Overview of Cisco Meraki MX67C Cloud Managed Security Appliance (MX67C-HW-WW) | New
The Cisco Meraki MX67C Cloud Managed Security Appliance (MX67C-HW-NA) includes a CAT 6 LTE modem for always-on connectivity. This device, which is ideal for small retail locations or clinics, can typically accommodate up to 50 users and has a stateful firewall throughput of up to 450 Mbps. It supports up to 50 simultaneous VPN sessions for completely secure data transfer and has five Gigabit Ethernet connections for connecting a range of devices.
Installation and remote management are straightforward because the MX is completely cloud managed. The MX provides a full set of security and network services, including threat management and SD-WAN features, removing the need for several appliances. Without having to travel, your company can set up its retail locations or clinics in a central area. Template-based multi-network management enables you to quickly set up profiles and settings across thousands of devices while ensuring easy scaling. Monitoring and reporting tools ensure that you receive email warnings about utilization data, and detailed changelogs make tracing changes quite fast.
Secure your network quickly with an intelligent WAN that incorporates policy-based routing and dynamic VPN path selection, as well as a choice of application-layer protocols and systems that ensure only authorized visitors gain access. For optimal protection, threat management solutions include content filtering, intrusion prevention via a PCI-compliant IPS sensor, identity-based policies, and Cisco Advanced Malware Protection. This Cisco Meraki cloud-managed security & SD-WAN appliance can process all information passing through it quickly thanks to an improved CPU and plenty of RAM.
Key Features of Cisco Meraki MX67C Cloud Managed Security Appliance
SD-branch cloud platform
Unified management for security, SD-WAN, Wi-Fi, switching, MDM, and IoT
Centralized management via web-based dashboard or API
True zero-touch provisioning
Smartphone-like firmware updates
Unified threat management
Next-generation layer 7 firewall and content filtering
Advanced Malware Protection (AMP) with Cisco Threat Grid
Intrusion detection and prevention (IDS/IPS)
Visibility of security events through an elegant security center GUI
Cloud security
Built-in SD-WAN connectivity to Cisco Umbrella global data centers
Application prioritization
SSL decryption/inspection, data loss prevention (DLP), CASB
Remote browser isolation, granular app control, SaaS tenant restrictions
Connectivity
Layer 7 application optimization over self-healing Auto VPN (SD-WAN fabric)
Extension of SD-WAN fabric to hybrid clouds and Cisco Umbrella
Support for native IPsec or Cisco AnyConnect remote client VPN
Instant wired failover with added 3G/4G failover via USB modem
Advanced analytics with ML
Automatically applied Smart Thresholds to identify true app degradation
At-a-glance performance of apps across the LAN, WAN, and app server
Instant root-cause analysis of degradation with intelligent recommendations
Status of multi-site uplinks in one view, including cellular
Specifications
Specification for Cisco Meraki MX67C Cloud Managed Security Appliance (MX67C-HW-WW) | New
| Manufacturer | Cisco |
| Manufacturer Part Number | MX67C-HW-WW |
| Product Name | Cisco Meraki MX67C Cloud Managed Security Appliance |
| Product Type | Security and Firewall |
Device Type | Security appliance |
Built-in Devices | Modem |
Width | 9.4 in |
Depth | 6.9 in |
Height | 1.1 in |
Weight | 29.98 oz |
Localization | North America |
Form Factor | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Network / Transport Protocol | DHCP |
Routing Protocol | Static IP routing |
Cloud-Managed | Yes |
Performance | Stateful throughput: 450 Mbps ¦ VPN throughput: 200 Mbps ¦ Secure traffic throughput: 300 Mbps |
Capacity | Concurrent users: 50 ¦ VPN tunnels: 50 |
Features | Firewall protection, DHCP support, NAT support, VLAN support, content filtering, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), firmware upgradable, wall mountable, IPSec Virtual Private Network (VPN), anti-malware protection, 3G/4G USB Dongle Support, Link Aggregation, VPN client, IP Security (IPSec) support, DMZ support |
Cellular Protocol | LTE |
Expansion Slots | 1 SIM card |
Interfaces | 4 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T - RJ-45 (WAN) ¦ 1 x USB 2.0 - Type A ¦ 1 x modem |
Power Device | External power adapter |
Power Provided | 30 Watt |
Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next day |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 113 °F |
Humidity Range Operating | 5 - 95% (non-condensing) |
User Guides
Frequently Asked Questions
Cisco Meraki MX67C Cloud Managed Security Appliance
Frequently Asked Questions (FAQ's)
What is the Cisco Meraki MX67C? The Cisco Meraki MX67C is a cloud-managed security appliance designed for small to medium-sized businesses, offering advanced security features such as next-gen firewall, content filtering, VPN, intrusion prevention, and more.
