Overview
Overview of Panasonic KX-UDT121 SIP DECT Cordless Compact Phone | New
The Panasonic KX-UDT121 SIP DECT Cordless Compact Phone is compatible with the Panasonic KX-TGP600 SIP cordless phone system and has high-definition audio, full duplex hands-free functionality, and Bluetooth support.
The KX-UDT121 is a cordless and compact DECT communication solution. The KX-UDT121 includes noise-reduction technology for clear communication in noisy areas, as well as over-the-air firmware upgrades and Bluetooth connectivity.
The audio features of the KX-UDT121 include 6 levels of handset, speaker, and headset volume, 27 distinct MIDI ringtones, a 2.5mm micro pin port, built-in Bluetooth, and a full duplex speakerphone. Each unit supports two Portable Station (PS) SIP accounts and has a phone book that can store up to 500 entries and retrieve the latest 20 incoming and outgoing calls. The phonebook may be shared by Bluetooth, and the KX-UDT121 supports fast firmware updates via air.
Key Features of Panasonic KX-UDT121 SIP DECT Cordless Compact Phone
Cordless Compact Phone
Slim, light model ideal for offices with active movement
Frequency: DECT 6.0
1.8” , 65,000-color TFT display
High-quality wideband voice
Noise reduction
Built-in Bluetooth
Full duplex speakerphone
Headset Jack: 2.5mm
Vibration
Up to 500 station personal phonebook
Quick charge: 3.0 hours
Li-ion 3.7 V, 700 mAh battery
13 hour (narrow band)/10 hour (wideband) talk time
200 hour standby time
DECT encryption
Message waiting indicator
Requires a TGP600G base station to work on the NS700 and NS1000 systems
Specifications
Specification for Panasonic KX-UDT121 SIP DECT Cordless Compact Phone | New
Manufacturer | Panasonic |
Manufacturer Part Number | KX-UDT121 |
Product Name | Panasonic KX-UDT121 SIP DECT Cordless Compact Phone |
Product Type | Wireless Phone |
LCD Display Type | 65,000-Color TFT |
LCD Size | 1.8 inch |
LCD Contrast | 6 levels |
LCD Backlight | Yes |
LED | Ringer/Charge |
Handset, Speaker, Headset Volume | 6 levels |
Ringtones | 27 (MIDI) |
Ringer Volume | 6 levels + Off |
Headset Port | Yes (2.5 mm mini pin jack) |
Headset Ringer | Yes |
Vibrate | Yes (4 Patterns) |
Bluetooth® | Yes (Built-in) |
HD Voice (Wideband Voice) | Yes |
Noise Reduction | Yes |
Speaker Phone | Yes (Full Duplex) |
SIP Accounts | 2 per Portable Station (PS) |
Phone Book (Entries) | Up to 500 numbers |
Call Log Entries | 20 incoming calls + 20 outgoing calls |
Redial | Yes |
Do Not Disturb | Yes |
Anonymous Call (CLIR) | Yes |
Anonymous Call Rejection | Yes |
Calling party name and number presentation (CLIP, CNIP) | Yes |
Call Rejection (Manual operation while incoming call) | Yes |
DTMF Dialing During Call | Yes |
Three-party Conferencing | Yes |
Call Transfer | Yes |
Call Hold | Yes |
Call Forward Unconditional/User Busy/No Answer | Yes |
Call Waiting | Yes |
Message Waiting Indication | Yes |
Vibrate Ring | No |
Distinctive Ringing | Yes |
Firmware Update Via Air | Yes |
Phone Book Transfer Via Bluetooth® | Yes (vCard) |
Talk | Up to 13 hours |
Standby | Up to 200 hours |
Battery Charge Time | 3 hours |
Charger | Standby: 0.3 W / Max: 4.0 W |
Battery Type | Li-ion battery pack x 1 |
Belt Clip | Yes (Swivel type is included) |
Strap Hole | Yes |
Wall Mount (Charger) | Yes |
Operating Environment | 32°F - 104°F (0°C - 40°C) |
DIMENSIONS (W X D X H) | |
Handset | (55 mm x 23 mm x 152 mm) (48.5 mm x 17.9 mm x 127.5 mm) |
Handset on Charger | (71.5 mm x 80.5 mm x 165.0 mm) (63 mm x 78 mm x 140 mm) |
WEIGHT | |
Handset | 0.19 lb (88 g) |
Handset + Charger | 0.30 lb (135 g) |
