Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch | Refresh
SKU: C1300-8FP-2G-RF
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch | Refresh
The Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch is a compact, high-performance switch designed for small business networks that need dependable power, flexibility and secure management. This Cisco managed switch, which has two combined Gigabit RJ45/SFP uplinks and eight Gigabit PoE+ ports, is designed to power IP phones, security cameras, access points and other linked devices with a simple, effective installation. It is a great option for offices that need quiet operation without compromising enterprise-style capability because of its fanless design, 120W PoE budget and Layer 3-ready feature set. Network administrators can monitor traffic, expedite setup and maintain dependable connection throughout the corporate environment using Cisco's user-friendly web interface and dashboard features.
Key Features of Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch
• 8 x 10/100/1000 Gigabit Ethernet PoE+ ports for powering business devices.
• 2 x combo Gigabit RJ45/SFP uplink ports for copper or fiber flexibility.
• 120W total PoE budget to support phones, cameras and wireless access points.
• Layer 2/Layer 3 managed switching features for stronger traffic control.
• 20 Gbps switching capacity and 14.88 Mpps forwarding rate for efficient performance.
• Fanless, silent operation for office and noise-sensitive environments.
• Cisco Business Dashboard and web-based management for easy setup and monitoring.
• Advanced security features including VLANs, ACLs and access protections.
• Rack-mountable design for organized deployment in business network closets.
• Designed for small and midsize business networks needing compact PoE switching.
Benefits of Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch
🗹 Power your essential devices directly through the switch and reduce cable clutter.
🗹 Keep your office quiet with a fanless design that runs silently in shared spaces.
🗹 Improve connectivity options with combo uplinks that support both copper and fiber.
🗹 Maintain smooth traffic flow with strong switching capacity and Layer 3 controls.
🗹 Enhance security and segmentation with Cisco business-class network features.
🗹 Simplify daily management through intuitive dashboard and browser-based tools.
🗹 Build a stable, scalable networking foundation for small business growth.
🗹 Deliver professional-grade performance in a compact, easy-to-deploy form factor.
Specifications
Specifications for Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch | Refresh
| Manufacturer | Cisco |
| Manufacturer Part Number | C1300-8FP-2G-RF |
| Product Name | Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch |
| Product Type | Networking Switch |
Enclosure Type | Rack-mountable |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP/RJ-45 |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 120 W |
Performance | Forwarding rate (64‑byte packets): 14.88 Mpps ¦ Switching capacity: 20 Gbps |
Capacity | MSTP instances: 8 ¦ RPVST+ instances: 126 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ VLAN IDs: 4093 ¦ IGMP multicast groups: 2000 ¦ IPv4 routes (static): up to 990 ¦ IPv4 interfaces: 128 ¦ ACL rules: 1024 ¦ Priority queues: 8 ¦ Packet buffer size: 1.5 MB |
MAC Address Table Size | 16000 entries |
Jumbo Frame Support | 9000 bytes |
Routing Protocol | RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3, policy-based routing (PBR), MLDv2, MLD, CIDR, MSTP, RSTP, STP, Bounjour |
Remote Management Protocol | SNMP, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RADIUS, Syslog |
Encryption Algorithm | MD5, SSL |
Authentication Method | RADIUS, TACACS+ |
Features | BOOTP support, VLAN support, IGMP snooping, DoS attack prevention, port mirroring, DiffServ support, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, sFlow, DHCP snooping, DHCP server, MLD snooping, reset button, STP Root Guard, fanless, DHCP relay, Port Security, DHCP client, IGMP proxy, Protocol-based VLANs support, Storm Control, MLD proxy, IP source guard, ARP inspection, MAC address authentication, IGMP querier, VLAN mirroring, DNS client, VLAN management, LLDP-MED, Private VLAN, RA guard, Guest VLAN, STP loop guard, EEE, DSCP based CoS, MAC based VLAN, loopback detection, Telnet server, Telnet client, Unknown Storm Control, BPDU Guard, router advertisement guard, DHCPv6 guard, Q-in-Q tunneling, IPv4 and IPv6 dual stack, Zero-Touch Deployment, cable length detection, Web authentication, PoE scheduling, trustworthy systems, layer 3 routing, dynamic routing, ACL support, eco-friendly button, Address Resolution Protocol, Auto Surveillance VLAN, CPE VLAN, TCP congestion, iSCSI traffic optimization, chip guard, boot integrity, persistent PoE, time-based port operation, MSTP support, QoS, PVST+, LACP, GARP, GVRP, ToS, SCP, SCT, SSD, UDP, DoS protection, WRR, HoL Blocking Prevention, LAG, RPVST+, DAD, LLDP, path MTU discovery, STP support, CLI management, ATP, FHS, IPMB, NDP, RSTP, PVE, MVR, TPID, UDLD, DAI, Cisco NG PnP Protocol, RSPAN |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az |
