  • Dell USB Type-C Docking Station with 130W Power Adapter (WD19S130W) | Like New
Dell USB Type-C Docking Station with 130W Power Adapter (WD19S130W) | Like New

Dell USB Type-C Docking Station with 130W Power Adapter (WD19S130W) | Like New

SKU: WD19S130W-LN
(0)No Reviews yet

Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns

$74.99 $74.99
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Dell WD19S130W USB Type-C Docking Station with 130W Power Adapter | Like New

The Dell WD19S130W USB Type-C Docking Station with 130W Power Adapter has a single USB Type-C input and an included cable that provides 130W Power Delivery with compatible Dell laptops and 90W to non-Dell systems when the included 130W AC power adapter is connected, allowing you to use your notebook while charging it. When connected, this hub provides three USB 3.1 Gen 1 Type-A and two Type-C ports, allowing you to connect to a variety of compatible devices. Two DisplayPort and one HDMI inputs allow you to connect a variety of displays to the WD19S while supporting a maximum resolution of 3840 x 2160 at a refresh rate of 60 Hz, providing a crisp and fluid image. A single RJ45 Gigabit Ethernet connector is also included, providing an upgraded hardwired connection suited for uploading and downloading files. While this device can be mounted in a variety of configurations using extra mounting hardware, the Noble Wedge and Kensington slots provide a security solution, preventing theft when connected with various locking mechanisms.

Key Features of Dell WD19S130W USB Type-C Docking Station with 130W Power Adapter



Industry Standard Compatibility

Dell Commercial Docks provide the most compatibility with Dell Commercial laptops. The WD19S is also compatible with notebooks from other manufacturers, such as HP and Lenovo, that support industry USB-C docking standards.

Power your day

Dell ExpressCharge charges up to 80% of your device in one hour, making it the most effective way to manage your workday.

Energize your workload

Get more done in less time with Dell ExpressCharge Boost, a feature that charges your device by up to 35% in just 20 minutes.

Unmatched charging

Increase your power delivery and charging speed with a dock that supplies up to 90W of electricity and a 130W power converter.

Mix and match

With our most adaptable dock, you can evolve as your needs change. The future-proof architecture allows you to easily swap out modules if you need to make field replacements or upgrade your systems.

Ultimate connectivity

USB-C connectivity makes it easier than ever to transfer power, data, audio, and video in a single handy cable, regardless of system.

Clean and clutter-free

Stay busy by installing your dock beneath your display or under your desk with the optional, secure VESA mount, which provides complete versatility with a one-meter cable built in.

Information in a flash

With data transfer rates of up to 10Gbps, you can stay productive while connected to all of your devices.

Smooth and seamless

Work without interruptions by utilizing a single firmware on our most manageable docks ever. You can also upgrade your firmware without rebooting your dock using Dell Client Command Suite and Microsoft System Center Configuration Manager.

Secure manageability

With MAC Address pass-through and remote port-disablement, you can keep your data safe. Plus, with features like PXE Boot, Wake-on-LAN, and more, it's easier than ever to be working while controlling your dock.

Specifications

Specifications for Dell WD19S130W USB Type-C Docking Station with 130W Power Adapter | Like New

ManufacturerDell
Manufacturer Part NumberWD19S130W
Product NameDell WD19S130W USB Type-C Docking Station with 130W Power Adapter
Product TypeDocking Station
Width8.1 in
Depth3.5 in
Height1.1 in
Weight20.63 oz
Enclosure ColorBlack
Max Resolution Details3840 x 2160 - 60 Hz
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Interfaces2 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x USB-C ¦ 3 x USB 3.1 Gen 1 - 9 pin USB Type A ¦ 2 x USB-C 3.1 Gen 2 ¦ 1 x network - Ethernet 1000 - RJ-45
Cables Included1 x USB-C cable - 2.6 ft
FeaturesSecurity lock slot (cable lock sold separately), 130W power delivery to Dell systems, 90W power delivery to non-Dell systems, wireless vPro
Security Slot TypeNoble Wedge security slot / Kensington security slot
Power DevicePower adapter
Voltage RequiredAC 120/230 V (50/60 Hz)
Power Provided130 Watt
OS RequiredRed Hat Enterprise Linux, Windows 10, Ubuntu 18.04
Bundled Services3 years Basic Hardware Service with Advanced Exchange
Designed ForDell Latitude 3310 2-in-1, 3320, 3410, 3420, 3510, 3520, 5310, 5310 2-in-1, 5320, 5410, 5510, 5520, 7320, 7320 Detachable, 7410 Chromebook Enterprise ¦ Dell XPS 13 9310

User Guides

Frequently Asked Questions

Dell USB Type-C Docking Station with 130W Power Adapter (WD19S130W)
Frequently Asked Questions (FAQ's)



What devices are compatible with the Dell WD19S130W docking station?
  • Most Dell laptops that have a USB-C or Thunderbolt 3/4 connector that supports DisplayPort over USB-C can use it.
  • What is the total power delivery output of the WD19S130W?
  • It can supply up to 130W to compatible Dell laptops and up to 90W to non-Dell systems.
  • Can I use the WD19S130W with non-Dell laptops?
  • Yes, although some features might not function as intended and charging might be restricted to 90W.
  • How many external displays does it support?
  • Depending on the graphics capabilities of your system, it can handle either one 5K monitor at 60Hz or up to two 4K displays at 60Hz.
  • Does the dock require driver installation?
  • Dell advises downloading the most recent firmware and drivers from their website, but the majority of drivers install automatically through Windows Update.
  • What ports are available on the WD19S130W?
  • Gigabit Ethernet, USB-C, USB-A (3.1 Gen 1), HDMI 2.0, DisplayPort 1.4, combination audio, and a power input connector are all included.
  • Is the dock hot-swappable?
  • Yes, hot swapping is supported without requiring a host system reboot.
  • Can I charge my phone or other devices via USB ports?
  • Yes, even when the laptop is not in use, USB PowerShare can be used to charge devices.
  • Does it support dual monitors on MacBooks?
  • Restricted support: unless third-party software or M1/M2 Pro/Max/Ultra chips are being used, macOS does not allow expanded display via DisplayLink.
  • Is this dock Thunderbolt compatible?
  • Although it is not a Thunderbolt dock, it can use USB-C fallback to connect to Thunderbolt 3/4 ports.
  • What operating systems are supported?
  • Windows 10/11, and limited support for Linux and macOS.
  • Can I update the firmware of the docking station?
  • Yes, Dell offers firmware updates through the support website or Dell Command Update.
  • Does it support Wake-on-LAN and PXE Boot?
  • Yes, if supported by the host system and BIOS settings.
  • Can it power external peripherals like external hard drives?
  • Yes, it provides sufficient power via USB-A and USB-C ports.
  • Is the dock portable?
  • It is primarily intended for desktop use, it is portable and adaptable to mobile configurations.
  • What is the difference between WD19S and WD19?
  • Some WD19S models do not have a 3.5mm audio jack, and the software has been upgraded to provide wider compatibility.
  • Does it support daisy chaining of monitors?
  • Yes, via DisplayPort Multi-Stream Transport (MST) if supported by the laptop.
  • Will it work if connected via a USB-C hub or adapter?
  • It is not advised because power and data performance may be impacted. Attach straight to a USB-C port that is suitable.
  • Can I use the dock with a USB-C to USB-A adapter?
  • No, in order to function properly, the dock needs a native USB-C port with DisplayPort Alt Mode.
  • Will the dock work if my laptop doesn’t support USB-C charging?
  • It may function for data and video, but it won’t charge your laptop.
