Connect your modem to the router’s WAN port, connect your devices to the LAN ports, and access the router’s web interface via a web browser to configure it.
What are the key features of the EdgeRouter X SFP? Key features include advanced routing capabilities, five gigabit Ethernet ports, one SFP port, PoE support, and a user-friendly graphical interface.
What is the SFP port used for? The SFP port is used for fiber optic connections, allowing for high-speed data transfer over long distances.
Does the EdgeRouter X SFP support PoE? Yes, it supports Passive PoE on ports eth0 and eth4.
How do I update the firmware on the EdgeRouter X SFP? Firmware can be updated through the router’s web interface by navigating to the System tab and uploading the new firmware file.
What is the maximum throughput of the EdgeRouter X SFP? The maximum throughput is 1 Gbps for routing and 2 Gbps for switching.
Can the EdgeRouter X SFP be managed remotely? Yes, it can be managed remotely using Ubiquiti’s UNMS (Ubiquiti Network Management System) or via SSH.
What is the operating temperature range for the EdgeRouter X SFP? The operating temperature range is -10°C to 45°C (14°F to 113°F).
Does the EdgeRouter X SFP support VLANs? Yes, it supports VLANs and VLAN tagging.
What kind of power adapter does the EdgeRouter X SFP use? It uses a 12V, 1A power adapter.
Is there a mobile app for managing the EdgeRouter X SFP? Yes, you can use the UNMS mobile app for basic management.
How do I reset the EdgeRouter X SFP to factory settings? Press and hold the reset button for about 10 seconds until the LEDs start flashing, then release the button.
What is the difference between the EdgeRouter X and the EdgeRouter X SFP? The EdgeRouter X SFP includes an SFP port for fiber connections, whereas the EdgeRouter X does not.
Can I use the EdgeRouter X SFP with an existing network setup? Yes, it can be integrated into an existing network setup as a router or switch.
Does the EdgeRouter X SFP support dual WAN failover? Yes, it supports dual WAN failover for increased reliability.
What security features are available on the EdgeRouter X SFP? Security features include firewall policies, NAT, VPN, and access control lists (ACLs).
How do I configure VPN on the EdgeRouter X SFP? VPN can be configured through the router’s web interface under the VPN tab, with options for PPTP, L2TP, and OpenVPN.
What type of SFP modules are compatible with the EdgeRouter X SFP? It is compatible with standard SFP modules, including single-mode and multi-mode fiber.
Can the EdgeRouter X SFP be rack-mounted? No, it is designed for desktop use and does not come with rack-mounting hardware.
