  • Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) | Refresh
Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) | Refresh

Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) | Refresh

SKU: CBS350-24XS-NA-RF
(0)No Reviews yet

🗹 24 x 10G SFP+ Ports
🗹 4 x 10G SFP+/RJ45 Combo Ports
🗹 480 Gbs Switching Capacity
🗹 240 Mpps Forwarding Rate
🗹 800 MHz ARM Processor
🗹 512MB RAM
🗹 Rack-Mountable Design
🗹 Comprehensive Layer 2 & 3 Features
🗹 Works with Cisco Business Dashboard

Cisco Refresh offers fully remanufactured, Cisco Certified products with SmartNet eligibility (OEM Refurbished).

Clean Serial: YES

Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$899.99 $899.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) | Refresh

The Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) is a high-performance Layer 3 managed switch built for small and medium-sized organizations that require reliable network connectivity and extensive capabilities. This versatile 24-port 10 Gigabit Ethernet switch provides great speed and flexibility, making it perfect for high-bandwidth applications, data centers, and demanding commercial environments. With 20 dedicated 10G SFP+ ports and 4 combo 10G SFP+/RJ45 ports, the CBS350-24XS offers a wide range of connectivity options for expanding networks. With an 800 MHz ARM processor and 512MB of RAM, this switch improves security, dependability, and operational efficiency for enterprises experiencing digital transformation.


Key Features of Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports


• 20 dedicated 10G SFP+ ports for high-speed fiber connectivity

• 4 combo 10G SFP+/RJ45 ports for flexible uplink options

• 480 Gbps switching capacity and 240 Mpps forwarding rate

• Layer 3 static routing capabilities

• Advanced security features including 802.1X authentication and ACLs

• Quality of Service (QoS) for traffic prioritization

• Easy-to-use web-based management interface

• True stacking capability with up to 4 units in a stack

• IPv6 support for future-proof networking

• Cisco Business Dashboard for simplified network management

• Energy Efficient Ethernet (EEE) support

• VLAN support for network segmentation

• Dual image support for seamless software upgrades

• Rack-mountable design for easy deployment

Specifications

Specifications for Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA) | Refresh

Manufacturer Cisco
Manufacturer Part Number CBS350-24XS-NA-RF
Product Name Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports
Product Type Networking Switch
Enclosure Type
Rack-mountable
Subtype
10 Gigabit Ethernet
Ports
20 x 10 Gigabit SFP+ + 4 x combo 10 Gigabit SFP+/RJ-45
Performance
Switching capacity: 480 Gbps ¦ Forwarding performance (64-byte packet size): 240 Mpps
Capacity
RPVST+ instances: 126 ¦ MSTP instances: 8 ¦ VLANs supported: 4094 ¦ ACL rules: 1024 ¦ Buffer capacity (MB): 3
MAC Address Table Size
16K entries
Jumbo Frame Support
2KB
Max Units In A Stack
4
Routing Protocol
IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MLDv2, MLD, CIDR, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Encryption Algorithm
SSL
Authentication Method
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
Features
Flow control, BOOTP support, ARP support, VLAN support, Syslog support, DoS attack prevention, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), reset button, STP Root Guard, Uni-Directional Link Detection (UDLD), LACP support, LLDP support, DHCP relay, Management Information Base (MIB), Multicast VLAN Registration (MVR), Generic VLAN Registration Protocol (GVRP), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, IP source guard, SmartPort technology, dual image support, DNS client, Secure Core Technology (SCT), Private VLAN Edge (PVE), LLDP-MED, IP/Mac/Port Binding (IPMB), Secure Sensitive Data (SSD), ISATAP tunnel support, RA guard, User Datagram Protocol (UDP), Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, loopback detection, Unknown Storm Control, BPDU Guard, Link Aggregation Group (LAG), Voice Services Discovery Protocol (VSDP), Rapid PVST+ (RPVST+), Duplicate Address Detection (DAD)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Processor
X ARM: 800 MHz
RAM
512 MB
Flash Memory
256 MB
Status Indicators
Status, link/activity/speed
Interfaces
24 x 10GBase-X SFP+ ¦ 4 x 10GBase-T RJ-45 uplink ¦ 1 x USB Type A ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x console RJ-45
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Rack Mounting Kit
Included
MTBF
1,356,179 hours
Compliant Standards
UL 60950, CSA 22.2, FCC CFR47 Part 15 B Class A, USGv6
Localization
Colombia, Canada, Chile, Mexico, Latin America, United States
Width
17.3 in
Depth
13.8 in
Height
1.7 in
Weight
9.7 lbs
Service & Support
Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - web support - 1 year ¦ Technical support - phone consulting - 1 year
Min Operating Temperature
32 °F
Max Operating Temperature
122 °F
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-13 °F
Max Storage Temperature
158 °F
Humidity Range Storage
10 - 90% (non-condensing)

