Overview of Cisco IE 2000 Series Industrial Ethernet 4-Port Switch (IE-2000-4TS-B-RF) | Refresh
The Cisco IE 2000 Series Industrial Ethernet Switch 4-Port (IE-2000-4TS-B-RF) is a line of compact, industrially rugged access switches. The IE 2000 series offers customers ease of use, secure access, and industry-leading convergence via Cisco Resilient Ethernet Protocol (REP). Several industries, including automotive, oil and gas, mining, transportation, and energy, are increasingly requiring IP-based networks in their production facilities. The IE 2000 enhancements were created to support access layer connectivity and to meet the growing demand for security, voice, and video traffic across industrial networks.
Features of the Cisco IE 2000 Series Industrial Ethernet Switch 4-Port
4 Twisted-Pair Ethernet Ports
This switch has 4 twisted-pair Ethernet ports, which are commonly used for connecting industrial devices such as PLCs (Programmable Logic Controllers), sensors, cameras, and other critical equipment.
Rugged Industrial Design
The Cisco IE-2000-4TS-B is designed to withstand the harsh environments common in industrial settings. It can perform well in extreme temperatures, resist dust and humidity, and withstand mechanical shock and vibration. This durability is critical for its use in factories, power plants, transportation systems, and other harsh environments.
Layer 2 Managed Switching
The switch supports Layer 2 network management, which allows you to configure and manage VLANs (Virtual LANs), Quality of Service (QoS), and other security features. This enables more efficient network operation and improves network control.
Redundancy and Resilience
Ensuring network reliability is critical in industrial applications where downtime can result in substantial losses. The Cisco IE-2000-4TS-B includes redundancy features like Rapid Spanning Tree Protocol (RSTP) and Media Redundancy Protocol (MRP) to improve network resilience and reduce the risk of network failure.
Advanced Security Features
Security is a top priority in industrial environments to protect sensitive data and critical infrastructure. This switch includes advanced security features such as Access Control Lists (ACLs), Port Security, and 802.1X Authentication to protect the network from unauthorized access and threats.
Easy Configuration and Management
Security is a top priority in industrial environments to protect sensitive data and critical infrastructure. This switch includes advanced security features such as Access Control Lists (ACLs), Port Security, and 802.1X Authentication to protect the network from unauthorized access and threats.
DIN-Rail Mounting
The switch can be conveniently mounted on DIN rails, which are a common mounting method in industrial settings. This allows for more flexible installation and better space utilization.
Specifications
Specifications for Cisco IE 2000 Series Industrial Ethernet 4-Port Switch (IE-2000-4TS-B-RF) | Refresh
| Manufacturer | Cisco |
| Manufacturer Part Number | IE-2000-4TS-B-RF |
| Product Name | Cisco IE 2000 Series Industrial Ethernet 4-Port Switch |
| Product Type | Networking Switch |
| Enclosure Type | DIN rail mountable |
| Subtype | Fast Ethernet |
| Ports | 4 x 10/100 + 2 x SFP |
| Performance | Forwarding performance (64-byte packet size): 6.5 Mpps |
| Capacity | Virtual interfaces (VLANs): 255 |
| MAC Address Table Size | 8K entries |
| Routing Protocol | IGMP, static IPv4 routing |
| Remote Management Protocol | SNMP 3, HTTPS, SSH |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | DHCP support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Quality of Service (QoS), Port Security, Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards | IEEE 802.1x |
| RAM | 256 MB |
| Flash Memory | 64 MB |
| Interfaces | 6 x 100Base-TX RJ-45 | 2 x SFP (mini-GBIC) |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card |
| Rack Mounting Kit | Optional |
| MTBF | 374,052 hours |
| Compliant Standards | C-Tick, CISPR 22 Class A, CISPR 24, IEC 61000-4-11, VCCI Class A ITE, EN55022 Class A, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, RoHS, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, EN 61000-6-4, IEC 60068-2-30, KCC, IEC 60068-2-27, IEC 60068-2-6, UL 508, FCC Part 15 A, IEC 60529 IP30, CISPR 11, CSA 22.2 No. 142, EN 61131-2, EN 61326-1, EN 61000-4-9, EN 61000-4-29, IEC 60068-2-14 |
| Software Included | Cisco IOS LAN Base |
| Width | 2.9 in |
| Depth | 4.5 in |
| Height | 5 in |
| Weight | 2.45 lbs |
| Service & Support | Limited warranty - 1 year |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 185 °F |
| Country of Origin | CN |
User Guides
Frequently Asked Questions
Cisco IE 2000 Series Industrial Ethernet 4-Port Switch (IE-2000-4TS-B)
Frequently Asked Questions (FAQ's)
What is the Cisco IE 2000? The Cisco IE 2000 is an industrial-grade Ethernet switch designed for use in severe environments and applications that require high reliability and longevity.
What are the key features of the Cisco IE 2000? Network management capabilities, Layer 2 switching, sophisticated security, ruggedized design, and support for industrial protocols like EtherNet/IP and PROFINET are some of the key characteristics.
What are the typical use cases for the Cisco IE 2000? Manufacturing, energy, transportation, and other industrial applications necessitate strong networking solutions.
What are the port options available on the Cisco IE 2000? Models include a range of port configurations, including 8, 16, or 24 Ethernet ports with copper and fiber connections.
What power input options does the Cisco IE 2000 support? It supports dual DC power inputs for redundancy, with ranges of 12–48 VDC.
Does the Cisco IE 2000 support PoE (Power over Ethernet)? Yes, some models provide PoE and PoE+ support for powering devices like as IP cameras and wireless access points.
What protocols does the Cisco IE 2000 support? It supports several protocols, including RSTP, MSTP, EtherChannel, VLANs, QoS, and IGMP snooping.
Is the Cisco IE 2000 compatible with industrial protocols? It supports several protocols, including RSTP, MSTP, EtherChannel, VLANs, QoS, and IGMP snooping.
Does the Cisco IE 2000 support Gigabit Ethernet? Some versions include Gigabit Ethernet ports, while others only support Fast Ethernet.
What security features are included? The features include 802.1X authentication, access control lists (ACLs), port security, and secure remote management via SSH and HTTPS.
How can the Cisco IE 2000 be managed? It can be managed using Cisco Industrial Network Director (IND), CLI, SNMP, or a web-based interface.
Does the Cisco IE 2000 support network redundancy? Yes, it does support redundancy technologies like as Spanning Tree Protocol (STP) and Cisco Resilient Ethernet Protocol (REP).
What temperature range does the Cisco IE 2000 support? It functions at harsh temperatures ranging from -40°C to 75°C, depending on the model.
Is the Cisco IE 2000 resistant to environmental factors? Yes, it is intended to tolerate stress, vibration, dust, and humidity in industrial settings.
What are the mounting options for the Cisco IE 2000? It accepts DIN rail and wall mounting for versatile installation in industrial situations.
Can the Cisco IE 2000 integrate with existing IT networks? Yes, it is designed to integrate seamlessly with enterprise IT networks that use Cisco technologies.
Does the Cisco IE 2000 support IPv6? Yes, it supports IPv6 for future-proof networking.
Can the Cisco IE 2000 be used in hazardous locations? Certain models are certified for deployment in hazardous environments in accordance with industry norms.
What kind of technical support is available for the Cisco IE 2000? Cisco offers a variety of support services, including Smart Net Total Care (SNTC) and TAC for technical assistance.
Does the Cisco IE 2000 support VLAN segmentation? Yes, it can handle up to 256 VLANs for network segmentation and traffic control.
