Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch (CBS350-12XT-NA-RF) | Refresh
SKU: CBS350-12XT-NA-RF
Same Day Shipping - Arrives in 3-5 Business Days /returns-icon.jpg){kind=icon}
30-day Returns
Have one to sell? Click here to sell to us
Same Day Shipping - Arrives in 3-5 Business Days 30-day Returns Overview
Overview of Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch (CBS350-12XT-NA-RF) | Refresh
The Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch is a high-performance managed switch designed for expanding networks and small enterprises in need of secure, dependable and quick 10G connection. This Cisco Business 350 Series switch provides the bandwidth required for servers, NAS storage, virtualized applications and high-speed workstations with 10 x 10GBase-T ports and 2 x 10G combination SFP+/RJ-45 ports. Even under heavy loads, its 178.56 Mpps forwarding rate and 240 Gbps switching capacity keep data flowing smoothly. In addition to supporting Cisco Business Dashboard management, Layer 2 and Layer 3 features and enterprise-class security capabilities in a small rack-mountable form factor, the CBS350-12XT was designed for easier administration.
Key Features of Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch
• 10 x 10GBase-T ports and 2 x 10G combo SFP+/RJ-45 ports for flexible high-speed connectivity.
• 240 Gbps switching capacity and 178.56 Mpps forwarding performance for nonblocking traffic flow.
• Layer 2 and Layer 3 capabilities, including VLANs, static routing and policy-based routing.
• Advanced security features such as 802.1X, ACLs, DHCP snooping, Dynamic ARP Inspection, IP source guard and storm control.
• Cisco Business Dashboard support for centralized monitoring, deployment and lifecycle management.
• Link aggregation support, jumbo frames, and stackability for scalable network design.
• Quiet dual-fan cooling and rack-mountable metal chassis for professional installations.
• Remote management options including SSH, SNMP, HTTPS, CLI and RADIUS/TACACS+.
Benefits of Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch
🗹 Accelerate data transfers and eliminate bottlenecks with true 10 Gigabit switching across critical network segments.
🗹 Improve network reliability for shared storage, backup systems and virtualized environments that depend on consistent throughput.
🗹 Strengthen security at the edge with robust access control and traffic protection features that help defend business data.
🗹 Simplify IT operations through centralized Cisco Business Dashboard management and straightforward web-based administration.
🗹 Scale confidently as your business grows, due to Layer 3 support, link aggregation and stackable architecture.
🗹 Reduce congestion on busy networks by giving servers, workstations and uplinks the speed they need to perform at their best.
Specifications
Specifications for Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch (CBS350-12XT-NA-RF) | Refresh
| Manufacturer | Cisco |
| Manufacturer Part Number | CBS350-12XT-NA-RF |
| Product Name | Cisco CBS350-12XT 12-Port 10G Managed Network Switch |
| Product Type | Networking Switch |
Enclosure Type | Rack-mountable |
Subtype | 10 Gigabit Ethernet |
Ports | 10 x 10GBase-T + 2 x combo 10 Gigabit SFP+/RJ-45 |
Performance | Switching capacity: 240 Gbps ¦ Forwarding performance (64-byte packet size): 178.56 Mpps |
Capacity | RPVST+ instances: 126 ¦ MSTP instances: 8 ¦ VLANs supported: 4094 ¦ ACL rules: 1024 ¦ Buffer capacity (MB): 3 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 2KB |
Max Units In A Stack | 4 |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MLDv2, MLD, CIDR, MSTP, RSTP, STP |
Remote Management Protocol | SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS |
Encryption Algorithm | SSL |
Authentication Method | Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2) |
Features | Flow control, BOOTP support, ARP support, VLAN support, Syslog support, DoS attack prevention, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), reset button, STP Root Guard, Uni-Directional Link Detection (UDLD), LACP support, LLDP support, DHCP relay, Management Information Base (MIB), Multicast VLAN Registration (MVR), Generic VLAN Registration Protocol (GVRP), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, IP source guard, SmartPort technology, dual image support, DNS client, Secure Core Technology (SCT), Private VLAN Edge (PVE), LLDP-MED, IP/Mac/Port Binding (IPMB), Secure Sensitive Data (SSD), ISATAP tunnel support, RA guard, User Datagram Protocol (UDP), Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, loopback detection, Unknown Storm Control, BPDU Guard, Link Aggregation Group (LAG), Voice Services Discovery Protocol (VSDP), Rapid PVST+ (RPVST+), Duplicate Address Detection (DAD) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az |
