Polycom SoundStation 2 Direct Connect for Nortel Conference Phone (2200-17120-001) | New
SKU: 2200-17120-001-N
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Polycom SoundStation 2 Direct Connect for Nortel Conference Phone (2200-17120-001) | New
The Polycom SoundStation 2 Direct Connect for Nortel Conference Phone (2200-17120-001) enables Nortel Meridian users to connect their Soundstation 2 directly to their Nortel Meridian PBX digital wall jack. There is no need for cumbersome connections because the direct connection will take advantage of natural two-way discussions using Polycom's Acoustic Clarity Technology.
Key Features of Polycom SoundStation 2 Direct Connect for Nortel Conference Phone
Direct Nortel Meridian PBX port access
This eliminates the requirement for a third-party PBX converter or the use of a dedicated conference room line. Users can use this feature to access basic PBX capabilities such as Conference, Transfer, and Hold.
Acoustic Clarity Technology
Allows for authentic, dynamic two-way dialogue. Full duplex eliminates the requirement for users to wait for speakers on the other end to cease talking before joining a conversation.
Dynamic Noise Reduction (DNR)
Reduces background noise in the room from fans, projectors, heating and air conditioning, and so on, for clearer sound and more effective conferencing.
3 Cardioid Microphones
Provide 360-degree coverage to ensure that everyone in the room can hear each other clearly.
Intelligent Microphone Mixing
Eliminates unnecessary background noises by automatically selecting the microphone nearest to the person speaking.
Microphone Expandability
Provides the option of adding two extension microphones to expand coverage in bigger conference rooms.
Large, backlit graphical display
Allows easy access to crucial call information such as phone number, number called, and call duration/progress. Also supports global Caller ID.
50% more microphone sensitivity
Allows you to speak normally and be clearly heard up to ten feet away from the microphones. It reduces ear strain and repetition.
Cell phone connectivity
Allows you to use the built-in cell phone connector to convert cell calls into conference calls.
Single-cord connection to phone console
Reduces cable clutter on the tabletop.
Specifications
Specification for Polycom SoundStation 2 Direct Connect for Nortel Conference Phone (2200-17120-001) | New
| Manufacturer | Polycom |
| Manufacturer Part Number | 2200-17120-001 |
| Product Name | Polycom SoundStation 2 Direct Connect for Nortel Conference Phone |
| Product Type | Conference Phone |
| Size (L x W x H) | 14.5 x 12.25 x 2.5 in |
| (36.8 x 31.1 x 6.4 cm) | |
| Weight | 1.75 lb. (0.8 kg) |
| Power | 110V 60Hz AC / 220V 50 Hz AC (depending on country-specific SKU) |
| Network Interface | Nortel Meridian Digital PBX |
| PBX Compatibility | Compatible with: |
| Nortel Meridian | |
| Meridian 1 (option 11 to 81) | |
| SL-1 or SL-100 | |
| User Interface | User selectable ring tones |
| Configurable soft keys for easy dialing of voice conferencing services | |
| Multi-lingual support: English, German, French, Italian, Spanish, Portuguese, Norwegian | |
| Password protected configuration settings for administrators | |
| Caller ID and Phone Book | Phone book/speed dial list – up to 25 entries* |
| Keypad | 12-key telephone keypad |
| On-hook/off-hook, conference, mute, volume up/down keys, menu, navigation keys* | |
| 3 context sensitive soft keys* including redial, hold, programmable conference key | |
| Console Loudspeaker | Frequency response: 300 to 3300 Hz |
| Volume: adjustable to 94 dBA SPL (peak) volume at 0.5 meters | |
| Console Microphones | 3 cardioid microphones 300 to 3500 Hz |
| Audio | Polycom Acoustic Clarity full duplex – IEEE 1329 Type 1 |
| Up to 10 ft. microphone pick-up range | |
| Gated microphones with intelligent microphone mixing | |
| Dynamic noise reduction | |
| Interfaces | 2 EX microphone connections |
| Applications Port for connection to other communication devices such as mobile phones and computers | |
| RCA Auxiliary audio jack | |
| Accessories | 2 cardioid extension microphones 300 – 3500 Hz (for EX model only) |
User Guides
Frequently Asked Questions
Polycom SoundStation 2 Direct Connect for Nortel Conference Phone
Frequently Asked Questions (FAQ's)
What is the Polycom SoundStation 2 Direct Connect for Nortel used for? It’s a conference phone designed to connect directly to Nortel PBX systems without requiring an analog adapter.
Is this model compatible with analog phone lines? No, it works exclusively with Nortel digital PBX systems.
Does it support full-duplex communication? ? Yes, it offers full-duplex audio, enabling natural, two-way conversations.
How many microphones does it include? The device comes with three built-in microphones for 360-degree coverage.
Can external microphones be connected for larger rooms? No, this model does not support external microphone expansion.
What room size is suitable for the SoundStation 2 Direct Connect? It’s designed for small to medium-sized rooms, accommodating up to 10 participants.
Does it require a separate power supply? No, it is powered through the Nortel digital line connection.
Is it compatible with VoIP systems? No, it is not compatible with VoIP and works only with Nortel digital PBX systems.
Does it feature noise reduction? Yes, it uses dynamic noise reduction (DNR) to minimize background noise.
Does the phone have an LCD display? Yes, it includes an LCD screen to display call information and settings.
Can I mute the microphones during a call? Yes, the phone includes a mute button for silencing microphones.
Does it support caller ID? Yes, it supports caller ID, depending on your Nortel PBX configuration.
Can the phone be used with call waiting? Yes, it supports call waiting features available on Nortel systems.
Is there a speed dial feature? Yes, it allows you to configure speed dial for frequently called numbers.
Does it have echo cancellation technology? Yes, it features built-in echo cancellation for enhanced audio clarity.
Can the SoundStation 2 be wall-mounted? No, it’s designed for tabletop use only.
What type of connection cable is used? It connects to the Nortel PBX system using a digital interface cable.
What happens if I try to use it on a non-Nortel system? It will not work with non-Nortel systems since it’s tailored specifically for Nortel digital lines.
Does the phone support conference calling? Yes, it supports conference calls via the Nortel PBX system.
Is the Polycom SoundStation 2 Direct Connect easy to set up? Yes, it’s a plug-and-play device, requiring only a direct connection to the Nortel PBX system.