Processor | X ARM: 1.4 GHz |
RAM | 1 GB DDR4 SDRAM |
Flash Memory | 512 MB |
Status Indicators | System, PoE, link/activity/speed |
Interfaces | 8 x 10/100/1000 Base-T (PoE+) RJ-45 ¦ 2 x 1000Base-X RJ-45/SFP ¦ 1 x console RJ-45 ¦ 1 x USB-C console |
Power Device | Internal power supply |
Voltage Required | AC 100-240 V (50 - 60 Hz) |
Included Accessories | Mounting kit, pointer card |
MTBF | 1,786,412 hours |
Compliant Standards | Plug and Play, FCC CFR47 Part 15, WEEE, CSA 22.2, RFC1213, RFC1493, RFC1757, RFC2674, RFC768, RFC791, RFC1157, RFC2460, RFC2011, RFC1643, RFC2012, RFC2013, UL 62368, RFC783, RFC792, RFC2863, RFC793, RFC826, RFC854, RFC2131, RFC2132, RFC1907, RFC1215, RFC2233, RFC2665, RFC951, RFC1542, RFC2618, RFC4443, RFC1981, RFC4861, RFC4862, RFC4291, RFC813, RFC879, RFC896, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1286, RFC1350, RFC1442, RFC1451, RFC1533, RFC1541, RFC1573, RFC1624, RFC1700, RFC1867, RFC2030, RFC2576, RFC2616, RFC2666, RFC2737, RFC2819, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595 |
Width | 10.6 in |
Depth | 10.7 in |
Height | 1.7 in |
Weight | 5.71 lbs |
Service & Support | Limited warranty - lifetime - response time: next business day ¦ Technical support - consulting - 1 year |
Min Operating Temperature | 23 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 5 - 90% RH (non-condensing) |
Min Storage Temperature | -13 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 5 - 90% RH (non-condensing) |
User Guides
Frequently Asked Questions
Cisco Catalyst C1300-8FP-2G 8-Port Gigabit PoE+ Managed Network Switch
Frequently Asked Questions (FAQ's)
What is the Cisco Catalyst C1300-8FP-2G used for?
It is a managed switch designed to connect devices, provide PoE+ power and support secure business networking.
How many ports does it have?
It includes 8 Gigabit PoE+ Ethernet ports and 2 Gigabit uplink ports.
Does it support PoE+?
Yes, it supports PoE+ for powering compatible devices through Ethernet cables.
What devices can it power?
It can power IP phones, wireless access points, IP cameras and other PoE-enabled devices.
Is this switch managed or unmanaged?
It is a fully managed switch with advanced networking and configuration capabilities.
Does it support VLANs?
Yes, VLAN support allows network segmentation for enhanced security and performance.
Does it support Layer 3 features?
Yes, it includes Layer 3 Lite functionality such as static routing.
Is it suitable for small businesses?
Yes, it is ideal for small businesses, branch offices and retail environments.
Can it be rack-mounted?
Yes, it supports flexible mounting options including rack installations.
Does it support QoS?
Yes, Quality of Service prioritizes voice, video and critical network traffic.
What are the uplink ports used for?
The 2 Gigabit uplink ports provide backbone connectivity and network expansion.
Is it secure?
Yes, it includes enterprise-grade security features such as ACLs and port security.
Can it handle multiple devices?
Yes, it is designed to efficiently support multiple connected devices simultaneously.
Does it require a license?
No, standard functionality typically does not require additional licensing.
Can I monitor network traffic?
Yes, monitoring and analytics tools are available through the management interface.
Is firmware upgradable?
Yes, firmware updates are supported for enhanced performance and security.
Does it support IPv6?
Yes, it supports IPv6 for compatibility with modern networking infrastructures.
Is it energy efficient?
Yes, it is optimized to reduce power consumption while maintaining high performance.
Is it suitable for VoIP deployments?
Yes, PoE+ and QoS features make it ideal for VoIP and unified communication systems.
Is it future-proof?
Yes, with scalable architecture and advanced networking features, it supports long-term business growth.
