Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP (NA) | Refresh

Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP (NA) | Refresh

SKU: CBS220-16T-2G-NA-RF
(0)No Reviews yet

Cisco Refresh offers fully remanufactured, Cisco Certified products with SmartNet eligibility (OEM Refurbished).

Clean Serial: YES

Same Day Shipping - Arrives in 3-5 Business Days
30-day Returns
$89.99 $89.99
Available Quantity:
For immediate assistance call our support team at 973-808-4588. For additional information, send an email to website@telquestintl.com.

Overview

Overview of Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP (NA) | Refresh

The Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP (NA) is a business-class Layer 2 controlled switch built for small organizations that require dependable network connectivity and key administration features. This affordable network switch combines simple administration features with dependable performance, making it excellent for small company networks and branch installations. The CBS220-16T-2G includes 16 Gigabit Ethernet ports and two SFP uplink connectors for network expansion. This switch, with its intuitive web interface and energy-efficient architecture, offers critical network management features at a cheap price.


Key Features of Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP


• 16 Gigabit Ethernet ports for high-speed connectivity

• 2 SFP uplink ports for flexible network expansion

• Layer 2 switching with basic management features

• 36 Gbps switching capacity

• User-friendly web-based management interface

• Essential security features with 802.1X support

• Easy-to-use device manager

• Energy-efficient design with EEE support

• VLAN support for basic network segmentation

• Quality of Service (QoS) capabilities

• Simple network monitoring and control

• Fanless design for quiet operation

• IPv6 support

• Compact desktop form factor

• Limited lifetime warranty

Specifications

Specifications for Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP (NA) | Refresh

ManufacturerCisco
Manufacturer Part NumberCBS220-16T-2G-NA-RF
Product NameCisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP
Product TypeNetworking Switch
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
16 x 10/100/1000 + 2 x Gigabit SFP (uplink)
Performance
Forwarding performance (64-byte packet size): 26.78 Mpps ¦ Switching capacity: 36 Gbps
Capacity
MSTP instances: 16 ¦ VLANs supported: 256 ¦ ACL rules: 512 ¦ Buffer capacity (MB): 4.1
MAC Address Table Size
8192 entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Encryption Algorithm
SSL
Authentication Method
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
Features
BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Access Control List (ACL) support, Quality of Service (QoS), Cable Diagnostics Function, fanless, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, Management Information Base (MIB), dual firmware images, Neighbor Discovery Protocol (NDP), Generic VLAN Registration Protocol (GVRP), 802.1x authentication, Type of Service (ToS), DiffServ Code Point (DSCP) support, VLAN management, LLDP-MED, Guest VLAN, User Datagram Protocol (UDP), STP loop guard, Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, loopback detection, Telnet server, Unknown Storm Control, BPDU Guard, Cisco Discovery Protocol (CDP), Duplicate Address Detection (DAD), TCP support, auto voice VLAN, Automatic Media-Dependent Interface Crossover (MDIX)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az
RAM
256 MB
Flash Memory
64 MB
Status Indicators
System, link/activity/speed
Interfaces
16 x 10/100/1000 Base-T RJ-45 ¦ 2 x 1000Base-X SFP uplink
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
11.4 Watt
Rack Mounting Kit
Included
MTBF
1,062,289 hours
Compliant Standards
C-Tick, UL 60950, CSA 22.2, FCC CFR47 Part 15 A
Localization
Colombia, Canada, Chile, Mexico, Latin America, North America
Width
17.3 in
Depth
8 in
Height
1.7 in
Weight
5.47 lbs
Service & Support
Limited warranty - replacement - 3 years - response time: next business day
Min Operating Temperature
32 °F
Max Operating Temperature
122 °F
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-4 °F
Max Storage Temperature
158 °F
Humidity Range Storage
10 - 90% (non-condensing)

User Guides

Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP Data Sheet

Frequently Asked Questions

Cisco CBS220-16T-2G 16-Port Gigabit Managed Network Switch with SFP

Frequently Asked Questions (FAQ's)



What is the maximum power consumption of the Cisco CBS220-16T-2G switch?
  • The maximum power usage is 30 watts.
    • Does the Cisco CBS220-16T-2G support Power over Ethernet (PoE)?
  • This model does not support PoE.
    • What is the warranty period for the Cisco CBS220-16T-2G switch?
  • The Cisco CBS220-16T-2G has a limited lifetime hardware warranty.
    • Can the Cisco CBS220-16T-2G be managed via a web interface?
  • Yes, it provides a simple web-based management interface for straightforward configuration.
    • Does the Cisco CBS220-16T-2G support VLANs?
  • Yes, it does support VLANs for network segmentation.
    • What is the operating temperature range for the Cisco CBS220-16T-2G switch?
  • The working temperature ranges from 0°C to 40°C.
    • Does the Cisco CBS220-16T-2G support Quality of Service (QoS)?
  • Yes, it provides QoS for prioritizing vital network traffic.
    • Is the Cisco CBS220-16T-2G suitable for small businesses?
  • Yes, it is intended for small and medium-sized enterprises seeking dependable networking solutions.
    • What is the maximum data transfer rate for the SFP uplink ports?
  • The SFP uplink ports offer data transfer rates of up to 1 Gbps.
    • Does the Cisco CBS220-16T-2G support link aggregation?
  • Yes, it allows link aggregation, which increases bandwidth and redundancy.
    • Can the Cisco CBS220-16T-2G be rack-mounted?
  • Yes, it can be rack mounted with the provided brackets.
    • Does the Cisco CBS220-16T-2G support SNMP?
  • Yes, it does support SNMP for network management.
    • What is the MTBF (Mean Time Between Failures) for the Cisco CBS220-16T-2G switch?
  • The MTBF is about 1,000,000 hours.
    • Does the Cisco CBS220-16T-2G support IGMP snooping?
  • Yes, it supports IGMP snooping to improve multicast traffic management.
    • Is the Cisco CBS220-16T-2G fanless?
  • Yes, it does not use fans and functions silently.
    • Does the Cisco CBS220-16T-2G support 802.1X authentication?
  • Yes, it supports 802.1X port-based network access control.
    • What is the maximum forwarding rate of the Cisco CBS220-16T-2G switch?
  • The maximum forwarding rate is 23.8 million packets/second.
    • Does the Cisco CBS220-16T-2G support RMON?
  • Yes, it supports RMON, which allows for extensive network monitoring.
    • What is the size of the MAC address table in the Cisco CBS220-16T-2G switch?
  • The MAC address table contains 8,000 entries.
    • Does the Cisco CBS220-16T-2G support DHCP snooping?
  • Yes, it supports DHCP snooping to improve security.
