Cisco CBS250-24P-4X 24-Port Smart Switch (NA) | Refresh

Overview of Cisco CBS250-24P-4X-NA-RF 24-Port Smart Switch | Refresh

The Cisco CBS250-24P-4X-NA-RF 24-Port Smart Switch is a powerful and intelligent 24-port Gigabit Ethernet smart network switch intended to meet the changing networking needs of small and medium-sized businesses (SMBs). This Cisco smart switch provides dependable, secure, and scalable connectivity for your growing network infrastructure thanks to its powerful PoE+ capabilities, advanced security features, Quality of Service (QoS) support, and user-friendly management interface. The Cisco CBS250-24P-4X is equipped with 24 PoE+ (Power over Ethernet) compliant Gigabit Ethernet ports and a remarkable 195W PoE+ budget, ensuring seamless power delivery to your PoE-enabled devices such as IP phones, wireless access points, and IP cameras. Its intelligent power management system distributes power efficiently across all ports, and the Perpetual PoE feature ensures continuous power during switch reloads for maximum uptime and reliability.

The Cisco CBS250-24P-4X includes a number of security features to help protect your network from unauthorized access and potential threats. It provides comprehensive 802.1x network access control, including flexible authentication and RADIUS integration. Additionally, it offers advanced security features such as Access Control Lists (ACLs), BPDU Guard, and SSH/SSL for secure remote management. You can easily configure, manage, and monitor your network using the intuitive web-based interface, command-line interface (CLI), or Cisco Business Mobile App. The Cisco CBS250-24P-4X supports a variety of management protocols, such as TFTP for software upgrades, NTP for precise time synchronization, and the Cisco Discovery Protocol for simple network integration. It also includes the Switched Port Analyzer (SPAN) feature for network monitoring and troubleshooting.

The Cisco CBS250-24P-4X, powered by an efficient switching architecture, provides smooth data transfers at a forwarding rate of 41.66 Mpps and a switching capacity of 56 Gbps. It also includes four 10 Gigabit SFP+ uplink ports, which allow you to expand your network and connect to faster backbone switches or routers as your business grows. This smart switch supports advanced features such as VLANs, QoS, and IGMP Snooping, ensuring optimal network performance and traffic prioritization. The Cisco CBS250-24P-4X 24-Port Smart Switch is an excellent choice for SMBs looking for a scalable, secure, and cost-effective networking solution. This intelligent Cisco network switch offers SMB networking solutions such as secure network management, high-bandwidth 10G SFP+ uplinks for network expansion, and Quality of Service features for optimal network performance, making it an important addition to Cisco's networking solution lineup.

Key Features of Cisco CBS250-24P-4X-NA-RF 24-Port Smart Switch

• 24 10/100/1000 Gigabit Ethernet ports

• 4 additional 10 Gigabit SFP+ uplink ports for high-speed fiber connectivity

• 24 PoE+ (Power over Ethernet) compliant ports

• 195W total PoE budget to power PoE-enabled devices like IP phones, wireless APs, and IP cameras

• Supports 802.1X port-based authentication for network access control

• Access Control Lists (ACLs) to enhance network security

• Web-based user interface and command-line interface (CLI) for configuration and monitoring

• Supports management protocols like TFTP, NTP, and Cisco Discovery Protocol
• Compatible with Cisco Business Mobile App for remote management

• Supports VLANs, QoS, IGMP Snooping, and other Layer 2 features for optimal network performance

• Switching capacity of 56 Gbps and forwarding rate of 41.66 Mpps

• 1.5 MB packet buffer for efficient data handling

• Compact form factor suitable for various environments

Specifications for Cisco CBS250-24P-4X-NA-RF 24-Port Smart Switch | Refresh

Cisco CBS250-24P-4X-NA-RF 24-Port Smart Switch Data Sheet
