  • Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | Refresh
Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | Refresh

Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | Refresh

SKU: C1000-8FP-2G-L-RF
(0)No Reviews yet
Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$329.99 $329.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | Refresh

The Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks is a high-performance Layer 2 managed switch intended for small enterprises and branch offices. This switch, which has Power over Ethernet Plus (PoE+), enhanced security features and customizable management choices, is suitable for powering IoT devices, IP phones, wireless access points and surveillance cameras while maintaining dependable network connectivity. The Catalyst 1000-8FP-2G-L has eight Gigabit Ethernet PoE+ ports and a total PoE budget of 120W, allowing it to power connected devices directly via network cable. It also has two combination Gigabit SFP uplink ports for fast fiber connections to core networks or extra switches. This switch, with its fanless design for silent operation and compact form factor, is ideal for noise-sensitive situations such as offices or classrooms. Advanced Layer 2 features including as VLANs, QoS and IGMP snooping ensure optimal traffic management, while strong security measures protect the network from illegal access.


Key Features of Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks


• 8 PoE+ Ports provides up to 30W per port with a total power budget of 120W for powering connected devices.

• 2 SFP Uplink Ports with high-speed fiber connectivity for seamless network expansion.

• Layer 2 Switching includes VLANs, QoS, IGMP snooping, and link aggregation for efficient traffic management.

• Advanced Security features MAC-based port security, ACLs and IEEE 802.1X authentication.

• Fanless Design with silent operation suitable for noise-sensitive environments.

• Energy Efficiency supports Energy Efficient Ethernet (EEE) standards to reduce power consumption.

• Space-saving design fits neatly into rack-mounted or standalone setups.

• Managed via CLI or an intuitive web-based interface.

• Supports forwarding bandwidth of 10 Gbps and switching bandwidth of 20 Gbps.


Benefits of Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks


🗹 PoE+ eliminates the need for separate power adapters, reducing cable clutter.

🗹 SFP uplink ports enable easy integration with core networks or additional switches.

🗹 Protect sensitive data with advanced security features like MAC-based port authentication.

🗹 Layer 2 features ensure efficient handling of network traffic for improved performance.

🗹 Fanless design ensures quiet performance in noise-sensitive environments like offices or classrooms.

🗹 Energy-efficient technologies help reduce operational costs over time.

🗹 Fits neatly into any workspace without taking up excessive space.

🗹 Intuitive management options simplify installation and configuration.

🗹 Built with Cisco’s trusted quality for long-term use in demanding environments.

🗹 Advanced features ensure compatibility with evolving business needs.

Specifications

Specifications for Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks | Refresh

ManufacturerCisco
Manufacturer Part NumberC1000-8FP-2G-L-RF
Product NameCisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks
Product TypeNetworking Switch
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (uplink)
Power Over Ethernet (PoE)
PoE+
PoE Budget
120 W
Performance
Forwarding bandwidth: 10 Gbps ¦ Switching bandwidth: 20 Gbps ¦ Forwarding rate (64‑byte L3 packets): 14.88 Mpps
Capacity
Unicast MAC addresses: 15360 ¦ IPv4 unicast direct routes: 542 ¦ IPv4 unicast indirect routes: 256 ¦ IPv6 unicast direct routes: 414 ¦ IPv6 unicast indirect routes: 128 ¦ IPv4 routes (static): 16 ¦ IPv6 routes (static): 16 ¦ IPv4 routes (Multicast): 1024 ¦ IPv6 groups (Multicast): 1024 ¦ IPv4/MAC security ACEs: 600 ¦ IPv6 security ACEs: 600 ¦ Active VLANs: 256 ¦ VLAN IDs: 4094 ¦ STP instances: 64 ¦ SPAN sessions: 4 ¦ MTU-L3 packet: 9198 byte
Jumbo Frame Support
10240 bytes
Routing Protocol
IGMP, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Authentication Method
Kerberos, Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS), Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, sFlow, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), fanless, Shaped Round Robin (SRR), LACP support, LLDP support, MAC Address Notification, Energy Efficient Ethernet, Management Information Base (MIB), Class of Service (CoS), 802.1x authentication, DiffServ Code Point (DSCP) support, IGMP filtering, IP source guard, Weighted Tail Drop (WTD), SmartPort technology, VLAN Trunking Protocol (VTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), proxy ARP, Switched Port Analyzer (SPAN), loopback detection, MAC Access Bypass (MAB), BPDU Guard, Network Edge Access Topology (NEAT)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, Bluetooth 4.0, IEEE 802.1AX
Processor
X ARM: 800 MHz
RAM
512 MB
Flash Memory
256 MB
Status Indicators
Status
Interfaces
8 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-T / 1000Base-X RJ-45/SFP uplink ¦ 1 x management RJ-45 ¦ 1 x mini-USB Type B ¦ 1 x USB Type A
Power Device
Internal power supply
Installed Qty
1
Voltage Required
AC 120/230 V (50 - 60 Hz)
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1-07 Second Edition, AS/NZS CISPR22 Class A
Width
10.6 in
Depth
12.7 in
Height
1.7 in
Weight
5.95 lbs
Service & Support
Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days
Min Operating Temperature
23 °F
Max Operating Temperature
122 °F
Humidity Range Operating
5 - 90%
Min Storage Temperature
-13 °F
Max Storage Temperature
158 °F
Humidity Range Storage
5 - 95%

