Ubiquiti Compatible 48V DC 0.5A 24W Gigabit PoE Adapter (POE-48-24W-G) | New

Ubiquiti Compatible 48V DC 0.5A 24W Gigabit PoE Adapter (POE-48-24W-G) | New

SKU: POE-48-24W-G-GEN
1Review
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$11.99 $11.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Ubiquiti Compatible 48V DC 0.5A 24W Gigabit PoE Adapter (POE-48-24W-G) | New

Specific PoE Adapter models are designed to work with the airGateway. The airGateway is a compact CPE (consumer premises equipment) gateway with built-in Wi-Fi used to connect the subscriber’s local network to the WISP network.

Ubiquiti Networks offers Power over Ethernet (PoE) Adapters to power a variety of Ubiquiti products. The PoE Adapters are compatible with most Ubiquiti PoE devices*, including:

• airFiber®
• airMAX®
• EdgeMAX®
• mFi®
• UniFi® AP
• UniFi Protect / airVision®
• UniFi LED
• UFiber

Specifications

Specifications for Ubiquiti Compatible 48V DC 0.5A 24W Gigabit PoE Adapter (POE-48-24W-G) | New

Manufacturer:Ubiquiti
ModelPOE-48-24W-G
Dimensions92 x 60 x 33 mm (3.62 x 2.36 x 1.30")
Weight158.5 g (5.59 oz)
Output Voltage48VDC @ 0.5A
LAN Activity IndicatorNo
Gigabit LAN PortYes
Remote Reset CapabilityNo
Reset ButtonNo
Rated Voltage100-240VAC @ 50/60Hz
Input Current0.6A @ 120VAC, 0.4A @ 240VAC
Inrush Current<65A Peak @ 120VAC, <130A Peak @ 230VAC
Efficiency80+%
Output Ripple1% Max.
Switching Frequency65 kHz
Line Regulation≤ 3%
Load Regulation≤ 5%
Operating Temperature0 to 40° C
Storage Temperature-30 to 70°C
Operating Humidity35 to 95% Noncondensing
AC ConnectorIEC-320 C6
Data IN / PoERJ45 Shielded Socket
Surge ProtectionDifference and Common Mode
Clamping Protection11V Data, 60V Power
Max. Surge Discharge1500A (8/20 μs) Power
Peak Pulse Current36A (10/1000 μs) Data
Shunt Capacitance<5 pF data
Response Time<1 ns


User Guides

Ubiquiti Compatible 48Volt 24Watt POE Injector (POE-48-24W-G) Data Sheet

Frequently Asked Questions

Ubiquiti POE-48-24W-G POE Injector 24 Watt
Frequently Asked Questions (FAQ's)



What is the Ubiquiti POE-48-24W-G used for?
  • Using Ethernet connections, this Power over Ethernet (PoE) injector powers compatible Ubiquiti devices.
    • What devices are compatible with the POE-48-24W-G?
  • It is compatible with Ubiquiti devices, including some UniFi and airMAX versions, that need 48V passive PoE.
    • What is the output power of this PoE adapter?
  • 24 watts.
    • What is the voltage and current output?
  • 48V DC at 0.5A.
    • Does it support Gigabit Ethernet?
  • Yes, it supports 10/100/1000 Mbps (Gigabit) Ethernet.
    • Can it be used outdoors?
  • No, it is designed for indoor use only.
    • Is the POE-48-24W-G compliant with IEEE 802.3af or 802.3at standards?
  • No, it is not IEEE 802.3af/at compliant and employs passive PoE.
    • Does it come with mounting hardware?
  • Some versions include wall-mount brackets; check product packaging.
    • What is the input voltage range?
  • 90–260V AC, 47–63 Hz.
    • Does it have surge protection?
  • Yes, it includes surge protection for enhanced device safety.
    • Can I use it with non-Ubiquiti devices?
  • Always verify the device specs to see if the gadget supports 48V passive PoE.
    • How many devices can it power at once?
  • One device per adapter.
    • Is the power supply included with the unit?
  • Yes, it has a built-in power supply and is a standalone adaptor.
    • What are the dimensions of the adapter?
  • Approximately 88 x 57 x 33 mm.
    • Does it have LED indicators?
  • Yes, it includes power and status LEDs.
    • Can it be used with UniFi Access Points?
  • Yes, if the AP requires 48V passive PoE.
    • Is this unit hot-swappable?
  • No, before connecting or detaching devices, you should unplug the power.
    • What is the difference between passive PoE and active PoE?
  • While active PoE works with the device to negotiate power requirements, passive PoE provides a steady voltage (IEEE 802.3af/at).
    • Can this adapter damage devices not rated for 48V?
  • Yes, it can damage devices that aren't compatible with it; check the voltage requirements before usage.
    • Is this PoE injector fanless?
  • Yes, it is a fanless unit, operating silently.