User Guides

Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports Data Sheet

Frequently Asked Questions

Cisco CBS350-24XS 24-Port Gigabit Managed Switch with 10G SFP+/RJ45 Combo Ports (NA)
Frequently Asked Questions (FAQ's)



What are the main features of the Cisco CBS350-24XS 24-Port Managed Network Switch?
  • The Cisco CBS350-24XS has 24 ports for fast data transfer, advanced security features, VLAN support, QoS capabilities, and simple management options.
    • Is the Cisco CBS350-24XS suitable for small businesses?
  • Yes, it is. The CBS350-24XS is intended to meet the networking needs of small and medium-sized businesses, providing scalability and dependable performance.
    • Does the Cisco CBS350-24XS support PoE (Power over Ethernet)?
  • The CBS350-24XS does not support PoE. However, Cisco does offer other models in the CBS350 series that support PoE.
    • Can I stack multiple Cisco CBS350-24XS switches for increased scalability?
  • Yes, you can stack up to four Cisco CBS350 switches, including the CBS350-24XS, using Cisco's stacking technology to improve management and scalability.
    • What type of security features does the Cisco CBS350-24XS offer?
  • The CBS350-24XS protects your network from unauthorized access and threats using advanced security features such as Access Control Lists (ACLs), MAC-based port security, and Secure Shell (SSH) encryption.
    • Does the Cisco CBS350-24XS support Quality of Service (QoS) prioritization?
  • Yes, it does. The CBS350-24XS supports QoS to prioritize specific types of traffic, ensuring peak performance for critical applications and services.
    • What is the maximum data transfer speed supported by the Cisco CBS350-24XS?
  • The CBS350-24XS supports Gigabit Ethernet speeds, with data transfer rates of up to 1 Gbps (Gigabit per second) on each port.
    • Is the Cisco CBS350-24XS easy to manage?
  • Yes, the CBS350-24XS has a user-friendly web-based management interface and supports Cisco's Smart Network Application (SNA) for easy configuration and monitoring.
    • Can I monitor network traffic with the Cisco CBS350-24XS?
  • Yes, the CBS350-24XS supports network traffic monitoring through features such as port mirroring and SNMP (Simple Network Management Protocol) for detailed network analysis.
    • Does the Cisco CBS350-24XS support VLAN (Virtual Local Area Network) configuration?
  • Yes, it does. The CBS350-24XS supports VLAN configuration, which enables you to segment your network for better performance and security.
    • What is the warranty period for the Cisco CBS350-24XS?
  • The Cisco CBS350-24XS has a limited lifetime warranty, providing peace of mind and ensuring dependable performance in the long run.
    • Can I integrate the Cisco CBS350-24XS with existing network infrastructure?
  • Yes, the CBS350-24XS is designed to work seamlessly with existing network infrastructure, including standard protocols and interoperability with other Cisco devices.
    • Is the Cisco CBS350-24XS rack-mountable?
  • Yes, the CBS350-24XS is rack-mountable, which allows for simple installation in standard 19-inch racks or cabinets.
    • Does the Cisco CBS350-24XS support IPv6 (Internet Protocol version 6)?
  • Yes, the CBS350-24XS supports IPv6, ensuring compatibility with cutting-edge networking technologies while also future-proofing your network infrastructure.
    • What are the power requirements for the Cisco CBS350-24XS?
  • The CBS350-24XS requires AC power and operates within standard voltage ranges, making it suitable for use in a variety of environments.
    • Can I access the Cisco CBS350-24XS remotely?
  • Yes, the CBS350-24XS supports remote management, including secure access via SSH or HTTPS for easy monitoring and configuration from anywhere.
    • Does the Cisco CBS350-24XS support link aggregation?
  • Yes, the CBS350-24XS supports link aggregation (also known as EtherChannel or port trunking), which combines multiple ports to increase bandwidth and redundancy.
    • What type of cable is required for connecting devices to the Cisco CBS350-24XS?
  • The CBS350-24XS connects devices to its ports using standard Ethernet cables (Cat5e or higher), ensuring compatibility with existing infrastructure.
    • Is the Cisco CBS350-24XS fanless?
  • No, the CBS350-24XS has integrated cooling fans, which ensure optimal performance and reliability under a variety of operating conditions.
    • Does the Cisco CBS350-24XS include any mounting hardware or accessories
  • Yes, the CBS350-24XS typically comes with mounting brackets and screws for easy installation in a rack or cabinet.
