Avaya 700500758 IPO 500 TCM-8 Module | Like New

Avaya 700500758 IPO 500 TCM-8 Module | Like New

SKU: 700500758-LN
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$31.99 $31.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Avaya IPO 500v2 TCM-8 Digital Station

  • Compatible with IP Office 500 Release 7.0
  • Compatible with IP Office Partner Version R7.0
  • Up to 8 Digital Extensions per card
  • Maximum of 4 per System
  • Support Norstar M-Series, Norstar T-Series, and Norstar Audio Conference Units
  • Mother card, takes internal slot in cabinet
  • Accepts one Daughter Card such as Trunk 4, Single or Dual T-1/PRI Card

Part Number: 700500758


Frequently Asked Questions

Avaya 700500758 | IPO 500 TCM-8 Module Frequently Asked Questions (FAQ's)



What is the Avaya IP500 TCM-8 module used for?
  • It provides connectivity for up to 8 digital Nortel telephones on an Avaya IP Office system.
    • What type of phones are compatible with the TCM-8 module?
  • It supports Nortel digital phones, such as the M7000 and T7000 series.
    • Is the TCM-8 compatible with all versions of IP Office?
  • It is compatible with IP Office Release 6.0 and later.
    • Can the TCM-8 module be used in the IP500 base chassis?
  • Yes, it installs directly into an IP500 control unit chassis.
    • Does the TCM-8 module support hot-swapping?
  • No, the system should be powered down before installing or removing the module.
    • Can I mix TCM-8 modules with other station modules?
  • Yes, you can install TCM-8 modules alongside other modules like DS or Phone modules in an IP500 chassis.
    • Is an external power supply required for the TCM-8?
  • No, it draws power from the IP500 chassis.
    • Does the TCM-8 support IP phones?
  • No, it only supports digital Nortel phones, not IP or analog devices. /li>
    • Can I upgrade the firmware on the TCM-8 module?
  • Firmware updates are managed via the IP Office system software.
    • How many TCM-8 modules can be installed in one IP500 chassis?
  • Up to 4 TCM-8 modules can be installed, subject to available slots and system resources.
    • Does it support caller ID on Nortel phones?
  • Yes, when the phone model supports it and the line configuration is appropriate.
    • What is the maximum cable length for connected phones?
  • Typically up to 1000 feet (305 meters) using proper cabling.
    • Is licensing required for using the TCM-8 module?
  • Yes, Nortel Digital Station licenses are required for each phone connected.
    • Can I connect a mix of Nortel and Avaya phones to the same system?
  • Yes, with the correct modules installed, both Nortel and Avaya phones can coexist.
    • What tools are required for installation?
  • A screwdriver for securing the module; configuration is done via IP Office Manager software.
    • Does the module support features like voicemail or conferencing?
  • These features are system-level functions and are available when the phones are connected via TCM-8.
    • Can I use the TCM-8 module with IP Office Server Edition?
  • TCM-8 is intended for use with IP Office control units, not Server Edition directly.
    • Is the TCM-8 module hot-desk capable?
  • Yes, if the system is configured to support hot-desking, Nortel phones via TCM-8 can use this feature.
    • Does it require specific firmware or software versions?
  • Yes, it requires IP Office Release 6.0 or higher for full functionality.
    • Where do I configure TCM-8 connected phones?
  • Configuration is done in the Avaya IP Office Manager under Extensions and Users.