What are the key features of the MX67C? Key features include a built-in 4G LTE modem, SD-WAN, advanced security features, VPN support, content filtering, traffic shaping, and cloud-based management via the Meraki dashboard.
Does the MX67C support VPN? Yes, the MX67C supports site-to-site VPN, client VPN, and auto VPN, making it ideal for remote workforce access and secure site connections.
Can I manage the Cisco Meraki MX67C remotely? Yes, the MX67C is cloud-managed, allowing you to monitor, configure, and troubleshoot your network remotely using the Meraki Dashboard.
What is the maximum number of devices the MX67C can support? The MX67C can support up to 50 devices and is ideal for small and medium-sized offices with up to 50 users.
What is the maximum throughput of the Cisco Meraki MX67C? The maximum throughput of the MX67C is 450 Mbps, making it suitable for medium-speed internet connections and a variety of small business needs.
How many Ethernet ports does the MX67C have? The MX67C has 3 Gigabit Ethernet ports, along with 1 WAN port and 1 USB port for a 4G LTE modem or other USB-based devices.
Does the MX67C have built-in 4G LTE? Yes, the MX67C includes a built-in 4G LTE modem, providing cellular failover or primary WAN connectivity when necessary.
Can I use the MX67C as a Wi-Fi access point? No, the MX67C is not an access point, but it can be paired with Meraki access points to extend your network with seamless wireless connectivity.
Does the Cisco Meraki MX67C include advanced security features? Yes, it includes features like next-gen firewall, intrusion detection and prevention (IDS/IPS), content filtering, malware protection, and application visibility and control.
What is the warranty for the Cisco Meraki MX67C? The Cisco Meraki MX67C typically comes with a 1-year warranty, with additional support and license options available through Cisco Meraki subscriptions.
Can I integrate the MX67C with an existing network? Yes, the MX67C can be easily integrated into your existing network infrastructure by connecting it to your current router or network.
How do I update the firmware on the Cisco Meraki MX67C? Firmware updates for the MX67C are automatically managed through the Meraki Dashboard, with updates pushed to the device from the cloud.
Is the Cisco Meraki MX67C suitable for SD-WAN? Yes, the MX67C supports SD-WAN functionality, which allows for improved WAN performance, traffic routing based on real-time conditions, and reduced costs compared to traditional MPLS networks.
What is the power supply requirement for the MX67C? The MX67C uses a 12V DC power adapter, which is included in the package.
Does the MX67C support IPv6? Yes, the MX67C supports IPv6, making it compatible with both IPv4 and IPv6 networks.
How does the Meraki Dashboard work with the MX67C? The Meraki Dashboard provides a user-friendly, web-based interface for configuring, monitoring, and managing the MX67C, including analytics, alerts, and performance metrics.
Can the MX67C handle traffic shaping? Yes, the MX67C supports traffic shaping, allowing you to prioritize certain types of traffic, such as VoIP or video conferencing, to ensure optimal performance.
Is the Cisco Meraki MX67C compatible with other Meraki products? Yes, the MX67C is designed to integrate seamlessly with other Meraki products, including Meraki access points, switches, and cameras, to provide a unified network solution.
What is the licensing model for the Cisco Meraki MX67C? The MX67C requires an active Meraki license subscription for continued access to cloud management, security features, and firmware updates. Licenses are typically sold in 1, 3, 5, or 7-year terms.
