Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch | New

Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch | New

SKU: C9300-48P-M-N
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$3,699.99 $3,699.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch | New

The Cisco Meraki Catalyst C9300 48P M 48-Port PoE+ Switch provides real business-grade performance, cloud-managed simplicity and high-density access to enable bigger campus and enterprise environments. This Layer 3 stackable switch has 48 Gigabit PoE+ ports (505W standard power budget, extensible up to 1220W) and it easily scales to power IP phones, cameras, Wi-Fi 6 APs and IoT endpoints. Adaptive Policy security segmentation, robust twin 120G hardware stacking, modular uplinks (10G/40G ready) and management through the user-friendly Meraki dashboard make it perfect for future-ready digital workspaces that require centralized control and smooth expansion.


Key Features of Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch


• 48 x 1GbE PoE+ ports distribute up to 30W/port for APs, VoIP and cameras, with a 505W PoE+ budget (expandable).

• Modular uplink options that add 10G/40G SFP+ for flexible expansion and fast aggregation or network core links.

• Dual 120G hardware stacking that chain up to eight switches for rapid growth or redundancy—up to 480Gbps stacking bandwidth.

• 256Gbps switching capacity with non-blocking performance, ideal for voice, video and data-rich applications.

• Adaptive Policy and Secure Connect with fine-grained segmentation and policy management for secure, compliant networks.

• Cloud-based Meraki Dashboard that remotely deploy, monitor, troubleshoot and automate firmware with minimal IT overhead.

• Layer 3 enterprise features with IPv4/v6 dynamic/static routing, VLANs, multicast, DHCP snooping and storm control.

• StackPower Technology that pool power supplies across the stack for resilient, optimized power distribution.

• Hot-swappable, redundant PSU maximize uptime with modular power and fan units.

• Secure, scalable management with SNMP, syslog, MACsec, ACLs and 802.1X authentication for robust physical and remote protection.


Benefits of Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch


🗹 Power modern workspaces that centralize device power for dense AP, phone and IoT deployments, reducing cabling and TCO.

🗹 Scale instantly, confidently that add switches and uplinks as requirements grow and expand PoE with StackPower for uninterrupted service.

🗹 Unified cloud control that Meraki dashboard streamlines config, policy and troubleshooting, enabling hands-off, secure multi-site management.

🗹 Security, compliance, branding that secure Connect, Adaptive Policy and comprehensive Layer 3 features enforce data security and segmentation.

🗹 Operational efficiency with hot-swap components, high stacking throughput and automated firmware reduce downtime and IT workload.

🗹 Future-proof investment with modular, high-bandwidth architecture supports next-gen wireless and digital transformation for years to come.

Specifications

Specifications for Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch | New

ManufacturerCisco
Manufacturer Part NumberC9300‑48P‑M
Product NameCisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch
Product TypeSwitch
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
48 x 10/100/1000 (PoE+)
Power Over Ethernet (PoE)
PoE+
PoE Budget
437 W
Performance
Switching capacity: 256 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 190.48 Mpps
Capacity
QoS queues: 8 ¦ Member ports per aggregated link: up to 8 ¦ VLANs with trunking: 4094
MAC Address Table Size
32000 entries
Max Units In A Stack
8
Routing Protocol
IGMP, VRRP, OSPFv2, static IP routing, MSTP, RSTP, STP
Remote Management Protocol
SNMP, DHCP, IPv4, IPv6, Syslog
Authentication Method
RADIUS
Features
VLAN support, port mirroring, Broadcast Storm Control, firmware upgradable, PVST, DHCP snooping, ACL support, QoS, DHCP server, DAI, STP Root Guard, UDLD, DHCP relay, Cisco StackPower technology, hot swappable 3 fans, network diagnostics, RBAC, push notification, STP BPDU Guard, STP loop guard, ZTP, DSCP to CoS Mutation, PIM, MAB, VLAN trunking, CDP, RPVST, sticky MAC, adaptive policy, usage statistics
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
Built-in Devices
3 x fans
Status Indicators
Status
Interfaces
48 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 2 x network stack device ¦ 1 x management ¦ 1 x USB Type A ¦ 1 x USB Type B console
Expansion Slots
1 (total) / 1 (free) x expansion slot
Power Device
Internal power supply - hot-plug
Installed Qty
1
Max Supported Qty
2
Power Redundancy
Optional
Power Provided
715 Watt
Voltage Required
AC 100-240 V (50 - 60 Hz)
80 PLUS Certification
80 PLUS Platinum
Rack Mounting Kit
Included
MTBF
277,770 hours
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, KN32, KN35, EN 55032, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, TCVN 7317, AN/NZS 60950.1, V-2/2015.04, V-3/2015.04, FCC CFR 47 Part 15 Class A, VCCI-CISPR 32 Class A
Width
17.5 in
Depth
17.7 in
Height
1.7 in
Weight
16.73 lbs
Min Operating Temperature
23 °F
Max Operating Temperature
113 °F
Humidity Range Operating
5 - 90%
Min Storage Temperature
-4 °F
Max Storage Temperature
158 °F