User Guides

Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks Data Sheet

Frequently Asked Questions

Cisco Catalyst 1000-8FP-2G-L 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Uplinks
Frequently Asked Questions (FAQ's)



What is the total number of ports on the Cisco C1000-8FP-2G-L switch?
  • The switch has eight Gigabit Ethernet PoE+ ports and two combo Gigabit SFP uplink ports.​
    • What is the PoE power budget of the C1000-8FP-2G-L switch?
  • The switch’s PoE power budget is 120 watts.
    • Is the Cisco C1000-8FP-2G-L suitable for rack mounting?
  • Yes, this switch is designed to be rack mounted.​
    • What type of management is supported by the C1000-8FP-2G-L switch?
  • The switch allows for management via both a Command-Line Interface (CLI) and an intuitive web-based user interface (UI).​
    • Does the switch support VLAN and QoS configurations?
  • Yes, the switch supports VLANs for traffic segmentation and QoS for bandwidth management and ensuring data delivery quality.​
    • What are the security features of the C1000-8FP-2G-L?
  • It contains features like IEEE 802.1X port-based network access control, which helps to secure the network by controlling who can access the network and what they can access.
    • Can this switch operate in fanless mode?
  • Yes, the C1000-8FP-2G-L works in a fanless mode, making it ideal for environments where noise must be minimized.
    • What is the warranty for the C1000-8FP-2G-L switch?
  • It comes with a Limited Lifetime Warranty, which provides long-term assurance about the reliability of the hardware.
    • What are the dimensions and weight of the switch?
  • The switch measures 268 x 323 x 44 mm and weighs around 2.70 kg.
    • Does the switch support energy-efficient Ethernet?
  • Yes, it supports IEEE 802.3az, an energy-efficient Ethernet standard.
    • How is network monitoring handled on the C1000-8FP-2G-L?
  • The switch supports network monitoring with features such as sFlow, which allows administrators to monitor traffic at wire speed.​
    • Are there any special hardware features in this switch?
  • This model has advanced PoE+ capabilities and dual combo uplink ports for flexible connectivity.
    • What is the cooling mechanism of the switch?
  • The switch uses a fanless design for quiet operation, which is particularly suitable for office environments.
    • How does the switch handle Internet of Things (IoT) devices?
  • It is designed to optimally support IoT devices, with its full PoE+ ports and robust security features.​
    • Can the switch be managed remotely?
  • Yes, it supports remote management capabilities via web UI and CLI, which allow administrators to manage the network from anywhere.
    • What are the primary use cases for the C1000-8FP-2G-L?
  • It is ideal for small businesses and branch offices that require a secure, manageable, and reliable network environment for both standard and PoE+ enabled devices.
    • Does this model include any uplink options?
  • Yes, it has two combo SFP/RJ-45 uplink ports for increased connectivity flexibility.​
    • What are the environmental operation conditions for the switch?
  • The switch operates effectively over a wide temperature range and is designed for low power consumption.
    • Is there support for advanced routing protocols on this switch?
  • While primarily a Layer 2 switch, it does support basic static routing functionalities, which are suitable for small network environments.​
    • What type of power supply is required for this switch?
  • It utilizes a standard 110 to 220V AC power supply.
