Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | Refresh

Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | Refresh

SKU: C1000-16P-2G-L-RF
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$399.99 $399.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview for Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | Refresh

The Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch is an enterprise-class Layer 2 managed switch intended for small enterprises and branch offices that require dependable network connectivity with Power over Ethernet features. This versatile network switch combines powerful features with accessible management, making it excellent for setting up IP phones, wireless access points, and security cameras. The C1000-16P-2G-L provides 120W of PoE+ power via 16 Gigabit Ethernet ports and two SFP uplink ports for network expansion2. With its fanless design and extensive security features, this switch delivers dependable performance for important IoT deployments and out-of-the-wiring-closet installations.


Key Features of Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch


• 16 Gigabit Ethernet ports with PoE+ support

• 120W PoE+ power budget for connected devices

• 2 SFP uplink ports for flexible connectivity

• Layer 2 switching with advanced management features

• Fanless operation for quiet environments

• 36 Gbps switching bandwidth capacity

• Web-based GUI and CLI management options

• Enhanced network security features

• Zero-touch deployment capability

• Energy-efficient design

• VLAN support for network segmentation

• Quality of Service (QoS) capabilities

• 512MB DRAM and 256MB Flash memory

• Compact form factor (10.56" x 11.69" x 1.73")

• Limited lifetime warranty

Specifications

Specification for Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch | Refresh

Manufacturer Cisco
Manufacturer Part Number C1000-16P-2G-L-RF
Product Name Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch
Product Type Networking Switch
Enclosure Type Rack-mountable
Subtype Gigabit Ethernet
Ports 16 x 10/100/1000 (PoE+) + 2 x Gigabit SFP (uplink)
Power Over Ethernet (PoE) PoE+
PoE Budget 120 W
Performance Forwarding bandwidth: 18 Gbps ¦ Switching bandwidth: 36 Gbps ¦ Forwarding rate (64‑byte L3 packets): 26.78 Mpps
Capacity Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte
Jumbo Frame Support 10240 bytes
Routing Protocol IGMP, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), fanless, Shaped Round Robin (SRR), LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, Management Information Base (MIB), Class of Service (CoS), 802.1x authentication, DiffServ Code Point (DSCP) support, IGMP filtering, IP source guard, Weighted Tail Drop (WTD), SmartPort technology, VLAN Trunking Protocol (VTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), proxy ARP, Switched Port Analyzer (SPAN), loopback detection, MAC Access Bypass (MAB), BPDU Guard, Network Edge Access Topology (NEAT)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX
Processor X ARM: 800 MHz
RAM 512 MB
Flash Memory 256 MB
Status Indicators Status
Interfaces 16 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-X SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A
Power Device Internal power supply
Installed Qty 1
Voltage Required AC 120/230 V (50 - 60 Hz)
Power Consumption Operational 136.92 Watt
Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A
Width 10.6 in
Depth 11.7 in
Height 1.7 in
Weight 5.25 lbs
Service & Support Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature 23 °F
Max Operating Temperature 122 °F
Humidity Range Operating 5 - 90%
Min Storage Temperature -13 °F
Max Storage Temperature 158 °F
Humidity Range Storage 5 - 95%

User Guides

Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch Data Sheet

Frequently Asked Questions

Cisco Catalyst C1000-16P-2G-L 16-Port PoE Ethernet Managed Network Switch
Frequently Asked Questions (FAQ's)



What is the Cisco Catalyst C1000-16P-2G-L?
  • The Cisco Catalyst C1000-16P-2G-L is a 16-port PoE Ethernet managed switch for small to medium-sized businesses that provides high performance, security, and ease of use.
    • How many PoE ports does the switch have?
  • The switch contains 16 PoE ports.
    • What is the total PoE power budget?
  • The overall PoE power budget is up to 120W.
    • How many uplink ports are available?
  • Uplink ports consist of 2 Gigabit SFP.
    • What is the switching capacity of the Cisco Catalyst C1000-16P-2G-L?
  • The switch capacity is 36 Gbps.
    • Does the switch support VLANs?
  • Yes, the switch does support VLANs.
    • What security features are included?
  • IEEE 802.1x, port security, and ACLs are some of the security features available.
    • Is the switch energy-efficient?
  • Yes, it uses energy-saving technologies to reduce power consumption.
    • Can the switch be managed via a web interface?
  • Yes, it has an intuitive web-based interface for simple configuration and monitoring.
    • Does the switch support Quality of Service (QoS)?
  • Yes, it offers advanced QoS features.
    • What are the physical dimensions of the switch?
  • The dimensions are 1.73 x 17.50 x 10.14 inches.
    • What is the weight of the switch?
  • The switch weighs 7.72 pounds.
    • What is the maximum power consumption of the switch?
  • The maximum power consumption is 160 watts.
    • Is the switch rack-mountable?
  • Yes, the switch is designed to be rack mounted.
    • Does the switch support link aggregation?
  • Yes, it does support link aggregation.
    • What is the forwarding rate of the switch?
  • The forwarding rate is 26.78 Mbps.
    • Can the switch be used in a stackable configuration?
  • No, the Cisco Catalyst C1000 series does not allow stacking.
    • What is the warranty period for the switch?
  • The switch typically comes with a limited lifetime warranty, but you should check with the vendor for specific warranty information.
    • Does the switch support IPv6?
  • Yes, the switch does support IPv6.
    • Is the switch suitable for outdoor use?
  • No, the switch is intended for indoor use in controlled environments.
