Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW) (Unclaimed) | Like New
SKU: MS320-24P-HW-LN
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW) | Like New
The Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW) is a robust and adaptable networking solution for modern businesses. This cloud-managed switch combines enterprise-level features with the ease of cloud management, resulting in seamless connectivity and efficient network operations. The MS320-24P-HW features a high-performance hardware platform with a non-blocking switch fabric that provides wire-speed switching and low latency. It has 24 Gigabit Ethernet PoE+ ports that can provide up to 370 watts of PoE budget, making it suitable for powering a wide range of PoE-enabled devices, including IP phones, wireless access points, and IP cameras.
The MS320-24P-HW leverages the power of cloud computing to eliminate the need for complex on-premises management systems. Administrators can configure, monitor, and troubleshoot the switch from any location using the intuitive Meraki dashboard, lowering operational costs and streamlining network management. As a layer 3 switch, the MS320-24P-HW supports advanced routing protocols such as OSPF and static routing. This feature allows for seamless integration with existing network infrastructures while also providing the flexibility to scale and adapt to changing business requirements. The MS320-24P-HW includes strong security features such as 802.1X authentication, DHCP snooping, and access control lists (ACLs), which ensure a secure and protected network environment. It also supports Quality of Service (QoS) features, which allow for the prioritization of mission-critical applications and ensure peak performance for latency-sensitive traffic.
The MS320-24P-HW integrates seamlessly with other Meraki products, such as wireless access points and security appliances, to create a unified and cohesive network solution. Its modular design and support for virtual stacking facilitate scalability, allowing businesses to expand their network as their needs change. The Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW) is an excellent choice for businesses looking for a high-performance, secure, and easily manageable networking solution that can evolve to meet their changing needs.
Key Features of Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch
• Provides up to 370W of PoE budget to power devices like IP phones, wireless APs, and IP cameras
• Allows high-speed uplink to aggregation switches or other upstream devices
• Supports static routing, dynamic routing protocols (OSPF, BGP)
• Provides inter-VLAN routing and policy-based routing
• Centralized management and monitoring from anywhere
• Zero-touch provisioning and simplified configuration
• 802.1X authentication, DHCP snooping, ACLs
• Multiple administrative roles and security policies
• Traffic prioritization for voice, video, and critical applications
• Per-port QoS configuration
• Virtual stacking of up to 10 switches
• Rapid Spanning Tree Protocol (RSTP) for fast convergence
• Low power consumption and fanless operation
• Lifetime hardware warranty and advanced replacement
Specifications
Specifications for Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW) | Like New
| Manufacturer | Cisco |
| Manufacturer Part Number | MS320-24P-HW |
| Product Name | Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch |
| Product Type | Wireless Headset |
| Network Ports | 24x 1 Gigabit Ethernet PoE RJ-45 |
| Uplink Ports | 4x 10 Gigabit Ethernet SFP+ |
| Management Ports | Cloud Managed |
| Product Family | Meraki MS320 Series |
| SFP Modules | None Included |
| Power Supplies Included | 1x MA-PWR-640WAC Internal AC PSU |
| PoE Budget | 370W |
| Switching Capacity | 128 Gbps |
| Latency | 2.5 microsecond latency |
| Rack Mounts | Integrated Rack Mount Brackets |
User Guides
Frequently Asked Questions
Cisco Meraki MS320-24P Cloud Managed 24-Port PoE Switch (MS320-24P-HW)
Frequently Asked Questions (FAQ's)
What is the Cisco Meraki MS320-24P? The MS320-24P is a cloud-managed 24-port Gigabit Ethernet PoE switch that is optimized for high performance and ease of use in medium to large networks.
How many ports does the MS320-24P have? It includes 24 Gigabit Ethernet ports.
Does the MS320-24P support Power over Ethernet (PoE)? Yes, it supports PoE and has a total power budget of 370 W.
What is the maximum PoE power output per port on the MS320-24P? Each port can deliver up to 30 watts of power.
Does the MS320-24P have uplink ports? Yes, it includes four SFP+ uplink ports for high-speed fiber connections.
Can the MS320-24P be managed through the cloud? Yes, it is managed using the Meraki cloud dashboard.
What Layer 3 features does the MS320-24P support? It can run OSPF, static routing, DHCP server, and DHCP relay.
How is the firmware updated on the MS320-24P? Firmware updates are automatically pushed via the Meraki cloud dashboard.
Does the MS320-24P support VLANs? Yes, it does support VLANs for network segmentation.
What is the power consumption of the MS320-24P? The typical power consumption is approximately 35W (without a PoE load).
Can the MS320-24P be used in a stack? No, the MS320 series does not allow physical stacking.
What is the warranty period for the MS320-24P? It includes a limited lifetime hardware warranty.
How do I configure the MS320-24P? Configuration is done using the Meraki cloud dashboard, which can be accessed via a web browser.
Does the MS320-24P support quality of service (QoS)? Yes, it supports QoS to prioritize network traffic.
Can the MS320-24P be mounted in a rack? Yes, it includes rack mounting hardware for easy installation in a standard 19-inch rack.
What security features are included with the MS320-24P? It has features such as port security, ACLs, and 802.1X authentication.
Is the MS320-24P suitable for outdoor use? No, it is intended for indoor use only.
Does the MS320-24P support link aggregation? Yes, it supports link aggregation, which combines multiple ports into a single logical link.
What management options are available for the MS320-24P? It is only managed through the Meraki cloud dashboard, which provides centralized management and monitoring.
Where can I purchase the MS320-24P? It can be purchased from authorized Cisco Meraki resellers, distributors, and online marketplaces.