Processor | X ARM: 800 MHz |
RAM | 512 MB |
Flash Memory | 256 MB |
Status Indicators | Status, link/activity/speed |
Interfaces | 12 x 10GBase-T RJ-45 ¦ 2 x 10GBase-X SFP+ ¦ 1 x USB Type A ¦ 1 x management (Gigabit LAN) RJ-45 console |
Power Device | Internal power supply |
Voltage Required | AC 100-240 V (50/60 Hz) |
Rack Mounting Kit | Included |
MTBF | 633,324 hours |
Compliant Standards | UL 60950, CSA 22.2, FCC CFR47 Part 15 B Class A, USGv6 |
Localization | Colombia, Canada, Chile, Mexico, Latin America, United States |
Width | 17.3 in |
Depth | 8 in |
Height | 1.7 in |
Weight | 6.46 lbs |
Service & Support | Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - web support - 1 year ¦ Technical support - phone consulting - 1 year |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 10 - 90% (non-condensing) |
Min Storage Temperature | -13 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 10 - 90% (non-condensing) |
User Guides
Frequently Asked Questions
Cisco Business CBS350-12XT 12-Port 10 Gigabit Managed Network Switch
Frequently Asked Questions (FAQ's)
What are the key features of the Cisco CBS350-12XT switch?
The Cisco CBS350-12XT includes 12 high-speed 10G Ethernet ports, advanced Layer 3 static routing, robust security features, and an intuitive web-based management interface—making it ideal for high-performance business networks.
Is the Cisco CBS350-12XT suitable for small to medium businesses?
Yes, it is purpose-built for SMBs, offering enterprise-grade performance with simplified deployment and scalability.
How many total ports does the CBS350-12XT offer?
It provides 12 dedicated 10 Gigabit Ethernet ports for ultra-fast connectivity.
Does the Cisco CBS350-12XT support Layer 3 switching?
Yes, it supports Layer 3 static routing, enabling efficient inter-VLAN traffic management and reduced network latency.
Can I manage the CBS350-12XT switch through a web interface?
Absolutely. It features an intuitive web-based GUI for easy configuration, monitoring, and troubleshooting.
Does this switch support VLAN segmentation?
Yes, VLAN support allows you to segment your network for improved security and performance.
Is the Cisco CBS350-12XT fanless or does it include active cooling?
It includes active cooling to ensure stable performance in high-demand environments.
What types of devices can connect to the CBS350-12XT?
You can connect servers, workstations, NAS devices, routers, and other switches using 10G Ethernet connections.
Does this switch offer link aggregation (LAG) capabilities?
Yes, it supports link aggregation to increase bandwidth and provide redundancy.
How does the CBS350-12XT enhance network security?
It includes advanced features such as ACLs, port security, and 802.1X authentication to protect against unauthorized access.
Is the Cisco CBS350-12XT rack-mountable?
Yes, it is designed for standard 1U rack-mount installation.
What kind of performance can be expected from this 10G switch?
It delivers low latency, high throughput, and consistent performance for bandwidth-intensive applications.
Can I monitor traffic on the CBS350-12XT switch?
Yes, it supports SNMP, RMON, and port mirroring for comprehensive traffic monitoring and diagnostics.
Is IPv6 supported by the CBS350-12XT?
Yes, it fully supports IPv6 for both management and data forwarding.
How does the CBS350-12XT handle power efficiency?
It complies with IEEE 802.3az Energy Efficient Ethernet standards to reduce power consumption during low usage.
Can I use the CBS350-12XT in a data center environment?
Yes, its high-speed 10G ports and advanced features make it suitable for data center edge or aggregation layers.
Does the switch support Quality of Service (QoS)?
Yes, advanced QoS ensures priority handling for voice, video, and mission-critical applications.
What is the maximum switching capacity of the CBS350-12XT?
It offers up to 240 Gbps switching capacity for high-performance traffic handling.
Can I stack the CBS350-12XT with other switches?
While it doesn’t support physical stacking, it offers virtual stacking for centralized management.
What management protocols are supported by the CBS350-12XT?
It supports SNMP, RMON, CLI, and a web-based interface, providing flexible management options for IT administrators.