User Guides

Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch Data Sheet

Frequently Asked Questions

Cisco Meraki Catalyst C9300‑48P‑M 48‑Port PoE+ Switch
Frequently Asked Questions (FAQ's)



What is the Cisco Meraki Catalyst 9300L-48P used for?
  • The Cisco Meraki Catalyst 9300L-48P is a high-performance network switch designed for enterprise-level networks. It provides secure, scalable, and intelligent switching for data centers, branch offices, and large campus environments.
    • Does the C9300-48P-M support Power over Ethernet (PoE)?
  • Yes, the Cisco Catalyst 9300L-48P-M supports full PoE+ (802.3at), delivering power to connected devices like IP phones, wireless access points, and surveillance cameras without requiring separate power supplies.
    • How many ports does the Cisco C9300-48P-M have?
  • The switch includes 48 Gigabit Ethernet ports and additional uplink options, providing ample connectivity for high-density networking environments.
    • Is the Catalyst 9300L-48P stackable?
  • Yes, this model supports Cisco StackWise technology, enabling multiple switches to operate as a single virtual switch for easier management and increased resiliency.
    • What makes the 9300L-48P-M suitable for enterprise environments?
  • Its support for advanced Layer 3 routing, high port density, PoE+ support, and Cisco DNA Center integration make it ideal for scalable, secure, and intelligent enterprise network deployments.
    • Does the C9300-48P-M support Layer 3 switching?
  • Yes, it includes full Layer 3 capabilities, such as OSPF, EIGRP, and BGP, allowing dynamic routing and inter-VLAN communication.
    • Can the Catalyst 9300L-48P be managed through Cisco Meraki dashboard?
  • No, despite the “Meraki” naming, the C9300-48P-M is not managed through the Meraki Dashboard. It is part of the Catalyst line and uses Cisco DNA Center or CLI for management.
    • What uplink options are available for the C9300-48P-M?
  • It supports modular uplinks, with options for 1G, 10G, or 25G interfaces, allowing for flexible network architecture upgrades.
    • How does the Catalyst 9300L enhance network security?
  • It includes features like TrustSec, MACsec encryption, and segmentation capabilities, helping enforce role-based access and secure data traffic.
    • What is the switching capacity of the C9300-48P-M?
  • The Catalyst 9300L-48P-M delivers a switching capacity of up to 208 Gbps, supporting high-performance applications and minimizing bottlenecks.
    • Does this switch support Cisco DNA licensing?
  • Yes, it supports Cisco DNA subscriptions, enabling software-defined networking features, analytics, and policy-based automation through DNA Center.
    • What type of power supplies does the C9300-48P-M use?
  • It typically comes with dual redundant power supplies to ensure continuous operation and prevent downtime in case of power failure.
    • Can this switch support voice and video over IP?
  • Yes, it is optimized for converged networks and provides the necessary QoS and PoE+ features to support voice and video traffic reliably.
    • Is there fan redundancy in the Catalyst 9300L-48P-M?
  • Yes, it includes redundant, field-replaceable fans that help maintain proper airflow and cooling for uninterrupted performance.
    • What is the typical use case for this switch in a network?
  • Common use cases include core and distribution layers in medium to large enterprise networks, powering access points and IP devices, and facilitating high-throughput connections.
    • Does the 9300L-48P-M support virtualization features?
  • Yes, it includes Virtual Routing and Forwarding (VRF) support, allowing multiple network paths without interfering with each other on the same switch.
    • Is QoS supported on the Cisco C9300-48P-M?
  • Yes, it includes advanced Quality of Service (QoS) settings to prioritize mission-critical traffic like voice and video.
    • What software does the C9300-48P-M run?
  • It runs on Cisco IOS XE, which supports modular software updates, automation, and programmability through APIs.
    • Can this switch operate in a 24/7 environment?
  • Absolutely, it is built for high-availability environments with redundant components and robust performance under continuous use.
    • How does the switch handle device onboarding and automation?
  • With support for Plug-and-Play (PnP) and integration with Cisco DNA Center, the C9300-48P-M enables streamlined onboarding and network automation features.
